APEX SERIES STEAL TH FRONT BUMPER
Before installation -
Read and understand all instructions,
warnings, cautions, and notes contained in this installation
instruction guide. Consult your vehicle owner's manual for proper
disconnection of electrical and li ting of vehicle if required for
installation of this product.
This install may require some technical skills and knowledge of basic
mechanical work. If you do not feel that you are capable of performing
this install please take this product to a trained professional.
A ter reading this guide please contact us with any questions or
concerns before installing product.
Customer Service: (626) 369-2121
ATTICA4X4 is not responsible for any bodily injury or harm to you or
your vehicle as a result of an improper install.
tech@attica4x4.com
16-23
TOYOY A TACOMA
ATTA01A101-BX
Proper installation of this kit requires knowledge of the factory
recommended procedures for removal and installation of original
equipment components. We recommend that the factory shop manual
and any special tools needed to service your vehicle be on hand
during the installation. Installation of this kit without proper
knowledge of the factory recommended procedures may a ect the
performance of these components and the safety of the vehicle.
Always wear eye protection when operating power tools.
Inspect all contents of this package to make sure product is not damaged and all
installation hardware has been included. If parts are missing from kit, please be
prepared to provide the following information:
•
Name of purchase location
•
•
Bar Code on side of box
•
Date above Bar Code
Date insde box cover
(626) 369-2121
