- Page 1 AP - DB1227 Shanghai Anping Static Technology Co.,Ltd Long Air Source Distance Free Long-Distance Electrostatic Ionizing Bar A P & T...
- Page 2 Suitable for film, textiles, rubber, etc. Effectively solve the problems caused by static electricity Static Removal Prevent adhesion of objects Prevent blockage of adhesion Control ink splashing Prevent uneven scattering...
- Page 3 The AP-DB1227 Long-Range Deionization Ion Bar is a rod-type deionization device developed and manufactured by Anping Company for long-range deionization. The AP-DB1227 Long-Range Deionization Ion Bar uses a DC high voltage power supply and tungsten electrodes. By alternating positive and negative DC high voltages on coupled electrode needles, it generates corona discharge, ionizes air molecules, and produces a large number of positive and negative air ions.
-
Page 4: Intelligent Remote Control
Intelligent Remote Control The effect of static eliminating is better compare to power frequency AC ion bar ◈ Pulse DC VS Traditional AC The pulsed DC method alternately applies positive "+" and negative "-" high voltages to the electrode needles, generating ions of both polarities. -
Page 5: Indicator Light
Features Safe / Easy to use / Durable 1350 1750 2150 2550 2950 ▍ Electric shock proof ▍ Multiple Sizes, Customizable The product is applicable to different Strong ion release capability, suitable for de-electrification distances, including static elimination without an air source 7 length specifications to meet the and at long distances de-electrification range requirements... -
Page 6: Product Specifications
Product Specifications Product Details / Product Size / Product Parameter ◈ Product Details Power / Communication Interface M5 Mounting Slide Electrode Needle Base Frequency Coding Switch Grounding studs (1)、Select the best position for de-electrification and securely install the bar body and the accompanying power adapter. (2)、Connect one end of the network cable to the power adapter port and the other end to the ion bar's "REM"... - Page 7 Product Specifications Product Details / Product Size / Product Parameter (5)、The dimension diagram of the adapted power supply is as follows： 60.5 123.8 39.5 Power / Communication Port Three-phase power socket （DC24V direct output） （AC100-240V, 50/60Hz) Note: Each adapted power supply can load up to 2 ion bars, with each port loading 1 ion bar. It cannot be connected in series. The port wiring information is the same as the table above.
- Page 8 Intelligent Remote Control Adjustable Cleaning Cycle, Static Elimination Speed And Ion Balance. Button Function instructions Function Symbol Operation instructions Unlock Unlock before adjusting operating parameters. Device starts running when power is on. Press "STOP" to standby and no Run / Pause high voltage output.
-
Page 9: Product Parameter
Product Specifications Product Details / Product Size / Product Parameter ◈ Product Parameter Model AP-DB1227 Input Voltage DC 24V Power ＜ 15W Electrode High Voltage ＜ 30KV Ion Emission Pulse DC Emitter electrode Tungsten（W） FREQ: 0.1, 0.3, 0.5, 0.7, 1, 3, 5, 7, 10, 30, 55Hz... -
Page 10: Use Of The Product
Use of the product Packaging Accessories / Safety Warning /Trouble Shooting ◈ Packaging Accessories Name Picture Part No. Specification Quantity GRT-240200 DC24V 2A P/N:1/2+ 5/6- Port Power Adapter AP2930003 metal PE National Standard Power 8YXG25110 Standard:1.8m, optional:3m/5m Cord Double Ended Crystal Head 8WXI00004 Standard:2.5m, 5m/10m:optional Black Shield Cable... -
Page 11: Troubleshooting
Its strictly forbidden to touch the electrode needles when power is on, otherwise it is easy to cause malfunctions and electric shock accidents. The electrode needle is a sharp metal object, please use it with care. Please check the specifications of the power supply before powering on the product. Any power supply that does not meet the specifications will cause damage to the product. -
Page 12: Maintenance
After-sales service AP-DB1227 Ion Bar has undergone rigorous testing and aging treatment before ex-work. Its performance has completely reached the relevant indicators marked in the usage instruction. AP&T makes a commitment to the customer that any defective parts inspected by AP&T will be repaired or replaced free of charge within one year from the date of purchase. - Page 13 SPECIALITY CREATES VALUE Professional electrostatic intelligent monitoring/analysis and elimination solution provider Shanghai Anping Static Technology Co.,Ltd Tel：021-6451 7676 Website：www.ap-static.com Address：3-4/F,Building 27,No.69,Guiqing Road,Shanghai,China...
