Offroad Animal FB-RTX-DT-21-PR-ASM0 Fitting Instruction

Predator front bar for ram 1500 trx
Hide thumbs

Advertisement

Quick Links

Download this manual
Offroad Animal
IMPORTANT! – READ BEFORE INSTALLATION
•
When installed in accordance with these instructions, the front protection bar does
not affect the operation of the vehicles SRS airbags.
•
This product must be installed exactly as per these instructions using only
hardware supplied.
•
Take a few moments to read instructions thoroughly before beginning work.
•
In the event of damage to any bar component please contact OFFROAD ANIMAL
to arrange repair/replacement of components.
•
Do not use this product for any vehicle make or model other than that specified on
these instructions.
•
Do not remove labels from this product.
•
This product and its fixings must not be modified in any way unless stated in these
fitting instructions.
•
The installation of this product is recommended for trained personnel.
•
These instructions are correct at time of publication. OFFROAD ANIMAL cannot
be held responsible for the impact of any changes subsequently made by the
vehicle manufacturer. If you find something has changed, please contact us to let
us know!
•
During installation it is the duty of the installer to check correct
operation/clearances of all components.
•
If Instructions are to be printed for reference in the workshop, it is recommended
that they are printed in colour, for best legibility.
REV A
FB-RTX-DT-21-PR-ASM0
Fitting Instruction
28/10/2024
RAM 1500 TRX
Predator Front Bar
Page 1 of 64

Advertisement

loading
Need help?

Need help?

Do you have a question about the FB-RTX-DT-21-PR-ASM0 and is the answer not in the manual?

Questions and answers

Related Manuals for Offroad Animal FB-RTX-DT-21-PR-ASM0

Summary of Contents for Offroad Animal FB-RTX-DT-21-PR-ASM0

  • Page 1 • Take a few moments to read instructions thoroughly before beginning work. • In the event of damage to any bar component please contact OFFROAD ANIMAL to arrange repair/replacement of components. • Do not use this product for any vehicle make or model other than that specified on these instructions.

  • Page 2: Parts List

    Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar IMPORTANT: Check all parts are present before beginning work! Contact OFFROAD ANIMAL if something is missing. Parts List Part Number Description Image RAM 1500 TRX FB-RTX-DT-21- Predator Bar Welded...
  • Page 3 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar Ram 1500 Halo Fog B-0519R Light Bracket RH Ram 1500 Halo Fog B-0519L Light Bracket LH RAM1500 DT Winch B-0589 Control Box Mount Bracket RAM 1500 TRX Winch B-1156R...
  • Page 4 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar M-0002R Light Cover Mesh M-0002L Light Cover Mesh RAM 1500 Predator M-0016 Fairlead Mesh RAM 1500 Predator M-0017R Side Mesh RH RAM 1500 Predator M-0017L Side Mesh LH RAM 1500 TRX Centre...
  • Page 5 Parking Sensor Holder F-0030 - Universal, Flat Tape Kit - 6 Sensor TK-COM-PSEN-6 Universal Pinch Weld - Plain PW-P-14X9-180 14X9MM, Rubber, 180mm Length Offroad Animal Metal OFA-LOGO Logo Fitting Instruction FI Note Note REV A 28/10/2024 Page 5 of 64...
  • Page 6 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar PREDATOR Fasteners – Contained in Small Parts Kit Bag Part Number Description M4X12 PAN SCREW, PAN HEAD PHILLIPS, M4X12X0.7 GR4.6 ZP M4 FLAT WASHER Flat Washer M4, 8mmODx0.8mm T...
  • Page 7 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar The following tools will be required to install the product. Hand Tools Power Tools Workshop Equipment Metric socket set 8-19mm Electric/Air Impact Isopropyl Alcohol Driver (Optional) Socket extension bar...
  • Page 8 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar It is the responsibility of the installer to always complete works in a safe manner. Make sure the following safety equipment is available and precautions are observed whilst fitting this product.

  • Page 9: Tools Required

    Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 1. Remove the number plate and set aside. TOOLS REQUIRED FASTENERS REV A 28/10/2024 Page 9 of 64...
  • Page 10 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 2. Remove 6x 16mm hex bolts holding the factory skid TOOLS REQUIRED plate. 16mm socket/spanner Retain bolts and skid plate for re-use. FASTENERS 6x 16mm factory hex bolts Retain for re-use...
  • Page 11 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN 3. Remove 5x 8mm hex bolts holding the front inner wheel TOOLS REQUIRED arch, per side. 8mm socket/spanner 4. Disconnect the main bumper wiring harness covered underneath on the LH passenger side (driver side for US LHD).
  • Page 12 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar LH SHOWN 5. Locate the oil cooler behind the front bumper, in TOOLS REQUIRED between the chassis rails. 13mm socket/spanner 6. Support the oil cooler with a box or stand.
  • Page 13 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN View from below 8. Remove 3x 18mm hex nuts (per side) holding the TOOLS REQUIRED bumper to the chassis rail. 18mm socket/spanner FASTENERS REV A 28/10/2024 Page 13 of 64...
  • Page 14 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 9. With a lifting device or assistance from another person, TOOLS REQUIRED pull the bumper outwards and remove from the vehicle. Set the bumper aside in a safe place.
  • Page 15 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 10. Remove 1x 18mm hex bolt (rear) and 1x 21mm hex bolt TOOLS REQUIRED (front) holding each tow hook to the underside of the chassis. Retain both bolts. 18mm socket/spanner...
  • Page 16 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 12. Remove 2x 13mm hex bolts holding the top of the oil TOOLS REQUIRED cooler to its mount. Ensure the rubber parts stay with the oil cooler. 13mm socket/spanner...
  • Page 17 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 13. Remove 2x 10mm hex nuts holding the bottom of the oil TOOLS REQUIRED cooler to its mount. 10mm socket/spanner 14. Retain the rubber block with the threaded studs (bottom left inset photo), as well the hex nuts.
  • Page 18 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar M8x35, washer + flange nut 16. Place the rubber block with studs back onto the TOOLS REQUIRED centre of the oil cooler, at the bottom. 10mm socket/spanner 17. Fit the supplied oil cooler relocation bracket to 13mm socket/spanner the oil cooler, by sliding it on the from the side.
  • Page 19 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 20. Re-use 4x of the 13mm hex bolts from Step 7 TOOLS REQUIRED and fit the oil cooler and bracket to the embedded nuts in the chassis cross member, as 13mm socket/spanner shown.
  • Page 20 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN 22. Loosely fit each impact assembly to the front face TOOLS REQUIRED of the chassis horns with 3x M12x30 hex bolts, heavy-duty washers and flange nuts. FASTENERS...
  • Page 21 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 21mm hex bolt RH SHOWN 18mm hex bolt + rubber bush M10x25 + flat washer, heavy-duty washer sandwiched in between + flange nut 23. Fit the tow point and bash plate mount to the TOOLS REQUIRED underside of the chassis rail.
  • Page 22 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN 28. Loosely secure the inner face of each tow point to TOOLS REQUIRED each impact assembly with 2x M10x25 hex bolts, flat washers and flange nuts. FASTENERS...
  • Page 23 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 29. Measure the distance between the outside faces of TOOLS REQUIRED uprights on bar using tape measure. Write distance below for reference if required. Tape measure Bar Upright Width = ___________mm...
  • Page 24 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN Unplug 32. Unplug the fog light on the back of the bumper. TOOLS REQUIRED 33. Remove 2x T40 Torx screws holding the top of the fog T40 Torx bit light to the bumper.
  • Page 25 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN 36. Remove and discard the fog light. TOOLS REQUIRED 37. Repeat for the other side. FASTENERS REV A 28/10/2024 Page 25 of 64...
  • Page 26 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 38. Unplug the side marker lamps located on the outer TOOLS REQUIRED ends of the bumper. These lamps will not be relocated into the bullbar. FASTENERS REV A 28/10/2024...
  • Page 27 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar Spread tabs apart 39. Locate the 6x parking sensors on the bumper, and unclip TOOLS REQUIRED them from its plastic housing by spreading the housing plastic tabs apart. 2x of the sensors are hidden behind metal bumper brackets (see inset photo), but can still be reached by hand without disassembly.
  • Page 28 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 40. Use a trim removal tool and unclip the entire bumper TOOLS REQUIRED wiring harness. Trim removal tool 41. Remove the harness with parking sensors from vehicle and set aside.
  • Page 29 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 42. Cclean the areas on the inside of the bullbar adjacent to TOOLS REQUIRED the 6x sensor holes with isopropyl alcohol. Allow to dry. Isopropyl alcohol Clean rag 43. Lightly scuff the bonding surfaces of the 6x supplied plastic Sandpaper sensor housings with sandpaper.
  • Page 30 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 44. Press down on the arrow location and break the bulb of TOOLS REQUIRED the supplied 3M Primer 94 ampule to activate the primer dispensing. 45. Apply 3M Primer 94 to all areas adjacent to the parking sensor locations, on both the bullbar and the sensor housings.
  • Page 31 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 46. Unplug the parking sensors from the previously removed TOOLS REQUIRED bumper wiring harness. Take note of the location of each parking sensor on the car/bullbar (eg. outer left, middle left, middle right etc.).
  • Page 32 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN Inner 2x sensors – plug facing outwards Outer 2x sensors – RH SHOWN plug facing inwards Intermediate 2x sensors – plug facing up/inwards RH SHOWN 49. Remove backing film on VHB tape (easier with utility knife to TOOLS REQUIRED peel off) and adhere parking sensors in position in the bullbar.
  • Page 33 Fitting Instruction Predator Front Bar LH SHOWN 54. If the option has been selected, fit the Offroad Animal TOOLS REQUIRED Halo fog lights to the supplied fog light brackets using 4x M4x12 pan head screws, flat washers and flange nuts Phillips head screwdriver (each).
  • Page 34 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar LH SHOWN 56. If wanting to fit other lights to the wing mesh instead of TOOLS REQUIRED fog lights, do so now. The wing mesh is capable to taking most 8”...
  • Page 35 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 57. Fit the wing mesh to the bullbar using 4x M16x16 black TOOLS REQUIRED button head bolts, black flat washers and flange nuts. 4mm hex/Allen Key 58. Secure and tighten using 4mm hex/Allen key and repeat for other side.
  • Page 36 60. If fitting an integrated light bar, do so now from the back. TOOLS REQUIRED This bar is designed to fit the Offroad Animal 32 inch light Supplied with accessories bar. If fitting this light bar, assemble the light bar with legs facing inwards, and line it up with the slots in the centre gusset.
  • Page 37 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 62. Fit the pan brace to the back of the bar using 6x M6x16 TOOLS REQUIRED black button head bolts, flat washers and flange nuts. 4mm hex/Allen key 63. Tidy up the wiring harness and other looms with cable Cable ties ties on the inside of the bar.
  • Page 38 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 64. Fit 10x M6 cage nuts into the rectangular slots on TOOLS REQUIRED the bottom of the bar wing (5x per side). Flat blade screwdriver To aid fitting, use a small flat blade screwdriver to push the edge of the cage nut to engage with the slot.
  • Page 39 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN 65. The wheel flares need to be trimmed to fit the bar. TOOLS REQUIRED Apply masking tape over the flares in approximately the position shown. Masking tape...
  • Page 40 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN 130mm 66. Measure and mark a straight horizontal line that is TOOLS REQUIRED parallel to the bottom edge of the flare, 130mm away. Do this for both flares.
  • Page 41 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN Optional 67. Remove 8x 8mm hex bolts securing the underside TOOLS REQUIRED of each flare. Retain the bolts for re-fitment. 8mm socket/spanner 68. (Optional) Drop the wheel arch liner for better access for removing plastic clips in next step.
  • Page 42 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN Push on clips with 8mm socket 69. Starting from the back, pull outwards to release the clips TOOLS REQUIRED holding the flare to the fender. 8mm socket (optional) 70.
  • Page 43 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN 72. Remove the plastic trim under each headlight. Start at the TOOLS REQUIRED base of the grille and pull the trim outwards to release the clips. FASTENERS...
  • Page 44 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN 20mm from end of radius to intersection on crease 20mm from edge Align the end point with the crease in the fender 73. The fiberglass fender also needs a section cut and TOOLS REQUIRED removed.
  • Page 45 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN 74. Use an air hacksaw to cut the fender along the marked TOOLS REQUIRED cut line. Air hacksaw WARNING: Fibreglass fibres are skin irritants and can cause respiratory issues when inhaled. Wear gloves and...
  • Page 46 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN 76. Cut the flares along the marked cut lines. TOOLS REQUIRED 77. Remove masking tape and clean up the cut edges with a Air hacksaw or similar utility knife.
  • Page 47 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN 78. Fit and trim the supplied pinch weld to the cut flare TOOLS REQUIRED edge. Side cutters 79. Notch the inside of the pinch weld to clear the flare clip mount (see inset).
  • Page 48 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 80. The front camera in the grille will be partially TOOLS REQUIRED obstructed by the bullbar (see reference image above). Driving lights and top tubes will fully obstruct the camera.
  • Page 49 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 82. Re-fit the plastic trim under each headlight. TOOLS REQUIRED 83. Re-fit the trimmed wheel arch flares using factory 8mm socket/spanner fasteners. 84. Re-fit wheel arch liners, if removed.
  • Page 50 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar RH SHOWN 85. Using a utility knife, cut out a 30x30mm section out of TOOLS REQUIRED the wheel arch liner, directly below the flare cut. Do this on both sides.
  • Page 51 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 86. With assistance, either from another person, or a TOOLS REQUIRED lifting trolley, lift the bar onto the mounts on the vehicle. Lifting trolley 87. Secure the bar to the mounts with 8x M12x30 Bolts, heavy duty washers and M12 Nyloc + flange nuts.
  • Page 52 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 15-20mm Clearance In line with 15-20mm wheel arch Clearance 88. With assistance, from another person, align the bar TOOLS REQUIRED with the edges of the vehicle. The bar should sit symmetric left/right on the vehicle.
  • Page 53 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar LH SHOWN 91. From underneath the vehicle, install the 2x tension TOOLS REQUIRED straps connecting the bottom of the winch cradle to the tow points. 16/17mm socket/spanner Note: The longer slot ins the strap goes to the tow point, and the shorter slot goes to the winch cradle.
  • Page 54 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar Control box bracket 93. If fitting a winch, do so now. TOOLS REQUIRED 94. This bar is designed to fit most low mount winches, Refer to instructions supplied by in foot down configuration.
  • Page 55 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 97. If required, fit the winch fairlead to the centre TOOLS REQUIRED mesh fairlead mount using M10 or 3/8” fasteners supplied with the winch. This bar is only 10mm socket/spanner compatible with hawse type fairleads.
  • Page 56 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 100. Fit the mesh fairlead mount to the threaded holes in TOOLS REQUIRED the centre of the bar, using 2x M8x16 black button head bolts (top), 2x M8x20 hex head bolts (bottom)
  • Page 57 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar LH SHOWN 103. Insert the side mesh panels into the winch opening TOOLS REQUIRED at an angle as shown, to get the outer flange behind the return of the front face of the bar.
  • Page 58 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 107. Fit the oil cooler air guide to the bash plate as TOOLS REQUIRED shown, and secure with 5x M6x16 black button head bolts, black washers and flange nuts.
  • Page 59 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 108. Fit the centre bash plate to the bar using 6x M8x30 TOOLS REQUIRED black button bolts and flat washers. 5mm hex/Allen key 109. Secure the back of the centre bash plate to the...
  • Page 60 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 110. Re-fit the factory skid plate, using the 6x factory TOOLS REQUIRED 16mm hex bolts from Step 2, plus 2x supplied M10 flange nuts for the front 2x bolts into the bash 16mm socket/spanner plate.
  • Page 61 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 111. Fit the supplied compliance label to the inside of TOOLS REQUIRED one of the side underpanels. FASTENERS REV A 28/10/2024 Page 61 of 64...
  • Page 62 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 112. Secure the side underpanel to the bar with 5x TOOLS REQUIRED M6x16 black button head bolts and black flat washers. 4mm hex/Allen key 13mm socket/spanner 113. Secure the side underpanel to the impact assembly (see inset) using 1x M8x20 hex head bolt, heavy- duty washer and flange nut.
  • Page 63 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar 115. Fit the Offroad Animal logo plate to the front of the TOOLS REQUIRED vehicle as shown. 116. Review fitment and double check all bolts are tightened correctly. FASTENERS...
  • Page 64 Offroad Animal FB-RTX-DT-21-PR-ASM0 RAM 1500 TRX Fitting Instruction Predator Front Bar Congratulations! You’re done! Head out of town and enjoy your newly protected TRX! REV A 28/10/2024 Page 64 of 64...
