  • Page 1 ROOF TOP TENT APEX RT-P-1600 OAP160RTTPA OWNER’S MANUAL...

  • Page 2: Helpful Hint

    Oztent Australia Pty Ltd www.oztent.com Document No: OAP160RTTPA Issue No. 0001 Issue date: 19/11/2024 © Oztent Australia Pty Ltd 19/11/2024 - All rights reserved Page 1 of 46...
  • Page 3 Apex RT-P-1600 to help you experience the great outdoors without sacrificing the comforts of home. This user manual is your guide to getting the most out of your Oztent Apex RT-P-1600. Inside, you’ll find easy-to-follow instructions on setup, care, and safety, ensuring the seamless enjoyment of your tent for years to come.

  • Page 4: Table Of Contents

    Pack Down Instructions .......................... 18 Apex Control Unit – Features and User Guide .................21 Remote Control User Guide ........................37 Apex Electronic Specifications ......................39 Oztent Apex RT-P-1600 Spare Parts ....................40 Additional Accessories Available for Your Apex 1600..............42 Warranty .................................46 Page 3 of 46...

  • Page 5: Package Contents

    Oztent Apex RT-P-1600 Gas Strut Safety System (4pc) OARTP01RTRCA Oztent Apex RT-P-1600 Remote Control OAP01SPAPEA Oztent Apex RTT 3 Metre Anderson Plug Extension OAP26RTLADA Oztent Apex Roof Top Tent 2.6m Telescopic Ladder With Carry Bag Oztent Apex RT-P-1600 User Manual Page 4 of 46...

  • Page 6: Warnings & Important Information

    Test drive short distances to become more comfortable with these changes. Professional Fitting Advised Oztent advises against attempting to fit this roof top tent to your vehicle yourself. We recommend that you contact your local dealer or get an authorised professional to fit your roof top tent.

  • Page 7: Safety And Care Considerations

    Apex RT-P-1600 Roof Top Tent Check your roof top tent’s fittings periodically to ensure they are secure. As a general rule of thumb, approximately once a week based on usage, loads and distances travelled is recommended. Always check that the latches are correctly sealed and ensure the product is closed correctly and locked before operating your vehicle.

  • Page 8: Fitting Instructions

    Fitting Instructions Warnings Installation Instructions: Improper installation may result in damage or injury. Follow all installation instructions carefully and use the correct tools. If unsure, seek professional assistance. Weight Capacity: Ensure the vehicle’s roof and roof rack system has a load capacity that supports both the rooftop tent and its occupants.
  • Page 9 Apex RT-P-1600 Roof Top Tent Fitting Kit Contents • 1 x Apex Series Fitment Bag • 8 x Channel Sliders L30 x H21 x H6 • 4 x ST Fitment Brackets • 1 x T25 Anti-Theft Hex key • 8 x M8 x 24mm Flat Washers •...
  • Page 10 M8 Flat M8 Spring Nyloc Nuts M8 Secure Nuts Washers (8pcs) Washers (8pcs) (8pcs) (8pcs) M8 x 50mm M8 x 70mm Channel Sliders Channel Bolts Channel Bolts L30 x H21 x H6 (8pcs) (8pcs) (8pcs) 3mm Hex Key (1pc) 4mm Hex Key (1pc) 5mm Hex Key (1pc) 6mm Hex Key (1pc) Apex Series...
  • Page 11 Apex RT-P-1600 Roof Top Tent 13mm Ratchet Ring 8-10mm Open End Spanner (1pc) Spanner (1pc) Fitting Rail Adjustment and Mounting Instructions Your Apex 1600 Roof Top Tent comes with the fitting rails pre-installed at a spacing of 820mm, with an additional set of spare holes at 600mm.
  • Page 12 4. Refit the Rails: Refit your rails using the 600mm set of holes for optimal placement. 5. Refit Grommets for Waterproofing: • Place the grommets back into any unused holes to maintain the tent’s waterproofing. • Proper placement of the grommets is essential to prevent water ingress and protect the interior of your tent from moisture.
  • Page 13 Apex RT-P-1600 Roof Top Tent Fitting Instructions Take your required size channel bolt for your fitment choice of Formal assembly or inverted assembly along with your slider. Note: M8x50mm channel bolt is for formal assembly and M8x70mm channel bolt is for inverted assembly.
  • Page 14 4. Repeat step 2 and 3 to fix the other channel bolts and sliders to the fitting extrusion rails. 5. With the assistance of at least three other people (4 in total), carefully lift the roof top tent over your vehicle and rest the tent on top of your roof rack/ platform, taking care to prevent the protruding bolts from damaging anything.
  • Page 15 Apex RT-P-1600 Roof Top Tent 8. Repeat step 7 to fix the other ST Fitment Brackets 9. Now you have all your ST Fitment Brackets fitted you can walk around your vehicle and check you tent it is positioned on the vehicle correctly.

  • Page 16: Ladder Instructions

    Ladder Instructions Important Notes Please read this booklet carefully as it contains important information regarding the proper use and setup of this ladder. Intended Use Only – Even Terrain – Ensure the Ladder Angle – DO NOT DO NOT use this ladder terrain is suitable for your climb the ladder if the for other applications.

  • Page 17: Setup Instructions

    Apex RT-P-1600 Roof Top Tent Setup Instructions Step 1 Unlock the side latches and release the standard front latches. Step 2 Push the rear section of the tent upwards first, followed by the front section. Page 16 of 46...
  • Page 18 Step 3 Connect the four gas strut safety system bars, stow the carry bag in an easy to remember place before connecting the ladder at your desired entrance. Step 4 Disconnect the internal bungees and pack them in their respective zippered pockets.

  • Page 19: Pack Down Instructions

    Apex RT-P-1600 Roof Top Tent Pack Down Instructions Step 1 Zip all windows up, leaving small gaps open to allow air to escape through the mesh screens. Step 2 Disconnect the four gas strut safety system bars, then place each bar inside the included drawstring carry bag.
  • Page 20 Step 4 Starting from the front, open the bungee system pockets and attach the bungee cords to the loops on the opposite wall. These will help pull the tent material inward as it collapses. Step 5 Close the rear entrance door most of the way, leaving the bottom section open and the handles positioned outside.
  • Page 21 Apex RT-P-1600 Roof Top Tent Step 7 Use the internal overhead pull down handle, or attach the pull down strap, to collapse the rear section. Step 8 Walk around the tent, ensuring that no excess material is sticking out. Secure both latches on the front of the tent.

  • Page 22: Apex Control Unit - Features And User Guide

    Apex Control Unit – Features and User Guide Welcome to the future of roof top tent camping with the Apex Control Unit! Designed to redefine outdoor experiences, this powerful control system introduces a suite of advanced features that enhance comfort, convenience, and safety on every adventure.
  • Page 23 Apex RT-P-1600 Roof Top Tent Do Not Use Excessive Force When Using Charging Wires Avoid excessive pulling or pushing when plugging in charging wires. Failure to do so may cause damage to the wire or charging ports and increase the risk of electric shock.
  • Page 24 Soft Fade Lighting Function The Soft Fade Lighting Function is designed to provide a smooth and elegant transition between lighting settings. When moving through the various lighting modes or brightness levels, this function softly dims and fades the light from one setting to the next, creating a gentle and visually pleasing lighting adjustment.
  • Page 25 Apex RT-P-1600 Roof Top Tent Emergency Signalling Mode The Oztent Apex Roof Top Tent comes with an innovative Emergency Signalling Mode, enhancing safety and communication in a range of situations. This feature uses integrated high-visibility lighting to signal for help during emergencies or low-visibility conditions.
  • Page 26 Apex Control Unit Button Functions Settings and Controls Explained The Settings Controls offer a comprehensive interface to manage fan, lighting, and sensor functionalities inside and outside the tent, enhancing user comfort and efficiency. • FAN: Controls the internal fan speed with low, medium, and high settings. Includes an “all power off”...
  • Page 27 Apex RT-P-1600 Roof Top Tent Black screen 1， ， Fan FAN Button 1， ， Fan 1， ， Fan 1， ， Fan The FAN Button provides versatile control over fan speed 1. Fan off settings and includes an ‘all power off’ mode for managing key 1.
  • Page 28 3. When INT light on, short press dimming low button 3rd times from 60% to 40% white lighting- gentle fade on. 4. When INT light on, short press dimming low 2， ， Internal lights button 4th times from 40% to 20% white lighting- gentle fade on.
  • Page 29 Apex RT-P-1600 Roof Top Tent External Lights (EXT) Button The EXT Button provides versatile control over external lighting 3， ， External lights with two modes: adjustable brightness for regular lighting needs of the external lighting and an emergency warning/ 3， ， External lights signalling mode with a flashing effect.
  • Page 30 screen When Sensor Light (SEN) Button 3， ， External lights The SEN Button provides control over the sensor-activated white light feature with two operational modes: 3， ， Sensor 1.External lights fade off 1. Short Press: off and • Sensor Light On: Activates 1.Short Press SEN button, Sensor white light on = Control Unit 100% - Fade on / Fade off on sensor operate, High...
  • Page 31 Apex RT-P-1600 Roof Top Tent Control Unit Specifications The Control Unit serves as the central hub for managing the Apex Roof Top Tent’s features, offering durable construction and intuitive touch control. • Material: ABS Shell – Provides a sturdy, impact-resistant external casing for durability.
  • Page 32 Supported Device Types This unit is designed to support a wide range of USB-powered devices, making it versatile and convenient for on-the-go charging. Compatible devices include smartphones, tablets, USB-powered fans, and other similar electronics. Whether you need to keep your phone charged, power a tablet for navigation, or run a portable fan, this unit provides reliable support for all your USB- powered essentials.
  • Page 33 Apex RT-P-1600 Roof Top Tent This configuration offers enhanced charging capabilities for PD-compatible devices when connected directly to a 12V power source. Type-C Input Specifications and Compatibility The Type-C Input Compatibility function allows for a secondary power source option via a Type-C input, serving as a backup power solution when the primary Anderson plug inlet power source is unavailable.
  • Page 34 3. Monitor for Overheating: The Apex electronic box includes multiple safety features, such as over-temperature protection, over-current protection, short-circuit protection, and surge current protection. These features ensure that the electronic box remains undamaged in case of overheating or power surges. In the event of overheating, the electronic box will automatically shut down safely to prevent damage.
  • Page 35 Apex RT-P-1600 Roof Top Tent 9. Observe Voltage and Power Limitations: Remember that the tent’s 12V power source is different from standard household AC power. The USB-C outputs and inputs are designed specifically for compatible USB-powered devices and may not handle devices that require higher power.
  • Page 36 Internal (INT) Lighting Specifications The Apex Roof Top Tent features high-quality LED strip lighting designed to create a comfortable and ambient atmosphere within the tent: • Working Voltage: 5V • Power Range: 0.3W to 3.5W Lighting Levels: • White Low: 45–60 Lumens •...
  • Page 37 Apex RT-P-1600 Roof Top Tent External Angled Lighting Specifications Illuminate your outdoor adventures with the Apex Roof Top Tent’s External Angled Lighting, a versatile solution for all your camping needs. Whether you’re winding down under the stars or setting up after dark, this lighting system offers adaptable brightness to suit any moment: •...

  • Page 38: Remote Control User Guide

    Remote Control User Guide Welcome to your Apex Remote Control! This guide will help you easily operate and get the most out of your remote control. Designed for quick access to key functions, the remote allows you to effortlessly manage settings, so you can focus on enjoying your adventure.
  • Page 39 Apex tents can control their own unit independently. If the remote is lost, a replacement can be easily obtained and programmed by contacting Oztent customer service. Setting up a new remote is a simple process: Apex Remote Setup Instructions: Turn on the power to the tent’s electronic control box.

  • Page 40: Apex Electronic Specifications

    Apex Electronic Specifications Control Unit Material: Black ABS shell Display Screen: Segment LCD Display Control: Touch screen power display. Display Activation: Simple press any button time to wake up display. Display Function: The screen and button display the current usage status. Display Off: Automatic fade off after 30 seconds to reduce power use.

  • Page 41: Oztent Apex Rt-P-1600 Spare Parts

    Apex RT-P-1600 Roof Top Tent Oztent Apex RT-P-1600 Spare Parts Be prepared for any adventure with our Oztent Apex RT-P-1600 Roof Top Tent Spare Parts list! Designed with convenience and reliability in mind, this spare parts resource ensures that nothing stands between you and the great outdoors.
  • Page 42 Oztent Apex RT-P-1600 Gas Strut Cover Set OARTP160SPBUA Oztent Apex RT-P-1600 Bungee Set OARTP160SPPDCA Oztent Apex RT-P-1600 Rapid Take Down System Cable Set OARTP160SPPDHA Oztent Apex RT-P-1600 Rapid Take Down System Handle Set Oztent Apex RT-P-1600 Rapid Take Down System Extension...

  • Page 43: Additional Accessories Available For Your Apex 1600

    Sold separately, these accessories seamlessly integrate with the Apex RT-P-1600, offering the flexibility to customise your tent setup for any terrain or weather. Embrace the freedom to explore with ease and style!
  • Page 44 Oztent Rear Tarp Extension for Apex 1600 Roof Top Tent Enhance your outdoor experience with the Oztent Rear Tarp Extension for the Apex 1600 Roof Top Tent. Designed for ultimate protection and versatility, this tarp extension offers UPF50+ sun protection and ensures complete coverage from the elements.
  • Page 45 System Extension! The Oztent Rooftop Tent Shoe Storage Bag The Oztent Rooftop Tent Shoe Storage Bag is the ideal solution for keeping your footwear organised and out of the way while camping. Crafted from durable, weather-resistant materials, this bag easily attaches to your rooftop tent using a straightforward slider attachment system, providing a secure fit that’s ready for any adventure.
  • Page 46 Oztent Apex Cigarette/Merit Plug to Anderson Plug Adapter The Oztent Apex Cigarette/Merit Plug to Anderson Plug Adapter enables seamless connectivity between your Apex Roof Top Tent and your vehicle’s accessory socket (cigarette lighter socket) or any external power source with a compatible socket.

  • Page 47: Warranty

    To the extent permitted (and does not exclude, restrict, or modify in any way) any non- by law, the liability of Oztent (if any) arising out of or in relation excludable statutory warranties in Australia, USA or International to the Product or any services supplied by Oztent shall be limited markets.
  • Page 48 Oztent Australia Pty Ltd PO Box Q1700 Sydney NSW 2000 Australia Ph: 02 8706 5100 USA Ph: 855 569 8368 International Ph: +61 2 8706 5100 www.oztent.com...
