OZTENT APEX RT-C-1400 Owner's Manual

Clamshell roof top tent

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

CLAMSHELL

ROOF TOP TENT

APEX RT-C-1400

OAP140RTTCA

OWNER'S MANUAL

Table of Contents

Need help?

Do you have a question about the APEX RT-C-1400 and is the answer not in the manual?

Questions and answers

Summary of Contents for OZTENT APEX RT-C-1400

Page 1 CLAMSHELL ROOF TOP TENT APEX RT-C-1400 OAP140RTTCA OWNER’S MANUAL...
Page 3 Apex RT-C-1400 to help you experience the great outdoors without sacrificing the comforts of home. This user manual is your guide to getting the most out of your Oztent Apex RT-C-1400. Inside, you’ll find easy-to-follow instructions on setup, care, and safety, ensuring the seamless enjoyment of your tent for years to come.
Page 4: Table Of Contents
Contents Package Contents ............................4 Warnings & Important Information ......................5 Safety and Care Considerations ......................6 Fitting Instructions ............................. 7 Ladder Instructions ..........................15 Setup Instructions ............................. 16 Pack Down Instructions .......................... 19 Apex 1400 Roof Weight Guidelines ....................22 Apex Control Unit – Features and User Guide ................23 Remote Control User Guide ........................39 Apex Electronic Specifications ......................41 Spare Parts ..............................42...
Page 5: Package Contents
Oztent Apex RT-C-1400 Spring Pole Slider Set (4pc) OARTC01SPSSA Oztent Apex RT-C-1400 Gas Strut Safety System (2pc) OAP01SPAPEA Oztent Apex RTT 3 Metre Anderson Plug Extension OAP26RTLADA Oztent Apex Roof Top Tent 2.6m Telescopic Ladder With Carry Bag Oztent Apex RT-C-1400 User Manual Page 4 of 46...
Page 6: Warnings & Important Information
Test drive short distances to become more comfortable with these changes. Professional Fitting Advised Oztent advises against attempting to fit this roof top tent to your vehicle yourself. We recommend that you contact your local dealer or get an authorised professional to fit your roof top tent.
Page 7: Maintenance Checks
Clamshell Apex RT-C-1400 Roof Top Tent No Automatic Car Wash Do not use an automatic car wash. This roof top tent must be removed prior to attempting to take a vehicle through an automatic car wash. Maintenance Checks Before attempting to drive your vehicle, ensure all bolts are tight and secure.
Page 8: Fitting Instructions
Fitting Instructions Warnings Installation Instructions: Improper installation may result in damage or injury. Follow all installation instructions carefully and use the correct tools. If unsure, seek professional assistance. Weight Capacity: Ensure the vehicle’s roof and roof rack system has a load capacity that supports both the rooftop tent and its occupants.
Page 9: Fitting Kit Contents
Clamshell Apex RT-C-1400 Roof Top Tent Fitting Kit Contents • 1 x Apex Series Fitment Bag • 8 x Channel Sliders L30 x H21 x H6 • 4 x ST Fitment Brackets • 1 x T25 Anti-Theft Hex key • 8 x M8 x 24mm Flat Washers •...
Page 10 M8 Flat M8 Spring Nyloc Nuts M8 Secure Nuts Washers (8pcs) Washers (8pcs) (8pcs) (8pcs) M8 x 50mm M8 x 70mm Channel Sliders Channel Bolts Channel Bolts L30 x H21 x H6 (8pcs) (8pcs) (8pcs) 3mm Hex Key (1pc) 4mm Hex Key (1pc) 5mm Hex Key (1pc) 6mm Hex Key (1pc) Apex Series...
Page 11 Clamshell Apex RT-C-1400 Roof Top Tent 13mm Ratchet Ring 8-10mm Open End Spanner (1pc) Spanner (1pc) Fitting Rail Adjustment and Mounting Instructions Your Apex 1400 Roof Top Tent comes with the fitting rails pre-installed at a spacing of 820mm, with an additional set of spare holes at 600mm.
Page 12 4. Refit the Rails: Refit your rails using the 600mm set of holes for optimal placement. 5. Refit Grommets for Waterproofing: • Place the grommets back into any unused holes to maintain the tent’s waterproofing. • Proper placement of the grommets is essential to prevent water ingress and protect the interior of your tent from moisture.
Page 13 Clamshell Apex RT-C-1400 Roof Top Tent Fitting Instructions Take your required size channel bolt for your fitment choice of Formal assembly or inverted assembly along with your slider. Note: M8x50mm channel bolt is for formal assembly and M8x70mm channel bolt is for inverted assembly.
Page 14 4. Repeat step 2 and 3 to fix the other channel bolts and sliders to the fitting extrusion rails. 5. With the assistance of at least three other people (4 in total), carefully lift the roof top tent over your vehicle and rest the tent on top of your roof rack/ platform, taking care to prevent the protruding bolts from damaging anything.
Page 15 Clamshell Apex RT-C-1400 Roof Top Tent 8. Repeat step 7 to fix the other ST Fitment Brackets 9. Now you have all your ST Fitment Brackets fitted you can walk around your vehicle and check you tent it is positioned on the vehicle correctly.
Page 16: Ladder Instructions
Ladder Instructions Important Notes Please read this booklet carefully as it contains important information regarding the proper use and setup of this ladder. Intended Use Only – Even Terrain – Ensure the Ladder Angle – DO NOT DO NOT use this ladder terrain is suitable for your climb the ladder if the for other applications.
Page 17: Setup Instructions
Clamshell Apex RT-C-1400 Roof Top Tent Setup Instructions Step 1 Unlock and release the 4 side latches. latch 3 latch 4 latch 1 latch 2 Step 2 Push the rear of the tent upwards, the X-frame gas strut system at the front, will automatically raise the tent.
Page 18 Step 4 Disconnect the rear external bungee cord and store it in its respective pocket. Step 5 Undo the zipper gussets around each entrance and connect the spring poles. Place the bottom of the poles into the inserts at the base of the tent and slot the rubber end caps in the slots at the top of the entrance cover.
Page 19: Important Safety Notes
Clamshell Apex RT-C-1400 Roof Top Tent Step 6 Disconnect the internal bungee cords and pack them in their respective zippered pockets. Step 7 Connecting the Anderson Plug Extension Cord: 1. Prepare the Anderson Plug: • Find the 300cm Anderson plug extension cord provided with your tent which will come in your ladder bag when shipped to you.
Page 20: Pack Down Instructions
Pack Down Instructions Step 1 Disconnect the gas strut safety system bars, and pack them in the carry bag. Step 2 Disconnect the entrance spring poles on the entrance covers. Step 3 Close all internal windows and side entrances, leaving small gaps open to allow air to escape through the mesh screens.
Page 21 Clamshell Apex RT-C-1400 Roof Top Tent Step 4 Open the internal wall bungee pockets and connect each bungee to the wall loop opposite. The bungee cords are colour coded to make this process simple. Step 5 Close and seal the entrance cover zippered gussets.
Page 22 Step 7 Use the pull-down handle or attach the pull down strap, to collapse the rear section. Step 8 Walk around the tent checking that no fabric or material is caught between the sealed tent. If the bungee cords are installed in the proper locations with colour code clips matching there should be no fabric outside of the seal.
Page 23: Apex 1400 Roof Weight Guidelines
Clamshell Apex RT-C-1400 Roof Top Tent Apex 1400 Roof Weight Guidelines To ensure the safety and longevity of your Apex 1400 rooftop tent, adhere to the following weight limits: • Closed Rooftop Tent: Maximum weight capacity is 30 kg. • Opened Rooftop Tent: Maximum weight capacity is 15 kg when using the supplied gas struts.
Page 24: Apex Control Unit - Features And User Guide
Apex Control Unit – Features and User Guide Welcome to the future of roof top tent camping with the Apex Control Unit! Designed to redefine outdoor experiences, this powerful control system introduces a suite of advanced features that enhance comfort, convenience, and safety on every adventure.
Page 25: Features Explained
Clamshell Apex RT-C-1400 Roof Top Tent Do Not Use Excessive Force When Using Charging Wires Avoid excessive pulling or pushing when plugging in charging wires. Failure to do so may cause damage to the wire or charging ports and increase the risk of electric shock.
Page 26 Soft Fade Lighting Function The Soft Fade Lighting Function is designed to provide a smooth and elegant transition between lighting settings. When moving through the various lighting modes or brightness levels, this function softly dims and fades the light from one setting to the next, creating a gentle and visually pleasing lighting adjustment.
Page 27 Clamshell Apex RT-C-1400 Roof Top Tent Signalling Mode The Oztent Apex Roof Top Tent comes with an innovative Signalling Mode, enhancing safety and communication in a range of situations. This feature uses integrated high-visibility lighting to signal for help during low-visibility conditions.
Page 28 Apex Control Unit Button Functions Settings and Controls Explained The Settings Controls offer a comprehensive interface to manage fan, lighting, and sensor functionalities inside and outside the tent, enhancing user comfort and efficiency. • FAN: Controls the internal fan speed with low, medium, and high settings. Includes an “all power off”...
Page 29 Clamshell Apex RT-C-1400 Roof Top Tent Black screen 1，， Fan FAN Button 1，， Fan 1，， Fan 1，， Fan The FAN Button provides versatile control over fan speed 1. Fan off settings and includes an ‘all power off’ mode for managing key 1.
Page 30 3. When INT light on, short press dimming low button 3rd times from 60% to 40% white lighting- gentle fade on. 2，， Internal lights 4. When INT light on, short press dimming low button 4th times from 40% to 20% white lighting- gentle fade on.
Page 31 Clamshell Apex RT-C-1400 Roof Top Tent External Lights (EXT) Button The EXT Button provides versatile control over external lighting 3，， External lights with two modes: adjustable brightness for regular lighting needs of the external lighting and an signalling mode with a 3，...
Page 32: Control Unit Specifications
screen When Sensor Light (SEN) Button 3，， External lights The SEN Button provides control over the sensor-activated white light feature with two operational modes: 3，， Sensor 1.External lights fade off 1. Short Press: off and • Sensor Light On: Activates 1.Short Press SEN button, Sensor white light on = Control Unit 100% - Fade on / Fade off on sensor operate, High...
Page 33: Supported Device Types
Clamshell Apex RT-C-1400 Roof Top Tent • Remote Connection: Internal Receiver Module – Connects seamlessly with the RF remote module for reliable communication. • Control Signal Wave: Uses 433 MHz radio waves for remote signal transmission, ensuring stable and effective control.
Page 34 Power Bank Requirements and Limitations In the event your primary Anderson plug power source becomes unavailable, your Apex Roof Top Tent features a dedicated power bank input designed as an emergency backup. Here’s a breakdown of power requirement: The power bank input supports the internal lighting, reading lights, external lighting, and display screen settings, requiring about 12W.
Page 35 Clamshell Apex RT-C-1400 Roof Top Tent Type-C Input Specifications and Compatibility The Type-C Input Compatibility function allows for a secondary power source option via a Type-C input, serving as a backup power solution when the primary Anderson plug inlet power source is unavailable. This feature enables users to power the system using a power bank, with a convenient storage pocket for the power bank located near the Apex control unit inside the tent.
Page 36 3. Monitor for Overheating: The Apex electronic box includes multiple safety features, such as over-temperature protection, over-current protection, short-circuit protection, and surge current protection. These features ensure that the electronic box remains undamaged in case of overheating or power surges. In the event of overheating, the electronic box will automatically shut down safely to prevent damage.
Page 37 Clamshell Apex RT-C-1400 Roof Top Tent 9. Observe Voltage and Power Limitations: Remember that the tent’s 12V power source is different from standard household AC power. The USB-C outputs and inputs are designed specifically for compatible USB-powered devices and may not handle devices that require higher power.
Page 38 Internal (INT) Lighting Specifications The Apex Roof Top Tent features high-quality LED strip lighting designed to create a comfortable and ambient atmosphere within the tent: • Working Voltage: 5V • Power Range: 0.3W to 3.5W Lighting Levels: • White Low: 45–60 Lumens •...
Page 39 Clamshell Apex RT-C-1400 Roof Top Tent External (EXT) Lighting Specifications The Apex Roof Top Tent’s External Lighting provides adaptable illumination to elevate your camping experience. Choose White Low at 70 lumens for a softer glow or White High at 270 lumens for full brightness, ensuring the perfect light for any moment.
Page 40: Remote Control User Guide
Remote Control User Guide Welcome to your Apex Remote Control! This guide will help you easily operate and get the most out of your remote control. Designed for quick access to key functions, the remote allows you to effortlessly manage settings, so you can focus on enjoying your adventure.
Page 41 Apex tents can control their own unit independently. If the remote is lost, a replacement can be easily obtained and programmed by contacting Oztent customer service. Setting up a new remote is a simple process: Apex Remote Setup Instructions: Turn on the power to the tent’s electronic control box.
Page 42: Apex Electronic Specifications
Apex Electronic Specifications Control Unit Material: Black ABS shell Display Screen: Segment LCD Display Control: Touch screen power display. Display Activation: Simple press any button time to wake up display. Display Function: The screen and button display the current usage status. Display Off: Automatic fade off after 30 seconds to reduce power use.
Page 43: Spare Parts
OARTC140FRA Oztent Apex RT-C-1400 Fitting Rail OARTC01ILEDA Oztent Apex RT-C-1400 Internal 1m LED Strip Set OARTC11ELEDA Oztent Apex RT-C-1400 0.98m External Rear Ladder LED Strip OARTC8ELEDA Oztent Apex RT-C-1400 0.8m External Side LED Strip OARTC140SPSEA Oztent Apex RT-C-1400 LED Sensor...
Page 44: Additional Accessories Available For Your Apex 1400
Apex 1400 rooftop tent. The Oztent Rooftop Tent Shoe Storage Bag The Oztent Rooftop Tent Shoe Storage Bag is the ideal solution for keeping your footwear organised and out of the way while camping. Crafted from durable, weather-resistant materials, this bag easily attaches to your rooftop tent using a straightforward slider attachment system, providing a secure fit that’s ready for any adventure.
Page 45 Oztent Apex Cigarette/Merit Plug to Anderson Plug Adapter The Oztent Apex Cigarette/Merit Plug to Anderson Plug Adapter enables seamless connectivity between your Apex Roof Top Tent and your vehicle’s accessory socket (cigarette lighter socket) or any external power source with a compatible socket.
Page 46 Page 45 of 46...
Page 47: Warranty
To the extent permitted (and does not exclude, restrict, or modify in any way) any non- by law, the liability of Oztent (if any) arising out of or in relation excludable statutory warranties in Australia, USA or International to the Product or any services supplied by Oztent shall be limited markets.
Page 48 Oztent Australia Pty Ltd PO Box Q1700 Sydney NSW 2000 Australia Ph: 02 8706 5100 USA Ph: 855 569 8368 International Ph: +61 2 8706 5100 www.oztent.com...
