- Page 1 QUICK INSTALLATION GUIDE SINGLE-PHASE ESS INVERTER 3K/3.6K/3.68K/4.6K/5K/6K...
-
Page 2: Packing List
QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K 1. Packing List Number Quantity Description Inverter Mounting bracket File package PV connector group (PV+/PV-) Battery waterproof cover COM waterproof cover Generator connector group Grid connector group Backup connector group 10-Pin terminal 14-Pin terminal Meter (Optional) M10 Expansion bolt M6 Security screw... - Page 3 QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K 2. Appearance Front PV SWITCH Left Bottom Right Number Description PV switch ON/OFF button and instruction lable PV connection port Battery connection port Communication port WIFI/LAN port GRID connection port External fan (It is only suitable for fan cooling series) GEN connection port BACKUP connection port...
-
Page 4: Installation
QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K 3. Location ≥500 ≤15° 328.0 29.0 270.0 12.0 32.0 ≥600 4. Installation The installation walls must be fireproof and non-flammable materials, otherwise there is a fire risk. DANGER Before drilling holes, check whether there are electric power pipes or other pipes buried in the walls to avoid risks. - Page 5 QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K 5. Installation Ensure that inverter and all cables to be installed are completely powered off during DANGER whole installation and connection. Otherwise, high voltage may result in fatal injury. Items Remark Screw M4 X 10 mm; 1.2 N·m ≥...
- Page 6 QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K 7. Wiring System for Parallel Application (2≤N≤9) Ensure that inverter and all cables to be installed are completely powered off during DANGER whole installation and connection. Otherwise, high voltage may result in fatal injury. L/Positive N/Negative Turn this switch...
- Page 7 QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K Note: ● BMS communication connection is only for lithium battery. ● It is necessary to additionally purchase suitable CT and meter for N≥6. ● It is necessary to turn the matched resistance switch of inverter No. 1 and inverter No. N to “ON” in parallel connection mode ●...
-
Page 8: Grid Connection
QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K 8. GRID Connection Before connecting the GRID terminal, ensure that both the AC terminal and the DC DANGER terminal are powered OFF and the PV switch is OFF. Otherwise there is a risk of high voltage shock. -
Page 9: Backup Connection
QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K 9. BACKUP Connection Before connecting the BACKUP terminal, ensure that both the AC terminal and the DC DANGER terminal are powered OFF and the PV switch is OFF. Otherwise there is a risk of high voltage shock. - Page 10 QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K 10. GEN Connection Before connecting the GEN terminal, ensure that both the AC terminal and the DC DANGER terminal are powered OFF and the PV switch is OFF. Otherwise there is a risk of high voltage shock.
-
Page 11: Battery Connection
QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K 11. Battery Connection Before connecting the battery terminal, ensure that both the AC terminal and the DC DANGER terminal are powered off and the PV switch is OFF. Otherwise there is a risk of high voltage shock. - Page 12 QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K 12. PV Connection Photovoltaic arrays exposed to sunlight will generate dangerous voltages! Before connecting the PV terminal, ensure that both the AC terminal and the DC DANGER terminal are powered off and the PV switch is OFF. Otherwise there is a risk of high voltage shock.
- Page 13 QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K 13. WIFI/LAN Module Connection (Optional) For details, please refer to the corresponding Module Installation Guide in the packing. The appearance of modules may be slightly different. The figure shown here is only for illustration. Move the cover.
- Page 14 QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K CT / Meter Connection Requirement NOTE CT: 3m cable length (default); 10m cable Inverter.Qty Distance CT Meter CT+Meter length (optional). Do not extend the CT cable. ≤ 3m Meter (optional): wire length up to 100m. 3 - 10m >...
-
Page 15: Startup/Shutdown Procedure
QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K 15. Startup/Shutdown Procedure Inspection Items The inverter is firmly installed. There is enough heat dissipation space, no external objects or parts left on the inverter. It is convenient for operation and maintenance. The wiring of the system is correct and firm. Check whether the DC and AC connections are correct with a multimeter, and ensure there is no short circuit, break, or wrong connection. -
Page 16: Shutdown Procedure
QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K Shutdown Procedure or go to APP (Quick Setup) “Beep” Click AC Circuit PV Switch Breaker BACKUP Circuit Battery Circuit Breaker Breaker... - Page 17 QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K 16. Display LED Indicator Status Description On-Grid status Blink Standby status Off-Grid status Fault has occurred...
- Page 18 QUICK INSTALLATION GUIDE Single-phase ESS Inverter 3K/3.6K/3.68K/4.6K/5K/6K NOTE As the technology is constantly updated and improved, the illustrations in this document are for reference only. Contents including illustrations in this document are subject to change without notice. 614-30253-00...
- Page 19 QUICK INSTALLATION GUIDE Single-phase ESS Inverter...
