Daikin DC96VE Quick Start Manual
Daikin DC96VE Quick Start Manual

Daikin DC96VE Quick Start Manual

Two-stage, multi-speed ecm gas furnace
Hide thumbs Also See for DC96VE:

Advertisement

Standard Features
• Energy-efficient multi-speed ECM blower motor
• Heavy-duty stainless-steel
tubular heat exchanger
• Stainless-steel secondary heat exchanger
• Two-stage gas valve provides quiet,
economical heating
• Durable Silicon Nitride igniter
• Quiet two-speed induced draft blower
• Self-diagnostic control board with constant
memory fault code history output to a LED
• Color-coded low-voltage terminals with provi-
sions for electronic air cleaner and humidifier
• Low continuous fan speed options
offer quiet air circulation
• Can no longer be installed in California's
South Coast Air Quality Management District
(SCAQMD) on or after October 1, 2019
• AHRI Certified; ETL Listed
SS-DC96VE
Heating Input: 40,000 - 100,000 BTU/h
Cabinet Features
• Designed for multi-position installation:
DC96VE: Counter flow, horizontal left or right
• Certified for direct vent (2-pipe) or non-direct vent (1-pipe)
• Easy-to-install top venting with optional side venting
• Convenient left or right connection
for gas and electrical service
• Cabinet air leakage (Q
• Heavy-gauge steel cabinet with durable finish
• Fully insulated heat exchanger and blower section
• Airtight solid bottom or side return
with easy-cut tabs for effortless removal
in bottom air-inlet applications
* Complete warranty details available from your local dealer or at www.daikincomfort.com.
To receive the Lifetime Heat Exchanger Limited Warranty (good for as long as you own your
home), the 6-Year Unit Replacement Limited Warranty and the 12-Year Parts Limited Warranty,
online registration must be completed within 60 days of installation. Additional requirements
for annual maintenance are required for the Unit Replacement Limited Warranty. Online
registration and some of the additional requirements are not required in California or Quebec.
www.daikincomfort.com
DC96VE
Two-Stage, Multi-Speed
ECM Gas Furnace
Up to 96% AFUE
Contents
Nomenclature ........................................ 2
Product Specifications ........................... 3
Dimensions ............................................ 4
Airflow Specifications ............................ 5
Wiring Diagram .................................... 10
Accessories .......................................... 11
) ≤ 2%
Leak
07/20
Supersedes 10/19

Advertisement

loading
Need help?

Need help?

Do you have a question about the DC96VE and is the answer not in the manual?

Questions and answers

donn lpn
January 20, 2025

What is the recomended minimum setback temperature

Subscribe to Our Youtube Channel

Summary of Contents for Daikin DC96VE

  • Page 1: Table Of Contents

    Standard Features Cabinet Features • Energy-efficient multi-speed ECM blower motor • Designed for multi-position installation: DC96VE: Counter flow, horizontal left or right • Heavy-duty stainless-steel tubular heat exchanger • Certified for direct vent (2-pipe) or non-direct vent (1-pipe) • Stainless-steel secondary heat exchanger •...
  • Page 2: Nomenclature

          5   -­‐   2 000   C FM 060   -­‐   6 0,000   B TU/h 120   -­‐   1 20,000   B TU/h 080   -­‐   8 0,000   B TU/h www.daikincomfort.com SS-DC96VE...
  • Page 3: Product Specifications

    Product Specifications DC96VE DC96VE DC96VE DC96VE 0403BNA 0603BNA 0803BNA 1005CNA Heating Data High Fire Input¹ 40,000 60,000 80,000 100,000 High Fire Output¹ 38,400 57,600 76,800 96,000 Low-Fire Steady-State Input¹ 28,000 42,000 56,000 70,000 Low-Fire Steady-State Output¹ 26,880 40,320 53,760 67,200 AFUE²...
  • Page 4: Dimensions

    NC = For installation on non-combustible floors only. A combustible floor sub-base must be used for installations on combustible flooring. AIR DISCHARGE AIR RETURN MODEL DC96VE0403BNA 17½" 14⅝" 14" 14½" 16" DC96VE0603BNA 17½" 14⅝" 14" 14½" 16" DC96VE0803BNA 17½" 14⅝" 14" 14½" 16" DC96VE1005CNA 21"” 18⅛" 17½" 18" 19½" www.daikincomfort.com SS-DC96VE...
  • Page 5: Airflow Specifications

    • For most jobs, about 400 CFM per ton when cooling is desirable. • INSTALLATION IS TO BE ADJUSTED TO OBTAIN TEMPERATURE RISE WITHIN THE RANGE SPECIFIED ON THE RATING PLATE. Minimum Filter Sizes DC96VE DC96VE DC96VE DC96VE 0403BN* 0603BN*...
  • Page 6 All furnaces ship as high speed for cooling. Installer must adjust blower speed as needed. • For most jobs, about 400 CFM per ton when cooling is desirable. • INSTALLATION IS TO BE ADJUSTED TO OBTAIN TEMPERATURE RISE WITHIN THE RANGE SPECIFIED ON THE RATING PLATE. www.daikincomfort.com SS-DC96VE...
  • Page 7 All furnaces ship as high speed for cooling. Installer must adjust blower speed as needed. • For most jobs, about 400 CFM per ton when cooling is desirable. • INSTALLATION IS TO BE ADJUSTED TO OBTAIN TEMPERATURE RISE WITHIN THE RANGE SPECIFIED ON THE RATING PLATE. SS-DC96VE www.daikincomfort.com...
  • Page 8 All furnaces ship as high speed for cooling. Installer must adjust blower speed as needed. • For most jobs, about 400 CFM per ton when cooling is desirable. • INSTALLATION IS TO BE ADJUSTED TO OBTAIN TEMPERATURE RISE WITHIN THE RANGE SPECIFIED ON THE RATING PLATE. www.daikincomfort.com SS-DC96VE...
  • Page 9 Temperature Rise Range Chart SS-DC96VE www.daikincomfort.com...
  • Page 10: Wiring Diagram

    Wiring Diagram — DC96VE WARNING:DISCONNECT POWER BEFORE SERVICING. WIRING TO UNIT MUST BE PROPERLY POLARIZED AND GROUNDED. ECM MTR HARNESS CIRCULATOR BLOWER EQUIPMENT GND FIELD GND FIELD SPLICE SWITCH (TEMP.) IGNITER SWITCH (PRESS.) OVERCURRENT PROT. DEVICE JUNCTION TERMINAL INTERNAL TO...
  • Page 11: Accessories

    Accessories DC96VE DC96VE DC96VE DC96VE Model Description 0403BNA 0603BNA 0803BNA 1005CNA CVENT-2 Concentric Vent Kit (2”) √ √ √ √ CVENT-3 Concentric Vent Kit (3”) √ √ √ √ CFSB17 Downflow Sub-Base 17.5" √ √ √ CFSB21 Downflow Sub-Base 21"...
  • Page 12 Notes Our continuing commitment to quality products may mean a change in specifications without notice. © 2020 • Houston, Texas www.daikincomfort.com SS-DC96VE...
