6. DEFINITION AND APPEARANCE
Appointment.
The electric drill is designed for drilling
holes in various materials such as wood,
metal, plastic, drywall, ceramics, etc.,
as well as for screwing and unscrewing
fasteners such as self-tapping screws,
screws, confirmations, etc. In addition,
the power tool chuck can be fitted with
accessories for mixing mortars, brushes
for cleaning various surfaces, etc.
The hammer drill is designed for drilling
without impact, drilling (drilling with im-
pact), screwing and unscrewing fasten-
ers, stirring mortar mixtures, and clean-
ing various surfaces.
The torque drill is designed for screwing/
unscrewing fasteners (screws, screws,
self-tapping screws, confirmation screws,
dowels, bolts and nuts) with the use of
special bits and for drilling holes in metal,
wood, ceramics, as well as in various ma-
terials with the use of drills.
Appearance of ND-45, ND-85 (Fig. 1)
1 Cartridge
Place (holder) for drilling depth
2
stop (mod. ND-85)
3 Auxiliary handle (mod. ND-85)
4 Spindle rotation direction switch
5 Spindle speed controller (ND-85)
6 Switch
7 Ventilation openings
8 Locking button for the switch
9 Handle
Place (holder) for the cartridge
10
key
11 Drilling depth stop (ND-85)
12 Graphite brushes
13 Key for the cartridge
10
Appearance of HD-80, HD-120,
HD-120M, HD-132M (Fig. 2)
1 Cartridge
2 Depth limiter
3 Drilling/drilling mode switch
4 Additional gripping surface
5 Additional handle
6 Ventilation openings
7 Spindle speed controller
8 Switch
Place (holder) for the cartridge
9
key
Chuck rotation direction switch (in
10
HD-120, HD-120M models)
11 Locking button for the switch
12 Main handle
13 Power cord
Chuck rotation direction switch (in
14
HD-80, HD-132M models)
Chuck speed mode switch
15
(for HD-132M models)
Chuck wrench (for HD-80, HD-120
16
models)
Appearance of TD-30, TD-32Q ,
TD-42 (Fig. 3)
Clamping cams of the quick-
1
release chuck
Quick-clamping chuck coupling
2
(for TD-30 and TD-42 models)
3 Torque/drilling force controller
4 Ventilation openings
Switch for the direction of rotation
5
of the accessory
6 Switch
7 Locking button for the switch
8 Handle
9 Power cord
Quick-clamping chuck coupling
10
(for TD-32Q )
Retaining ring of the quick-release
11
chuck (for TD-32Q )
Brush assembly cover
12
(for TD-42 model)
Accessory speed mode switch
13
(TD-32Q , TD-42 models)
