Bake=n-Warm
TM
Double Oven
Light Operation (some models):
The Bake-n-Warm
TM
Double Oven light operates with the
upper oven light and automatically turns ON when the upper
oven door is opened, if equipped, the Bake-n-Warm
TM
Double
Oven light may also be manually operated by pressing the
pad.
To Remove the Bake-n-Warm
TM
Double Oven
Drawer &
Replace
the Oven
Light:
t. Beforedrawerremoval, besureto
turn OFF the Bake-n-Warm
TM
Double Oven and let the drawer area
cool completely.
2. Pull the drawer away from the oven.
Using a phillips-head screwdriver
remove the two d rawer screws from
the insides of the front oven drawer
compartment (See Fig. t ).
3. With one hand hold the drawer front
in place. Use your other hand to pull
the glide away from the oven (See
Fig. 2) until the glide hook
disengages (See Fig. 3).
4. Repeat from step 3 above for the
other side of the drawer.
5. With BOTH glide hooks disengaged, Fig. 1
carefully lift the drawer up and away
from the oven. Push both drawer
glides into lower oven cavity.
6. Replace the lower oven light with a
40 Watt Appliance light bulb (Refer
to Fig.5).
Glide Hook Disengaged
Fig. 3
Be sure the range is
unplugged and all parts are COOL before
replacing oven light. Weara leather-
faced glove for protection against
possible broken glass. Use CAUTION
when reaching across the oven element
and brackets. These parts may be sharp
and cause cuts.
Fig. 5
Fig. 2
Glide Hook Engaged
Fig. 4
To
replace
Bake-n=Warm
TM
Double Oven Drawer:
t. Pull both drawer glides and fully extend outward from lower oven cavity.
2. Carefully rest the drawer on top of both glides.
3. Adjust the drawer position on top of the rails until both of the drawer side slots are correctly engaged with the glide
hooks (See Fig. 4).
4. Pull the drawer forward to line up the drawer with both screw holes in the glides. Using a phillips-head screwdriver
replace the two screws removed from the inner drawer sides.
5. Replace drawer rack if removed.
6. CIoselowerovendrawer.
