6097947W /6097952WCOM
MS Glass Door TV Stand
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves .
B346097XXXW00GO
Scan for Animated
Assembly Instructions
Easy
Assembly Difficulty Meter
People Needed for Assembly: 2
Follow Ameriwood Home
You
Tube
Tough

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6097947W and is the answer not in the manual?

Questions and answers

Related Manuals for Mainstays 6097947W

Summary of Contents for Mainstays 6097947W

  • Page 1 6097947W /6097952WCOM MS Glass Door TV Stand B346097XXXW00GO Date of Purchase ___ / ___ / ___ Lot Number: Scan for Animated Assembly Instructions THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Do Not Return This Product! Contact our customer service team for help first.

  • Page 2: Helpful Hints

    Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Call us! 1-800-489-3351 Visit ameriwoodhome.com Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 2 - Open your item in the area you plan to keep it to avoid excessive heavy lifting. - Identify, sort and count the parts before attempting assembly.

  • Page 3: Before You Start

    Before You Start Read through each step carefully and follow the proper order. Separate and count all your parts and hardware. Give yourself enough room for the assembly process. Have the following tools: #2 Phillips Head Screwdriver and Hammer. Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.
  • Page 4 Before You Start Please Note: You may need to lightly tap the wood dowels with a hammer into the holes during your assembly process. Wood Dowel Insertion: Insert wood dowel completely into the hole. Not Actual Size Wood dowel will extend out approximately 3/8".

  • Page 5: Board Identification

    Board Identification Not Actual Size PARTITION PANEL TOP PANEL LEFT SIDE FRAME RIGHT SIDE FRAME 1 PC 1 PC 1 PC 1 PC BOTTOM PANEL BACK PANEL FRONT RAIL ADJ SHELF 1 PC 1 PC 1 PC 2 PCS For any replacement part, see page 7.
  • Page 6 Board Identification Not Actual Size ameriwoodhome.com Tube...

  • Page 7: Part Number Reference

    Each part has a unique part number. Please refer to the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above. 6097947W 6097952WCOM LABEL PART NAME...
  • Page 8 Part List Actual Size For any replacement (x17) (x22) hardware, see page 9. Cam Bolt Wood Dowel Ø6x25 mm Ø8x30 mm (x4) (x4) (x24) Bolt Screw Screw 5/32"x25mm Ø4x38 mm Ø3.5x14 mm Not Actual Size (x4) (x8) (x2) (x17) Cam Lock Shelf Support Bumper Card Hinge...
  • Page 9 Each part has a unique part number. Please refer to the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above. 6097947W 6097952WCOM MODEL# (Spring Pine)
  • Page 10 STEP Dowels extend out 3/8". For more details, please see page 4 (x8) (x3) Attach three Cam Bolts (1) into the Front Rail (F) as illustrated. Do NOT over-tighten. Insert two Wood Dowels (2) into the Front Rail (F) and Insert six Wood Dowels (2) into the Bottom Panel (E) as illustrated.
  • Page 11 STEP Arrow to point towards end hole in edge of part (x3) End hole Attach Front Rail (F) to Bottom Panel (E) and insert three Cam Locks (6) as illustrated. Turn Cam Locks (6) clockwise to lock panels in place. Unfinished Edge Unfinished Edge The hole for...
  • Page 12 STEP Dowels extend out 3/8". For more details, please see page 4 (x2) (x2) Insert two Wood Dowel (2) into the bottom of Partition Panel (D) as illustrated. Attach the Bottom Panel (E) to the Partition Panel (D) using two Screws (3) as illustrated. Finished Edge Unfinished Edge Finished Edge...
  • Page 13 STEP Dowels extend out 3/8". For more details, please see page 4 (x6) Insert six Wood Dowels (2) into the Back Panel (H) as illustrated. Unfinished Edge Warning Label facing upward Unfinished Edge ameriwoodhome.com Tube...
  • Page 14 STEP (x2) Attach the Back Panel (H) to the Bottom Panel (E) using two Screws (3) as illustrated. Unfinished Edge Finished Edge Warning Label facing upward Edge with Wood Dowels The hole for Cam Lock faces outward when setup in this orientation ameriwoodhome.com Tube...
  • Page 15 STEP (x6) Attach three Cam Bolts (1) into the Left Side Frame (B) and three Cam Bolts (1) into the Right Side Frame (C) as illustrated. Do NOT over-tighten. Unfinished Edge ameriwoodhome.com Tube...
  • Page 16 STEP Arrow to point towards end hole in edge of part (x3) End hole Attach boards (E), (F) and (H) to the Left Side Frame (B) and insert three Cam Locks (6) as illustrated. Turn Cam Locks (6) clockwise to lock panels in place. Unfinished Edge Pro Tip: If you are having trouble connecting your Cam Bolts and Cam Locks, check to make sure your Cam Locks are in the open position with the arrow pointing toward the Left Side Frame (B).
  • Page 17 STEP Arrow to point towards end hole in edge of part (x3) End hole Attach boards (E), (F) and (H) to the Right Side Frame (C) and insert three Cam Locks (6) as illustrated. Turn Cam Locks (6) clockwise to lock panels in place. Unfinished Edge Pro Tip: If you are having trouble connecting your Cam Bolts and Cam Locks, check to make sure your Cam Locks are in the open position with the arrow pointing toward the Right Side Frame (C).
  • Page 18 STEP Attach Middle Leg (I) to the Bottom Panel (E) as illustrated. Do NOT over-tighten. The warning faces upward when setup in this orientation ameriwoodhome.com Tube...
  • Page 19 STEP Dowels extend out 3/8". For more details, please see (x6) page 4 With the assistance of a second person, carefully turn the unit upright. Insert six Wood Dowels (2) into boards (B), (C), and (D) as illustrated. ameriwoodhome.com Tube...
  • Page 20 STEP (x8) Attach 8 Cam Bolts (1) into the Top Panel (A) as illustrated. Do NOT over-tighten. Back ameriwoodhome.com Tube...
  • Page 21 STEP Arrow to point towards end hole in edge of part (x6) End hole Attach the Top Panel (A) to boards (B), (C) and (D) as illustrated. Insert six Cam Locks (6) to board (B), (C) and (D). Turn Cam Locks (6) clockwise to lock panels in place. Back Pro Tip: If you are having trouble connecting your Cam Bolts and Cam Locks, check to make sure your Cam Locks are in the open position with the arrow pointing up.
  • Page 22 STEP Arrow to point towards end hole in edge of part (x2) End hole Attach the Top Panel (A) to Back Panel (H) and insert two Cam Locks (6) to board (H) as illustrated. Turn Cam Locks (6) clockwise to lock panels in place. Pro Tip: If you are having trouble connecting your Cam Bolts and Cam Locks, check to make sure your Cam Locks are in the open position with the arrow pointing up.
  • Page 23 STEP (x8) Insert 8 Shelf Supports (7) into the TV Stand at the desired shelf heights. Put the Adj Shelf (G) onto the Shelf Support (7) as illustrated. Finished Edge ameriwoodhome.com Tube...
  • Page 24 STEP (x8) (x2) (x4) (x4) Attach two Hinges (9) to the Door (J) with four Screws (4) as illustrated. Repeat this step for 2nd door. Attach the Handle (10) to the Door (J) with two Bolts (5) as illustrated. Repeat this step for 2nd door.
  • Page 25 STEP (x8) Attach the Door (J) to the Left Side Frame (B) with 8 Screws (4) as illustrated. ameriwoodhome.com Tube...
  • Page 26 STEP (x2) (x8) Attach the Door (J) to the Right Side Frame (C) with 8 Screws (4) as illustrated. Stick two Bumper Cards (8) onto the edge of the Partition Panel (D) as illustrated. ameriwoodhome.com Tube...
  • Page 27 STEP To adjust the vertical height. Loosen the four screws "A" on both hinges. Two of them are in slotted holes which allows you to adjust up or down by a few mm and then tighten back up. Para ajustar la altura vertical Afloje los cuatro tornillos "A"...

  • Page 28: Warning Label

    STEP WARNING ADVERTENCIA AVERTISSEMENT Apply Warning Label (11) to the center of Top Panel (A) as shown, ensuring that the TV covers the label. Please note that the label is permanent. Once affixed to your item, it will not come off and will damage the surface if removal is attempted.
  • Page 29 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. WARNING ADVERTENCIA AVERTISSEMENT WARNING LABEL (11) Certificate of Conformity 1. This certificate applies to the Dorel Home Furnishings, Inc. product identified by this instruction manual. 2.
  • Page 30 Register your product to receive the following: * New trend details - sneak peek on what's new * Surveys - have a voice within our community * Quick and easy replacement part service To register your product, visit ameriwoodhome.com Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You"...
  • Page 31 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
  • Page 32 Español Identificación de los Paneles (Página 5-6) Lista de Piezas (Página 8) Tamaño real Este no es el tamaño real Este no es el tamaño real Bloqueo de leva Perno de leva PANEL SUPERIOR Taco de madera Soporte de estante MARCO LATERAL IZQUIERDO Tornillo Tarjeta de parachoques...
  • Page 33 Español Página 17 Conecte las tablas (E), (F) y (H) al marco del lado derecho (C) e inserte tres cerraduras de leva (6) como se ilustra. Gire las trabas de leva (6) en el sentido de las agujas del reloj para bloquear los paneles en su lugar.
  • Page 34 Español Página 27 Ajuste de la bisagra de la puerta. Página 28 Aplique la etiqueta de advertencia (11) al centro del panel superior (A) como se muestra, asegurándose de que el televisor cubra la etiqueta. Tenga en cuenta que la etiqueta es permanente. Una vez fijado a su artículo, no se desprenderá...
  • Page 35 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: 1-800-489-3351 (sans frais) Visitez: www.ameriwoodhome.com ATTENTION...
  • Page 36 Français Liste des pièces (Page 8) Identification des matériaux (Page 5-6) Taille réelle Pas de taille réelle Pas de taille réelle (A) PANNEAU DU HAUT Verrouillage à came Boulon à came Support d'étagère Cheville en bois (B) CADRE CÔTÉ GAUCHE Carte pare-chocs (C) CADRE CÔTÉ...
  • Page 37 Français Page 17 Fixez les planches (E), (F) et (H) au cadre latéral droit (C) et insérez trois verrous à came (6) comme illustré. Tournez les verrous à came (6) dans le sens des aiguilles d'une montre pour verrouiller les panneaux en place.
  • Page 38 Français Page 27 Réglage charnière de porte. Page 28 Appliquez l'étiquette d'avertissement (11) au centre du panneau supérieur (A), comme illustré, en vous assurant que le téléviseur recouvre l'étiquette. Veuillez noter que l'étiquette est permanente. Une fois apposé sur votre article, il ne se détachera pas et endommagera la surface si l'on tente de le retirer. AVERTISSEMENT : Risque de mort ou de blessures graves.
