Offroad Animal
IMPORTANT! – READ BEFORE INSTALLATION
•
This product must be installed exactly as per these instructions using only
hardware supplied.
•
Take a few moments to read instructions thoroughly before beginning work.
•
In the event of damage to any component please contact OFFROAD ANIMAL to
arrange repair/replacement of components.
•
Do not use this product for any vehicle make or model other than that specified on
these instructions.
•
Do not remove labels from this product.
•
This product and its fixings must not be modified in any way unless stated in these
fitting instructions.
•
The installation of this product is recommended for trained personnel.
•
These instructions are correct at time of publication. OFFROAD ANIMAL cannot
be held responsible for the impact of any changes subsequently made by the
vehicle manufacturer. If you find something has changed please contact us to let
us know!
•
During installation it is the duty of the installer to check correct
operation/clearances of all components.
•
If Instructions are to be printed for reference in the workshop, it is recommended
that they are printed in colour, for best legibility.
•
Estimated install time: 2 hours
REV NIL
RB-JWR-JK-07-ASM0
Fitting Instruction
8/07/19
2007-2018 JK Wrangler
REAR BUMPER
Page 1 of 18
Advertisement
Related Manuals for Offroad Animal RB-JWR-JK-07-ASM0
Summary of Contents for Offroad Animal RB-JWR-JK-07-ASM0
- Page 1 • Take a few moments to read instructions thoroughly before beginning work. • In the event of damage to any component please contact OFFROAD ANIMAL to arrange repair/replacement of components. • Do not use this product for any vehicle make or model other than that specified on these instructions.
- Page 2 Offroad Animal RB-JWR-JK-07-ASM0 2007-2018 JK Wrangler Fitting Instruction REAR BUMPER IMPORTANT: Check all parts are present before beginning work! Contact OFFROAD ANIMAL if something is missing. Main Parts – In the Box Part Description Image Number RP-JWR- JK-07- JK Rear bar...
- Page 3 Offroad Animal RB-JWR-JK-07-ASM0 2007-2018 JK Wrangler Fitting Instruction REAR BUMPER JK rear wing B-0128R support RH JK-rear wing B-0128L support LH Optional part from JK rear mud Mud flap flap bracket B-0205R Optional part from JK rear mud Mud flap...
- Page 4 250W x 350L MF-001 Small Parts – Contained in Small Parts Kit Bag Part Number Description OFA-LOGO Offroad Animal Logo metal M12 FW LHD M12 FW Large Heavy duty M10 x 20 BHCS M10 button head cap screw M10 NY...
- Page 5 Offroad Animal RB-JWR-JK-07-ASM0 2007-2018 JK Wrangler Fitting Instruction REAR BUMPER The following tools will be required to install the product. Hand Tools Power Tools Workshop Equipment None None 16mm Socket 18mm socket 16mm spanner 18mm spanner 4mm Allen key 5mm Allen Key...
- Page 6 Offroad Animal RB-JWR-JK-07-ASM0 2007-2018 JK Wrangler Fitting Instruction REAR BUMPER TOOLS REQUIRED 1. Start by removing 2x M10 bolts on side of chassis 16mm socket or spanner 2. Repeat on other side. FASTENERS Retain for later use REV NIL 8/07/19...
- Page 7 Offroad Animal RB-JWR-JK-07-ASM0 2007-2018 JK Wrangler Fitting Instruction REAR BUMPER 3. Climb underneath and disconnect loom for rear number TOOLS REQUIRED plates FASTENERS REV NIL 8/07/19 Page 7 of 18...
- Page 8 Offroad Animal RB-JWR-JK-07-ASM0 2007-2018 JK Wrangler Fitting Instruction REAR BUMPER TOOLS REQUIRED 4. While still underneath remove 2 x M10 bolts as shown, and 16mm socket loosen M10 bolts further up on same bracket FASTENERS Discard fasteners REV NIL 8/07/19...
- Page 9 Offroad Animal RB-JWR-JK-07-ASM0 2007-2018 JK Wrangler Fitting Instruction REAR BUMPER TOOLS REQUIRED 5. Pull rear bumper away from body FASTENERS REV NIL 8/07/19 Page 9 of 18...
-
Page 10: Tools Required
Offroad Animal RB-JWR-JK-07-ASM0 2007-2018 JK Wrangler Fitting Instruction REAR BUMPER 6. Remove Factory tow hook TOOLS REQUIRED 18mm socket or spanner FASTENERS Discard factory fasteners REV NIL 8/07/19 Page 10 of 18... - Page 11 Offroad Animal RB-JWR-JK-07-ASM0 2007-2018 JK Wrangler Fitting Instruction REAR BUMPER 7. With bumper removed open rear door before putting new TOOLS REQUIRED bar on FASTENERS REV NIL 8/07/19 Page 11 of 18...
- Page 12 Offroad Animal RB-JWR-JK-07-ASM0 2007-2018 JK Wrangler Fitting Instruction REAR BUMPER 8. Insert nut plates into chassis like shown TOOLS REQUIRED FASTENERS REV NIL 8/07/19 Page 12 of 18...
- Page 13 Offroad Animal RB-JWR-JK-07-ASM0 2007-2018 JK Wrangler Fitting Instruction REAR BUMPER 9. Lift bar on to Jeep TOOLS REQUIRED FASTENERS REV NIL 8/07/19 Page 13 of 18...
- Page 14 Offroad Animal RB-JWR-JK-07-ASM0 2007-2018 JK Wrangler Fitting Instruction REAR BUMPER 10. Use factory bolts up front to hold bar in place, and insert TOOLS REQUIRED supplied M12 bolts to hold bar. Tighten all M12 bolts starting with underside ones first 18mm socket and spanner 11.
- Page 15 Offroad Animal RB-JWR-JK-07-ASM0 2007-2018 JK Wrangler Fitting Instruction REAR BUMPER 12. Remove factory bolts put in the last step and position wing TOOLS REQUIRED support bracket as shown. 13. Insert factory M10 bolts back into side of chassis 16mm spanner...
- Page 16 Offroad Animal RB-JWR-JK-07-ASM0 2007-2018 JK Wrangler Fitting Instruction REAR BUMPER 14. Put M10 BHCS into bracket and edge of bar as shown. TOOLS REQUIRED Tighten all bolts 6mm Allen key 15. Repeat for other side 16mm socket FASTENERS M10 x 20 BHCS (2)
- Page 17 Offroad Animal RB-JWR-JK-07-ASM0 2007-2018 JK Wrangler Fitting Instruction REAR BUMPER 16. If fitting Optional mud flap brackets, position bracket as TOOLS REQUIRED shown with M8 BHCS and flange nuts with washers 17. Repeat for other side 5mm Allen key FASTENERS...
