18-23
Frontier Series Front Bumper
Before installation -
Read and understand all instructions,
warnings, cautions, and notes contained in this installation
instruction guide. Consult your vehicle owner's manual for proper
disconnection of electrical and li ting of vehicle if required for
installation of this product.
This install may require some technical skills and knowledge of basic
mechanical work. If you do not feel that you are capable of performing
this install please take this product to a trained professional.
A ter reading this guide please contact us with any questions or
concerns before installing product.
Customer Service: (626) 369-2121
ATTICA4X4 is not responsible for any bodily injury or harm to you or
your vehicle as a result of an improper install.
tech@attica4x4.com
Jeep Wrangler JL
ATTJL01A110-BX
Proper installation of this kit requires knowledge of the factory
recommended procedures for removal and installation of original
equipment components. We recommend that the factory shop manual
and any special tools needed to service your vehicle be on hand
during the installation. Installation of this kit without proper
knowledge of the factory recommended procedures may a ect the
performance of these components and the safety of the vehicle.
Inspect all contents of this package to make sure product is not damaged and all
installation hardware has been included. If parts are missing from kit, please be
prepared to provide the following information:
•
•
Always wear eye protection when operating power tools.
Name of purchase location
•
Date above Bar Code
Bar Code on side of box
•
Date insde box cover
(626) 369-2121
Advertisement
Related Manuals for attica Frontier ATTJL01A110-BX
Summary of Contents for attica Frontier ATTJL01A110-BX
- Page 1 18-23 Jeep Wrangler JL Frontier Series Front Bumper ATTJL01A110-BX Before installation - Proper installation of this kit requires knowledge of the factory Read and understand all instructions, recommended procedures for removal and installation of original warnings, cautions, and notes contained in this installation equipment components.
-
Page 2: Tools Required
tools required • 13mm socket • 16mm socket • 4mm hex tool hardw are kit W19 | Washer W22 | washer W21 | PLASTIC retainer W23 | Washer W16 | washer b46 | hex head bolt W39 | Washer b34 | hex head bolt winch plate spacer N15 | Hex Flange Nut b35 | hex head bolt... - Page 3 Begin by unpacking all items and inspecting them for damage or missing items. Any concerns, please contact the company you purchased the bumper from. A ter inspection, remove your factory bumper & winch. 13942 VALLEY BLVD, CITY OF INDUSTRY, CA 91746 TECH@ATTICA4X4.COM 626-369-2121 WWW.ATTICA4X4.COM...
- Page 4 First step is to mount the bull bar to the bumper. The bull bar mounts to the bumper using B20 bolts, W16 and W19 washers and N22 nuts securing with 4mm hex tool & 13mm socket tool. Insert B34 bolts and W21 plastic retainers onto the bumper as shown on the le t.
- Page 5 To install the winch plate, use W22, W23, and W39 washers, winch plate spacers, and B25 bolts, securing them with a 16mm socket tool. The winch plate spacer goes on the side, and the W39 washer goes in the front. 13942 VALLEY BLVD, CITY OF INDUSTRY, CA 91746 TECH@ATTICA4X4.COM 626-369-2121...
- Page 6 Attaching the front bumper onto your vehicle using W22,and W23 washers, and N25 nuts, securing them with a 16mm socket tool. Once finished your Attica Frontier Series Front Bumper will be completely installed and ready to take to the outdoors! 13942 VALLEY BLVD, CITY OF INDUSTRY, CA 91746 TECH@ATTICA4X4.COM...
- Page 7 if you have any questions, please email us at tech@attica4x4.com or call us at 626-369-2121 (626) 369-2121 tech@attica4x4.com...
