Terra Series Side Steps
Before installation -
Read and understand all instructions,
warnings, cautions, and notes contained in this installation
instruction guide. Consult your vehicle owner's manual for proper
disconnection of electrical and li ting of vehicle if required for
installation of this product.
This install may require some technical skills and knowledge of basic
mechanical work. If you do not feel that you are capable of performing
this install please take this product to a trained professional.
A ter reading this guide please contact us with any questions or
concerns before installing product.
Customer Service: (626) 369-2121
ATTICA4X4 is not responsible for any bodily injury or harm to you or
your vehicle as a result of an improper install.
tech@attica4x4.com
18-23
Ford Bronco
ATTFB01C102-BX
Proper installation of this kit requires knowledge of the factory
recommended procedures for removal and installation of original
equipment components. We recommend that the factory shop manual
and any special tools needed to service your vehicle be on hand
during the installation. Installation of this kit without proper
knowledge of the factory recommended procedures may a ect the
performance of these components and the safety of the vehicle.
Always wear eye protection when operating power tools.
Inspect all contents of this package to make sure product is not damaged and all
installation hardware has been included. If parts are missing from kit, please be
prepared to provide the following information:
•
Name of purchase location
•
•
Bar Code on side of box
•
Date above Bar Code
Date insde box cover
(626) 369-2121
Advertisement
Related Manuals for attica ATTFB01C102-BX
Summary of Contents for attica ATTFB01C102-BX
- Page 1 18-23 Ford Bronco Terra Series Side Steps ATTFB01C102-BX Before installation - Proper installation of this kit requires knowledge of the factory Read and understand all instructions, recommended procedures for removal and installation of original warnings, cautions, and notes contained in this installation equipment components.
-
Page 2: Tools Required
tools required • 16mm socket • 18mm socket hardw are kit threaded plate W22 | washer x 17 x 12 W27 | Washer W25 | washer x 12 W23 | Washer SPARE PARTS HARDWARE KIT b35 | bolt N15 | Hex Flange Nut b37 | bolt N19 | Hex Flange Nut 13942 VALLEY BLVD, CITY OF INDUSTRY, CA 91746... - Page 3 Begin by unpacking all items and inspecting them for damage or missing items. Any concerns, please contact the company you purchased the side steps from. To prevent damaging your gas tank, use the supplied W25 lock washer with the thicker washer for the passenger’s side middle mounting point.
- Page 4 For the driver’s side front mounting point, use B58 bolt and W27 washer as shown to the top le t. Use the oversized washer with W25 lock washer and N19 nut as shown to the top right. For the bottom bolt, use B37 bolt, W25 lock washer and W27 washer with the threaded plate (Feed the threaded plate into the frame).
- Page 5 For the driver’s side middle mounting point, use B58 bolt and W27 washer as shown to the top le t. Use the W27 washer with W25 lock washer and N19 nut as shown to the top right. (Do not use the oversized washer for this mounting point.) 13942 VALLEY BLVD, CITY OF INDUSTRY, CA 91746 TECH@ATTICA4X4.COM 626-369-2121...
- Page 6 For the driver’s side rear mounting point, use B58 bolt and W27 washer as shown to the top le t. Use the oversized washer with W25 lock washer and N19 nut as shown to the top right. Attach the supporting bracket to the driver’s side rear mounting point, using B35 bolt, W22 lock washer and W23 washer, with the N15 nut.
- Page 7 For the passengers side front mounting point, use B58 bolt and W27 washer as shown to the top le t. Use the oversized washer with W25 lock washer and N19 nut as shown to the top right. For the bottom bolt, use B37 bolt, W25 lock washer and W27 washer with the threaded plate (Feed the threaded plate into the frame).
- Page 8 For the passenger’s side middle mounting point, use B58 bolt and the thick washer with W25 lock washer as shown to the top right. Use the oversized washer with W25 lock washer and N19 nut to mount to the frame. Take note of the distance between the bolt and gas tank, if more clearance is needed, W27 washer can be added.
- Page 9 B35 bolt, W22 lock washer and W23 washer, with the N15 nut. Once finished your Attica Terra Series Side Steps will be completely installed and ready to take to the outdoors! 13942 VALLEY BLVD, CITY OF INDUSTRY, CA 91746 TECH@ATTICA4X4.COM...
- Page 10 if you have any questions, please email us at tech@attica4x4.com or call us at 626-369-2121 (626) 369-2121 tech@attica4x4.com...
