infinix NOTE 40 X6853 Manual

Exploded diagram specification

1	TP+LCM	2	FRONT HOUSING GRAPHITE_FILM
3	GRAPHITE PLATE	4	MIDDLE HOUSING
5	FRONT CAMERA FRAME	6	FRONT CAMERA GROUNDING COPPER FOIL
7	32M CAMERA	8	SHIELDING CASE COPPER FOIL
9	MAIN BOARD	10	108M CAMERA GROUNDING COPPER FOIL
11	108M CAMERA	12	8W CAMERA
13	8W CAMERA CONDUCTIVE_FABRIC	14	2M CAMERA
15	2M CAMERA RUBBER	16	RECEIVER
17	MAIN FPC	18	BATTERY
19	UP FRAME	20	FLASH LAMP FPC
21	STEEL	22	MAIN PCB HEAT FILM
23	UP FRAME HEAT FILM	24	NFC WIRELESS FPC
25	COAXIAL CABLE 1	26	COAXIAL CABLE 2
27	SCREW	28	BATTERY COVER
29	REAR CAMERA DECORATION	30	REAR CAMERA LENS
31	108M CAMERA LENS	32	2M CAMERA LENS
33	SIM CONNECTOR	34	SPK BOX FRAME
35	ANTENNA SUB ADHESIVE	36	ANTENNA SUB
37	COAXIAL CABLE MYLAR	38	USB RUBBER
39	SUB RUBBER	40	FINGERPRINT
41	MOTOR	42	FINGERPRINT FOAM
43	LCM RUBBER

Know your phone

Front camera
Volume + button
Volume - button
Power button
NFC & Wireless charging

SIM/SD card installation

Power off your phone.
Refer to the following picture for SIM/SD card installation.

Charging the phone

You can charge your phone with a charger or by connecting it to a computer using a USB cable (comes with the phone).
Use Infinix chargers and cables only. Other chargers or cables may damage the device. This will invalidate your phone warranty.
Charging the phone
