- Page 1 AP&T Shanghai Anping Static Technology Co.,Ltd High Efficient Electroshock-proof Ion Bar AP-AB1205 AP&T...
- Page 2 Widely used in printing, UV flatbed industry Effectively solve the problem caused by static electricity Control ink splashing Prevent uneven scattering Static removal Prevent adhesion of objects Prevent sticking...
- Page 3 High efficient Safe Static removal...
-
Page 4: Intelligent Control
Intelligent Control Ion balance/ ion output frequency adjustable The output ratio of positive and negative ions is adjustable, which can be used to adjust the ion balance voltage Positive high voltage amplitude Positive high voltage amplitude (Positive high voltage) (Positive high voltage) The negative ion output increases with the increase of negative high voltage amplitude time... - Page 5 Intelligent Control Ion balance/ ion output frequency adjustable Button function instructions Symbol Operation instructions Function Unlock before adjusting operating parameters. Unlock Device starts running when power is on. Press "STOP" to standby and no high voltage Run / Pause output. Press "RUN" again and the device will start working. Press CTTH first, then +/- to increase or decrease the cleaning cycle.
- Page 6 Pulse AC The effect of static eliminating is better compare to power frequency AC ion bar Pulse AC Comparison with traditional AC Positive pulse Negative pulse Pulse AC Positive voltage working time The pulsed AC method alternately applies "+" and "-" (Positive high pressure) high voltage to one electrode needle to generate two polar ions.
- Page 7 Efficiently static removal Stay away static trouble & for clean production environment 150mm 150mm 1.7s 2.8s 30mm 3.2s 3.1s 50mm 3.1s 2.3s 0.1s 70mm 5.1s 6.0s 1.0s 100mm 150mm*150mm Flat tester Test Conditions： Ion bar length：410mm Working frequency：30Hz Test standard: ANSI/ESD.STM3.1, SJ/T 11446—2013 Test instrument: Trek157 static tester Test voltage: ±1000V →...
- Page 8 Features Safe / Easy to use / Durable No.1 Easy installation M5 sheet slider nut installation accessories provided. Put the slider nut into the slot of the ion bar. Slide left and righ to adjust position and can adapt to various installation environments.
-
Page 9: Specification
Specification Details / Parameter / Size Product Details DC24V high flexible towline power cord M5-12*12*4 square nuts Front Strip grounding electrode Working status indicator Needle holder and electrode needle Back Product Size unit：mm DC24V high flexible towline power cord M5-12*12*4 square nuts Working status indicator Needle holder and electrode needle Strip grounding electrode... -
Page 10: Product Parameter
Product Parameter Model AP-AB1205 Input voltage DC 24V Power Electrode pin voltage Vpp:8-12KV Ion emission Pulse AC Emitter electrode Discharge structure Resistance coupling Output frequency 1,3,5,10,20,30,50Hz; (EX-Work setting: 30Hz) Discharge range L*W*H：Bar Length*200*100mm Installation distance 30→100mm Ion balance ≤|±30V| （ AVE ）... -
Page 11: Use Of The Product
Use of the product Installation step / Installation position / Packaging accessories Installation step Connection method 1 Connection method 2 Bracket installation 1.Take out the ion bar, adapter power supply, power supply network cable , Connection method 1: Connect one end of the DC24V high-flexible power stainless steel mounting brackets and other accessories from the packing supply cable to the industrial control power supply and insert one end of the box. -
Page 12: Installation Position
Installation position 1. Choose the best static elimination position and install the bar body and the matching power adapter firmly after the static detection of the on-site working environment. The installation angle should be perpendicular to the surface of the charged body and the installation distance can be referred to the following table. -
Page 13: Packaging Accessories
Packaging accessories Name Image Part No. Specification Quantity GRT-240200: DC24V 2A, dual network port Power Adapter OSP000601 output, Size: 123*61*40.5mm (L*W*H) National standard power 8YXG25110 Standard:1.8m, optional:3m/5m cord Three-core flexible power cord with aviation plug —— Standard 1.5m (customizable on site) (optional) Network cable (optional) ——... - Page 14 It can be used only after the electrical performance index is normal. After-sales service AP-AB1205 has undergone rigorous testing and aging treatment before ex-work. Its performance has completely reached the relevant indicators marked in the usage instruction.
- Page 15 S pe cia lity C re a t es Val ue S pe cia lity C re a t es Val ue Shanghai Anping Static Technology Co.,Ltd Tel : 021-64517676 Fax : 021-64517673 Postcode : 200233 Website : www.ap-static.com Address : 3/F,Building 27,No.69,Guiqing Road,Shanghai,China...
