Two-stage gas furnaces
Table of Contents

Advertisement

These furnaces comply with requirements embodied
in the American National Standard/National
Standard of Canada ANSI Z21.47•CSA-2.3 Gas
Fired Central Furnaces.
As a professional installer you have an obligation to know
the product better than the customer. This includes all
safety precautions and related items.
Prior to actual installation, thoroughly familiarize yourself
with this Instruction Manual. Pay special attention to all
safety warnings. Often during installation or repair it is
possible to place yourself in a position which is more
hazardous than when the unit is in operation.
Remember, it is your responsibility to install the product
safely and to know it well enough to be able to instruct a
customer in its safe use.
Safety is a matter of common sense...a matter of thinking
before acting. Most dealers have a list of specific good
safety practices...follow them.
The precautions listed in this Installation Manual are
intended as supplemental to existing practices. However, if
there is a direct conflict between existing practices and the
content of this manual, the precautions listed here take
precedence.
Our continuing commitment to quality products may mean a change in specifications without notice.
©2016 - 2022
IOD-2011U
02/2022
DM96VE & DC96VE Two-Stage Gas Furnaces
(Type FSP CATEGORY IV Direct
or Non Direct Vent Air Furnace)
(Type FSP CATÉGORIE IV Direct
ou four á air soufflé non direct)
Installer:
Affix all manuals
adjacent to the unit.
19001 Kermier Rd. Waller, Tx 77484
*NOTE: Please contact your distributor or our
website for the applicable Specification Sheet
referred to in this manual.
Only personnel that have been trained to install, adjust,
service or repair(hereinafter, "service") the equipment
specified in this manual should service the equipment.
The manufacturer will not be responsible for any injury
or property damage arising from improper service or
service procedures. If you service this unit, you assume
responsibility for any injury or property damage which
may result. In addition, in jurisdictions that require one
or more licenses to service the equipment specified in
this manual, only licensed personnel should service the
equipment. Improper installation, adjustment, servicing
or repair of the equipment specified in this manual,
or attempting to install, adjust, service or repair the
equipment specified in this manual without proper training
may result in product damage, property damage, personal
injury or death.
Do not bypass safety devices.
www.daikincomfort.com
INSTALLATION INSTRUCTIONS
RECOGNIZE THIS SYMBOL AS
A SAFETY PRECAUTION.
WARNING
WARNING
