- Page 1 OWNER'S MANUAL Color Video Camera Please read this manual carefully before operating your set and retain it for future reference. MODEL L322-BN L322-BP L322 Series P/NO : MFL67260110...
- Page 2 FCC WARNING: This equipment may generate or use radio CAUTION frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction RISK OF ELECTRIC SHOCK manual. The user could lose the authority to operate this DO NOT OPEN equipment if an unauthorized change or modification is made.
- Page 3 Caution: This installation should be made by a qualified • Caution: Danger of explosion if battery is incorrectly replaced. Replaced only with the same or equivalent service person and should conform to all local codes. type recommended by the manufacturer. Dispose Caution: To avoid electrical shock, do not open the of used batteries according to the manufacturer’s cabinet.
- Page 4 LG Electronics hereby declares that this/ Disposal of your old appliance these product(s) is/are in compliance with the essential requirements and other rel- When this crossed-out wheeled bin evant provisions of Directive 2004/108/EC, symbol is attached to a product it means 2006/95/EC, and 2009/125/EC.
-
Page 5: Important Safety Instructions
Important Safety Instructions Read these instructions. and the point where they exit from the apparatus. Keep these instructions. 11. Only use attachments/accessories specified by the manufacturer. Heed all warnings. 12. Use only with the cart, stand, tripod, bracket, or table Follow all instructions. -
Page 6: Cautions For Safe Operation
Cautions for Safe Operation Power Supply Operating and storage location This camera must always be operated by AC 24 V or Avoid viewing a very bright object (such as light fittings) DC 12 V Certified/Listed, class 2 power supply only. during an extended period. -
Page 7: Table Of Contents
Contents Features ..............8 OSD Menu Overview ...........21 General Operation ............25 Part Names and Functions ........9 Setting the USER TITLE ..........25 White Balance settings ..........29 Connections ............11 3D-DNR Setting .............30 Day/Night Setting ............31 Precautions ..............11 Privacy Setting ...............32 Connection Overview ..........11 Special Menu Settings..........33 Connecting Display device........12... -
Page 8: Features
Features This Color Video Camera is designed for installation in an video surveillance system. This manual contains instructions on how to install and manage the Color Video Camera in your video surveillance system. Should you require any technical assistance, please contact authorized service center. -
Page 9: Part Names And Functions
Part Names and Functions c Flange-back adjustment lever b c d d Lens iris output connector (LENS) This 4- pin connector is used to send the Iris control signal and power supply to an auto-iris type lens. e Setup menu control buttons Use these buttons to set the menu options. -
Page 10: Power Input Terminal
Part Names and Functions f Power input terminal Supplies AC 24 V or DC 12 V from an external power source. g External Device Connectors • D&N Connect the external switch to set the D&N function manually. • ALARM (Alarm Output Terminal) Connect to the alarm input of an external device. -
Page 11: Connections
Connections Precautions • Be sure to switch off the unit before installation and connection. • A qualified service person, complying with all applicable codes, should perform all required hardware installation. • Do not expose the power and connection cable to moisture, which may cause damage to the unit. Connection Overview RS-485 Unit External D&N... -
Page 12: Connecting Display Device
Connections Connecting Display device Connecting Power Source The video signal connection between the camera and the Connect power, using the method listed below: monitor. Remove the insulation on the power cable as illustrated. (a) Attach the terminal tips. (b) Connect to the DC 12 V / AC 24 V UL Listed, Class 2 Power Supply only on the unit. -
Page 13: Connecting Rs-485 Device
Connections Connecting RS-485 Device Connecting Alarm Device Use these ports to connect an external device of RS-485 Alarm terminals are used to connect the alarm (relay) format. devices such as sensors, door switches, etc. Connect the alarm (relay) device to the alarm (relay) output terminal. -
Page 14: Contact Ratings
Connections Connecting Day&Night Switch Contact Ratings Connect the external D&N switch to the D&N terminal. • Maximum load current is ±130 mA. • Do not connect any system or device that has Equivalent over 40 Vp-p bias voltage Diagram on the contact terminal. Note: Use a relay unit if the voltage or current of the connected device exceeds the ratings. -
Page 15: Night Function
Connections Day function Note: If you use the external D&N function, you should set When you open the external switch, the D&N function the DAY/NIGHT option to EXT on the setup menu. is set to Day mod. Mounting the Lens Remove the lens mount cap from the camera. - Page 16 Connections 2-2. C mount type lens In such a case, remove the original plug and using a soldering iron, connect a lens iris plug according to To allow for flange- back adjustment, install the the diagram. (Refer to next page.) C-mount adaptor (option) on the lens mount, then carefully align the lens mount with the camera opening and turn the lens slowly to...
- Page 17 Connections Rewire the lens iris plug Cut off the plug of the lens cable, cut off approximately 8 mm of the insulation, and then strip approximately 2 mm of the ends of the cable sheaths. Solder the ends of the cable wires to the ends of the pins, and then attach the cover of the lens iris plug.
-
Page 18: Flange-Back Adjustment
Connections Flange-back Adjustment The adjustment is required only when a lens without focus-adjusting mechanism is mounted, or when a lens with adjusting mechanism is mounted and focus that is more accurate is needed. Loosen the flange-back fixing lever. Up and down the flange-back adjusting lever to obtain a focused point while watching the monitor screen. -
Page 19: Mounting The Camera
Connections Mounting the camera The mounting bracket can be secured on either the top or bottom of the camera. Use the same set of screws to attach the mounting bracket on the camera. Note: If using a camera mounting bracket, select a location that is strong enough to bear the full weight of the camera and the mounting bracket for long periods, and install the camera and mounting bracket securely. -
Page 20: Menu Operation
Menu Operation OSD Menu control buttons BUTTON Description This camera utilizes an on-screen user MENU. To set items Used to move upper direction on the on the menu, use the following buttons. menu screen. Use this button to select an item or adjust the parameters. UP button Used to move lower direction on the menu screen. -
Page 21: Osd Menu Overview
Menu Operation OSD Menu Overview The following table shows the list of menu items and options. You can adapt the camera to your requirements by setting up the respective items in these menus. Main Menu Sub Menu Contents USER TITLE WDR/BLC OFF/WDR/BLC/HSBLC BRIGHTNESS... - Page 22 Menu Operation Main Menu Sub Menu Contents STANDARD COOL USER MODE WARM VIVID WHTIE BAL AWC / PUSH COLR TEMP INDOOR, OUTDOOR MANUAL -100 to 100 BLUE -100 to 100 3D-DNR MIDDLE HIGH LEVEL LOW/MIDDLE/HIGH AUTO DWELL TIME 5, 10, 15, 30, 60 SEC DAY/NIGHT NIGHT...
- Page 23 Menu Operation Main Menu Sub Menu Contents MASK NUMBER AREA 1 to AREA 8 DISPLAY SET ON/OFF COLOR SET GRAY/WHITE/BLACK PRIVACY HEIGHT 4 to 100 WIDTH 4 to 100 MOVE Y 2 to 98 MOVE X 2 to 98 LANGUAGE ENG/CHN/KOR/JAP/FRE/ITA/SPA/POR/DUT/GER/POL/RUS/TUR/ARA/HEB COLOR EFFECT OFF/ON...
- Page 24 16 to 100 MOVE Y 6 to 94 MOVE X 8 to 92 SPECIAL SENSITIVITY 0 to 100 FACTORY RESET CAMERA ID OFF, 1 to 255 PROTOCOL LG/PELCO-D/PELCO-P RESET COMMUNICATION BAUD RATE 2400 bps/ 4800 bps/ 9600 bps SAVE & REBOOT EXIT...
-
Page 25: General Operation
Menu Operation General Operation • RETURN: Return to the previous. Setting the USER TITLE Press [SET] button. The setup menu screen appears on the monitor. You can use the camera identification to assign a number and character to the camera. The USER TITLE is displayed on the upper left of the screen. -
Page 26: Wdr/Blc Setting
Menu Operation WDR/BLC setting • POS: Move the USER TITLE position on the screen using the arrow buttons. Use WDR/BLC option to view the object clearly in backlight • END: Confirm your selection or exit the setting conditions. • A (Blank): Inserts a space at the cursor position. •... -
Page 27: Brightness Setting
Menu Operation Brightness setting • BLC: Camera's backlight compensation feature helps alleviate issues of visibility in high contrast You can increase the brightness of the darkened video. If areas. Set the BLC limit. you set the brightness to lower value, the image is •... -
Page 28: Agc (Automatic Gain Control) Setting
Menu Operation AGC (Automatic Gain Control) setting SHUTTER (Shutter Speed) setting If the images are too dark, change the maximum [AGC] Select the desired shutter speed for camera exposure. You value to make the images brighter. can change the shutter speed to higher speed to capture fast-moving subjects, though the image becomes darker. -
Page 29: White Balance Settings
Menu Operation SENS-UP setting Note: If you set to one of the SHUTTER options except AUTO on If pictures are not clear due to darkness, this SENS-UP the [SHUTTER] menu the [SENS-UP] setting is not available operation would increase the sensitivity of picture. and [---] mark is displayed. -
Page 30: 3D-Dnr Setting
Menu Operation 3D-DNR Setting You can select the USER MODE. • AWC/PUSH: If you select the AWC/PUSH mode, you will be able to set up the White Balance automatically using [SET] button. • MANUAL: You can set the white balance options manually. -
Page 31: Day/Night Setting
Menu Operation Day/Night Setting > DWELL TIME: Use [LEFT] or [RIGHT] button to select a dwell time. • EXT : Switches between color picture and black- and-white picture when an external day/night switching signal is received. • DAY: Color mode enabled. •... -
Page 32: Privacy Setting
Menu Operation Privacy Setting Use [LEFT] or [RIGHT] button to set up the GRAY, WHITE and BLACK on the COLOR SET option. This function is aiming at the protection of personal Use [UP] or [DOWN] button to select an option then privacy, selecting a screen part black not to be displayed in use [LEFT] or [RIGHT] button to adjust the option. -
Page 33: Special Menu Settings
Menu Operation Special Menu Settings LANGUAGE Setting Select the viewer language for the camera setup menu and This menu lets you adjust and set up LANGUAGE, COLOR OSD information display. EFFECT, SHARPNESS, STABILIZER, D-ZOOM, D-EFFECT, MOTION DET, FACTORY RESET, COMMUNICATION function by yourself in the SPECIAL menu. - Page 34 Menu Operation Setting the COLOR Setting the SHARPNESS effect You can switch the displayed picture to gray scale or color. The degree to which the boundary of the two portions is Select [COLOR] option on the [SPECIAL] menu. clearly distinguished. Use [LEFT] or [RIGHT] button to change a color.
-
Page 35: Setting The D-Zoom (Digital Zoom) Level
Menu Operation STABILIZER setting Setting the D-ZOOM (Digital Zoom) level The image stabilizer function minimizes the appearance of You can select the digital zoom level. shaky images caused by low-frequency vibration. This function is useful for outdoor surveillance. Select [STABILIZER] option and set to ON or OFF. Select [D-ZOOM] option on the [SPECIAL] menu. - Page 36 Menu Operation Setting the D-EFFECT (Digital effect) • TILT: Use [LEFT] or [RIGHT] button to move the screen. (up or down) You can select the digital effect. Select [D-EFFECT] option on the [SPECIAL] menu. Use [LEFT] or [RIGHT] button to select a digital effect. •...
-
Page 37: Motion Detection Setting
Menu Operation Motion Detection Setting Use [UP] or [DOWN] to select an option then use [LEFT] or [RIGHT] button to adjust the option. The motion detection detects the moving objects in the • HEIGHT: Enlarge or decrease the vertical size of scene by monitoring changes in brightness level. -
Page 38: Reset Setting
Menu Operation Reset Setting BAUD RATE: Set the speed of communication between the camera and the RS-485 unit. SAVE & REBOOT: To confirm the communication settings. Press [SET] button to confirm your selection. Select [RESET] option. Press [SET] button and the RESET menu appears. Use [UP] or [DOWN] to select option. -
Page 39: Reference
Reference RS-485 Protocol ex) In case of transmission, 0xC5, 0x5F, 0x02, 0x00, 0x0A” Data Communication Format C.S. = 0xC5 +0x5F +0x02 +0x00 +0x0A = 0x0130 • Data Length: 1 Byte (8 Bit) therefore, C.S. = 0x30 • Start/Stop Bit: 1 Bit Commands •... -
Page 40: Specification
Reference Specification ITEM L322-BN L322-BP Signal System NTSC Total Pixels No./ Effective Pixels No. 410 000 / 380 000 Pixels 470 000 / 440 000 Pixels Image Device 6 mm CCD XDI-S2 Lens CS Mount (C Mount using adaptor ring) Digital Zoom IRIS Control DC / ELC... - Page 41 Reference ITEM L322-BN L322-BP 3D-DNR (OFF / LOW / MIDDLE / HIGH) Auto Gain Control OFF / LOW / MIDDLE / HIGH Electronic Shutter Speed 1/60 to 1/100 000 1/50 to 1/100 000 Electronic Sensitivity OFF / AUTO (X2, X3, X4, ..., X128) ATW / AWC / PUSH / MANUAL White Balance Motion detection...
