Baumatic BFW46SS Instruction Manual

Baumatic BFW46SS Instruction Manual

46 bottle dual temperature electronic wine cooler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BFW46SS 46 Bottle
dual temperature
electronic wine cooler

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BFW46SS and is the answer not in the manual?

Questions and answers

Related Manuals for Baumatic BFW46SS

Summary of Contents for Baumatic BFW46SS

  • Page 1 BFW46SS 46 Bottle dual temperature electronic wine cooler...
  • Page 2 BFW46SS 46 Bottle dual temperature electronic wine cooler NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference, for you or any person not familiar with the operation of the appliance.

  • Page 3: Table Of Contents

    Specifications of your wine cooler 7 - 8 Description of the appliance Control panel Description of the product features Using your Baumatic wine cooler 9-11 Before switching on 9-10 During first use Switching on the appliance and setting the temperature...

  • Page 4: Environmental Note

    This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance. o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the...

  • Page 5: Important Safety Information

    Important safety information Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Baumatic Advice Line.
  • Page 6 Child safety o Packaging material should be kept away from children. o Children should not be allowed to touch the controls or play with the appliance. General safety o Do not pull on the power supply cable to remove the plug from your mains supply socket.

  • Page 7: Specifications Of Your Wine Cooler

    Specifications of your wine cooler o Gross capacity: 150 litres o Net capacity: 145 litres o Bottle capacity: 46 x 0.75 litre wine bottles o Electronic push button control operation o LED display o Celsius and Fahrenheit button o 4 Wooden shelves with telescopic runners o Adjustable temperature o Internal light o Black interior and exterior...

  • Page 8: Description Of The Appliance

    Model number ……………………………………………… Serial number ……………………………………………… Date of purchase …………………………………………….. Description of the appliance Control panel The control panel is located at the top of the appliance, above the glass door. Lower compartment A) Temperature decrease button B) Temperature increase button C) Temperature display D) Fahrenheit temperature neon E) Celsius temperature neon...

  • Page 9: Description Of The Product Features

    ON/OFF buttons (F) and (K). 4) The wine cooler shelves o The full depth shelves will fit onto the telescopic runners. Using your Baumatic wine cooler Before switching on o Make sure that it has been installed by a suitably qualified...

  • Page 10: During First Use

    o There can be an odour when you first switch on the appliance. It will lessen as the appliance starts to cool. During first use o When you first switch on the appliance, the compressor will run continuously until the wine cooler reaches a cool enough temperature.

  • Page 11: Interior Light

    Interior light o To operate the interior light, you should press the light ON/OFF button (K) for the lower zone or the light ON/OFF button (F) for the upper zone. Storage temperature neons o The control panel has four storage temperature neons; these indicate which type of wine is most suited to being stored in the temperature zone at the current temperature setting.

  • Page 12: Storing Your Wines

    Storing your wines The chart below indicates the ideal storage temperatures for different types of wine:- Type of wine Temperature Temperature (Celsius) (Fahrenheit) Red wine (*) 15.5 – 18.5°C 59.9 – 65.3°F White wine (**) 10 - 15°C 50 – 59°F Sparkling 7.2 –...

  • Page 13: Wine Storage Problems

    o Special stoppers that keep wine sparking and Champagne bubbling for one or two days after opening, can be bought at most good wine shops. o When stored correctly, white wines can keep well for up to two years. Full bodied reds will age well for ten years and dessert wines will age well for up to twenty years.

  • Page 14: Cleaning And Maintenance

    Slight effervescence in still wine- this isn’t really a problem with the way the wine has been stored, but as a result of incomplete malolactic fermentation before the wine was bottled. A good way to get rid of the effervescence is to let the wine breathe. Alternatively you can use a bottle vacuum device, after about five minutes the effervescence will vanish.

  • Page 15: Defrosting

    o After washing the appliance, wipe over the area that you have cleaned with a damp cloth and then dry it thoroughly. o When cleaning is complete, dry your hands and then reconnect the plug to your mains supply. Defrosting o Defrosting occurs automatically inside of the wine cooler during operation.

  • Page 16: Electrical Connection

    Electrical connection YOUR WINE COOLER IS INTENDED FOR FITTED AND PERMANENT INSTALLATION. We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.E. and local regulations. o Your wine cooler comes supplied with a 13 amp plug fitted.

  • Page 17: Positioning

    Positioning o It is advisable that your appliance is only installed in a location where the ambient temperature of the room, corresponds with the climate classification that is stated on the rating plate of your appliance. Your appliance may not function correctly if the ambient temperature falls outside of the following ranges.

  • Page 18: Built-In Installation

    Built-in installation o Your wine cooler can be used as a freestanding or a built in unit. If you are going to use it as a built in unit, then the dimensions shown in the diagram above will need to be followed. o In particular the depth dimension must be observed.

  • Page 19: Reversing The Door Of Your Wine Cooler

    Reversing the door of your wine cooler This appliance has the capability of the door opening from either the left or right hand side. The unit is delivered to you with the door opening from the left side. If you want to reverse the opening direction of the door, please follow the instructions below: Any parts that you remove from the appliance whilst reversing the door, should be retained for later use.
  • Page 20 o The seal must adhere properly all the way around the door. o If the seal is not adhering to the cabinet properly, then you should either:- a) Use a warm damp cloth and manipulate the seal until it does adhere to the cabinet properly, all the way around the door.

  • Page 21: Troubleshooting

    Troubleshooting IMPORTANT: If your wine cooler appears not to be operating properly, before contacting the Customer Care Department, please refer to the checklist below. PROBLEM POSSIBLE CAUSE Appliance does not operate Not plugged in. The circuit breaker has tripped or the fuse has blown.
  • Page 22 Or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the...

  • Page 23: Contact Details

    Czech Republic Baumatic CR spol s.r.o. Průmyslová zóna Sever 696 460 11 Liberec 11 United Kingdom Czech Republic Baumatic Ltd., Baumatic Buildings, +420 483 577 200 6 Bennet Road, Reading, Berkshire www.baumatic.cz RG2 0QX United Kingdom Slovakia Baumatic Slovakia, s.r.o.
