- Page 1 ATR585C(ATR3CMOS08300KPA) User Manual ATR585C User Manual Version 1.2 Apr 2025 All materials related to this publication are subject to change without notice and its copyright totally belongs to ToupTek Photonics. Please download the latest version from touptek-astro.com.
-
Page 2: Table Of Contents
ATR585C(ATR3CMOS08300KPA) User Manual Contents ATR585C User Manual ............................... 1 Description and Features............................1 ATR585C Specifications and Performance ......................1 Camera Specifications ............................. 1 Sony IMX585 Sensitivity ..........................2 12bit ADC and ROI ............................2 DDR3 Buffer..............................2 Binning ................................2 Conversion Gain Switch .......................... -
Page 3: Description And Features
ATR585C(ATR3CMOS08300KPA) User Manual 1 Description and Features The ATR585C(ATR3CMOS08300KPA) camera is designed specifically for astrophotography. It is mainly used for deep sky photo shooting, since the camera has cooled CMOS sensor, ultra-low readout noise and zero amp-glow. It can be also used for planetary photo shooting. -
Page 4: Atr585C Specifications And Performance
ATR585C(ATR3CMOS08300KPA) User Manual 2 ATR585C Specifications and Performance 2.1 Camera Specifications Table 1 ATR585C Technique Specifications. Sensor Sony IMX585 back illuminated sensor Diagonal 12.85 mm Image Resolution 8.3 mega pixels (3840*2160) 2.9m 2.9m Pixel Size 11.2mm 6.3mm Image Area... -
Page 5: Sony Imx585 Sensitivity
2.3 12bit ADC and ROI ATR585C has built in 12bit ADC. It also has 12bit output mode for hardware binning and smaller resolution. The camera also supports hardware ROI, and the smaller the ROI size is, the higher the frame rate is. -
Page 6: Zero Amp-Glow
2.8 Zero Amp-Glow ATR585C has been carefully designed and is able to achieve zero amp-glow photo shooting. Figure and Figure show the different cameras at 20C and 5-minute exposure time with and without amp-glow. By comparison, the image captured by ATR585C shows zero amp-glow. - Page 7 ATR585C(ATR3CMOS08300KPA) User Manual Gain Value Value) for the description For the ATR series camera, the is in xxx% mode. Here xxx is used as the x axis (Gain of the camera performance ������ ��������(����) = 20 ∗ ������ [������(�������� ����������)/100] (������...
- Page 8 Camera setting used for HCG performance analysis is shown below: ⚫ Full resolution ⚫ RAW 12-bit mode ⚫ Temperature: -10C Figure shows the curves of the camera analysis data in Table 3 Figure 5 e/ADU, Read Noise, Full Well and Dynamic Range for ATR585C...
- Page 9 ATR585C(ATR3CMOS08300KPA) User Manual The camera analysis data is shown in Table 3: Table 3 Camera Analysis Data Sensor Analysis Data Gain Value 1000 1778 3162 5623 10000 15000 Rel Gain (dB) 5.12 10.23 20.09 25.22 29.91 34.96 39.95 43.07 e-/ADU 1.01...
- Page 10 Camera setting used for LCG performance analysis is shown below: ⚫ Full resolution ⚫ RAW 12-bit mode ⚫ Temperature: -10C Figure 6 shows the curves of the camera analysis data in Table 4 Figure 6 e/ADU, Read Noise, Full Well and Dynamic Range for ATR585C...
- Page 11 ATR585C(ATR3CMOS08300KPA) User Manual The camera analysis data is shown in Table 4: Table 4 Camera Analysis Data Sensor Analysis Data Gain Value 1000 3162 5623 10000 15000 1778 Rel Gain (dB) 4.82 9.95 14.78 19.87 24.96 34.87 39.96 43.53 0.00 29.81...
- Page 12 ATR585C(ATR3CMOS08300KPA) User Manual Camera setting used for HDR performance analysis is shown below: ⚫ Full resolution ⚫ RAW 16-bit mode ⚫ Temperature: -10C Figure shows the curves of the camera analysis data in...
- Page 13 ATR585C(ATR3CMOS08300KPA) User Manual The camera analysis data is shown in Table 5: Table 5 Figure 7 e/ADU, Read Noise, Full Well and Dynamic Range for ATR585C...
- Page 14 ATR585C(ATR3CMOS08300KPA) User Manual The camera analysis data is shown in Table 5: Table 5 Camera Analysis Data Sensor Analysis Data Gain Value 1000 1778 3162 5623 10000 15000 Rel Gain (dB) 4.74 9.87 14.63 19.69 24.79 29.58 34.67 39.71 43.15 e-/ADU 0.12...
-
Page 15: Product Package And Connections
ATR585C(ATR3CMOS08300KPA) User Manual 3 Product Package and Connections 3.1 Packing List Figure 8 Packing Information of ATR585C Table 6 ATR585C Packing List Standard Package Carton L:50cm W:30cm H:30cm (20pcs, 12~17Kg/ carton, 0.045m3), not shown in the photo 3-A safety equipment case: L:28cm W:23cm H:15cm (1pcs, 3.9Kg/ box); carton size: L:28.2cm W:16.7cm H:25.5cm (TBD), not shown in the photo ATR series camera (M42x0.75 Mount+2”... -
Page 16: Camera Dimension And Its Mount
ATR585C(ATR3CMOS08300KPA) User Manual 3.2 Camera Dimension and Its Mount Figure 9 Dimension and Mount of ATR585C Table 6 Dimension and Mount of ATR585C Item Specification 80mm Diameter Height 107.1mm Mount M42Fx0.75mm... -
Page 17: Camera Outline And Interface
The female flange to the sensor is 17.5mm. ATR585C comes with M42x0.75 mount and can connect to telescope with the M42x0.75 thread in a direct way. ATR585C can also connect to the telescope who use 1.25” or 2” eyepieces by M42M-1.25”... -
Page 18: Camera Mechanical Connection With Lens
ATR585C(ATR3CMOS08300KPA) User Manual or M42M-2” adapter. Figure shows the connection of the camera and the adapter. After the adapter is screwed to the camera, the camera can insert into the telescope’s eyepiece tube. Table 8 list the details of the camera and adapter parameters. -
Page 19: Camera Electric Connection With Accessories
3.6 Camera Electric Connection with Accessories On the back side of ATR585C, there are 3 connection ports: DC 12V/3A power port, USB3.0/ USB2.0 port and USB-HUB. Due to the significantly larger power cunsumption of IMX585, ATR585C (including the cooling system) is now booted up only by 12V/3A power supply. - Page 20 ATR585C(ATR3CMOS08300KPA) User Manual Figure 4 Camera Electric Connection Table 10 Camera Electric Connection Details Item Specification USB3.0/USb2.0 Port To computer with USB3.0/USB2.0 cable To filter wheel with USB2.0 cable USB HUB for Accessories To guiding camera with USB 2.0 cable...
-
Page 21: Atr585C And Its Software
4 ATR585C and Its Software 4.1 Application Installation For software, customers are welcomed to go to our software website: https://touptek-astro.com/downloads/, to download the latest ToupSky. The ATR can also be used with ASCOM, DirectShow SDK. If the third-party software is compatible with these SDK, customers can also download the software driver from our website and install the drivers into the third-party software. -
Page 22: Professional Camera Control Panel
ATR585C(ATR3CMOS08300KPA) User Manual Figure 5 ToupSky and Its Video Window Figure 6 ToupSky and Its Browse Window 4.1.2 Professional Camera Control Panel Capture & Resolution Set the live and snap resolution and snap the image or record video; Exposure & Gain... -
Page 23: Practical Functions With Good Results
ATR585C(ATR3CMOS08300KPA) User Manual Color Balance Advanced single-click intelligent white balance setting, temperature and tint can be manually adjusted; Color Adjustment Hue, saturation, brightness, contrast, gamma initialization adjustment; Frame Rate Adjustment of frame rate available for different computer configurations; Flip Check the “horizontal” or “vertical” option to correct the sample direction;... -
Page 24: Atr585C And Dshow
4.2 ATR585C and Dshow ToupTekDshowAstroSetup (Click the left blue link to download) DshowAstro is an interface driver providing Dshow standard support for ToupTek USB astronomy camera Supported OS: Windows: ⚫ x86: XP SP3 or above; CPU supports SSE2 instruction set or above ⚫... -
Page 25: Maximdl
ATR585C(ATR3CMOS08300KPA) User Manual 4.3.8 MAXIMDL Famous full functional CCD Control/Image Process software. Popular used in US. 4.3.9 AstroArt Famous full functional CCD Control/Image Process software. Popular used in Europe. 4.3.10 FireCapture Great free planetary capture software. Support part of AstroCam series telescope camera. -
Page 26: Service
ATR585C(ATR3CMOS08300KPA) User Manual 5 Service For software upgrades, please refer to “Download” on our official website: https://touptek-astro.com// For customers who purchase the cameras from local dealer, please contact your dealer for more inquiry. For technical support, please contact e-mail address: astro@touptek.com.
