Model TD-30 (Fig. 10)
Hold the clutch (5) stationary.
Models TD-30, TD-32Q , TD-42 (Fig. 10)
– Adjust the distance between the clamp-
ing cams (2) by rotating the coupling
(4) according to the diameter of the ac-
cessory (1).
– Insert the accessory (1) as far as it will
go into the chuck (3).
– Secure the accessory (1) in the chuck by
tightening the coupling (4) as far as it
will go in the direction of ( GRIP).
Removing accessories
HD-80, HD-120, ND-85 models (Fig. 7)
– Insert the wrench (1) into the side hole
of the chuck, unscrew the cam release
coupling (2) (3) of the chuck, and then
pull the accessories out of the chuck.
– HD-120M, HD-132M, ND-45 models
(Fig. 9)
– Hold the coupling (1) stationary and
manually unscrew the coupling (2) (in
the direction of the OPEN or AUF.RE-
LEASE arrow on the chuck) to open the
chuck cams, then remove the accesso-
ry from the chuck.
Model TD-30 (Fig. 10)
Hold the clutch (5) stationary.
Models TD-30, TD-32Q , TD-42 (Fig. 10)
Open the chuck cams (2) by rotating the
coupling (4) and pull the accessory (1) out
of the chuck (3).
Installing the key in the holder
(Fig. 11)
HD-120, HD-120M, ND-85 models
Once the accessory has been installed
and secured in the chuck, we recommend
inserting the key (1) into the correspond-
ing hole (2) in the chuck key holder. This
way, the key is always accessible.
Adjusting the depth stop HD-80,
HD-120, HD-120M, HD-132M, ND-45,
ND-85 (Fig. 12)
– Loosen the handle bracket (3) by un-
screwing the additional handle (2).
– Adjust the desired hole depth (A) by
moving the depth stop (1) in the handle
EU-NDHDTD0823001-0823002
bracket (3). For convenience, use the
scale on the depth stop.
– Secure the position of the depth stop
(1) by screwing in the additional han-
dle (2).
Bit holder. Installing/removing
accessories (Model TD-32Q )
Installing accessories
The bit holder can be used with accesso-
ries with a HEX 3/8" shank type.
– Remove the chuck (1) from the spindle
by pulling the retaining ring (2) away
from the power tool (Fig. 14).
– Place the accessory (1) in the bit hold-
er (2) (Fig. 13).
– Removing accessories
– Pull the accessory (1) out of the bit hold-
er (2) (Fig. 13).
Installing/removing the cam chuck
Model TD-32Q
Installing the cartridge (Fig. 14)
– While holding the chuck (1), pull the re-
taining ring (2) away from the power
tool.
– Place the chuck (1) on the spindle (bit
holder) (3) and then release the retain-
ing ring (2).
Replacing/removing
(Fig. 14)
– Pull the retaining ring (2) and remove
the chuck (1) from the spindle (bit hold-
er) (3).
If the bit holder is equipped with a 25 mm
bit (HEX 3/8" shank type), you can mount
the chuck on the spindle (bit holder) with-
out removing the bit from the bit holder.
Change the direction of rotation
WA R NI NG!
Change the direction of rotation
of the chuck and operating modes
(drilling/drilling)
power tool chuck has come to a
complete stop.
Models ND-45, ND-85 (Fig. 15)
To set the spindle to rotate clockwise,
move the switch to side (A), and to set
the spindle to rotate counterclockwise,
move the switch to side (B).
the cartridge
