PART NAMES
INDOOR UNIT
OUTDOOR UNIT
1 1 Inlet (Air)
2
2 Open Panel
3
3 Air Filter
4 AUX Button
5 Receiver Window
4
6 Power Supply Cord
7 Vertical Adjustment Louvre
8 Horizontal Adjustment Louvre
5
9 Outlet (Air)
6 0 Remote Control
7
8
9
0
q PLASMACLUSTER Lamp (blue)
q
w OPERATION Lamp (red
e TIMER Lamp (orange
w
r POWERFUL JET Lamp (green
e
t AIR FILTER SIGN Lamp (red
r
t
y y Inlet (Air)
u Refrigerant Tube and Interconnecting
u
Cord
i Drainage Hose
i
o Outlet (Air)
o
NOTE:
Actual units might vary slightly from
those shown above.
E-2
)
)
)
)
