Poly Edge E Series Quick Start Manual

Smart Office
Poly Edge E Series Phones
Quick start guide
Welcome to your Smart Office quick start guide for Poly
Edge phones!
Before you use the phone, familiarize yourself with its features
and user interface.
Hardware overview
Basic front hardware features
This table lists each numbered feature shown in the figure on the right.
Feature
1
Led bar
2
Line keys
3
Softkeys
4
Pagination key
5
Back key
Navigation keys /
6
Select key
7 Home key
8
Hold key
Forward/transfer
9
key
10 Volume keys
11 Messages key
12
Headset key
13
Speakerphone key
14
Mute key
15
Dialpad
Feature description
Provides call and phone status information.
Select a phone line, view calls on a line, or quickly
call a favorite contact.
Select context-sensitive keys that display along the
bottom of the screen.
View additional line screens.
Return to the previous screen.
Scroll through information or options displayed on
the phone's screen or select a field of displayed
data.
Display the home screen from other screens or
display the lines and calls screen from the home
screen.
Hold an active call or resume a held call.
Forward or transfer an active call to a selected
contact.
Adjust the volume of the handset, headset,
speaker, and ringer.
Access and manage instant and voice messages.
Place and receive calls through a headset.
Provides ringer and speakerphone audio output.
Mute or unmute the microphone during an active
call.
Enter numbers, letters, and special characters. Use
the dial pad keys to select menu items that have
index numbers
Surround LED lighting bar
The surround LED lighting bar indicates various phone states.
State
Incoming call
Active call
Held call, available voicemail
Bluetooth discovery in progress
Off-hours or sleep mode
1
Led lighting bar status
Breathing green
Solid green
Breathing red
Chasing blue
Breathing yellow
