- Page 1 ALTA POOl TABLE MODEL NO. PTAL Please Do Not Return This Contact Escalade® Sports customer service department at: Phone: 1-800-835-7665 (Toll-FREE!) Product to the Store! Hours: 10:00 - 6:00 EST, Monday - Friday E-mail: Claims@AmericanHeritageBilliards.com 2022 Escalade Sports...
-
Page 2: P R E - A S S E M B L Y T I P S
NOTICE: READ AND FOLLOW ALL ASSEMBLY, OPERATION AND SAFETY INSTRUCTIONS CAREFULLY. P R E - A S S E M B L Y T I P S 1. Read this manual carefully before starting assembly. Read each step completely before beginning next step. - Page 3 HARDWARE LIST (ACTUAL SIZE) H1 - 5/16” x 2-1/2” PHILLIPS HEX HEAD BOLT (28 PCS) H3 - 5/16” LOCK WASHER H2 - 5/16” x 4-1/2” PHILLIPS HEX HEAD BOLT (32 PCS) (16 PCS) H5 - 5/16” HEX NUT H4 - 5/16” x 19 mm FLAT H6 - 5/16”...
- Page 4 PTAL PARTS LIST (NOT ACTUAL SIZE) PTAL - TOP RAIL/BLIND BOX P2A - END TOP RAIL P2B - END TOP RAIL WITH P1 - TOP RAIL (1 PC) AHB NAME PLATE (1 PC) (2 PCS) PTAL - PANELS & BEAMS BOX P4 - END BLIND P3 - LONG SIDE BLIND P6 - CENTER BEAM...
-
Page 5: Parts Required
PARTS REQUIRED: 8 PCS H1 - 5/16” x 2-1/2” PHILLIPS HEX HEAD BOLT 2 PCS P3 - LONG SIDE BLIND 8 PCS H4 - 5/16” x 3/5” FLAT WASHER 2 PCS P4 - END BLIND STEP 1: Attach End Blinds P4 to Long Side Blinds P3, use Phillips Hex Head Bolts H1, Flat Washers H4 as shown in FIGURE 1 &... - Page 6 PARTS REQUIRED: H1 - 5/16” x 2-1/2” PHILLIPS HEX HEAD BOLT 4 PCS P7 - LEG 16 PCS 16 PCS H4 - 5/16” x 3/5” FLAT WASHER STEP 2: Attach Legs P7 to the Blinds assembly from STEP 1, use Phillips Hex Head Bolts H1, Flat Washers H4 as shown in FIGURE 2 &...
- Page 7 PARTS REQUIRED: 8 PCS H2 - 5/16” x 4-1/2” PHILLIPS HEX HEAD BOLT 2 PCS P5 - LONG SIDE BEAM 16 PCS H3 - 5/16” LOCK WASHER 16 PCS H4 - 5/16” x 3/4” FLAT WASHER 8 PCS H5 - 5/16” HEX NUT STEP 3: Attach Long Side Beams P5 to End Blinds P4, use Phillips Hex Head Bolts H2, Lock Washers H3, Flat Washers H4 and Hex Nut H5 as shown in FIGURE 3 &...
- Page 8 PARTS REQUIRED: H1 - 5/16” x 2-1/2” PHILLIPS HEX HEAD BOLT P6 - CENTER BEAM 4 PCS 2 PCS 8 PCS H2 - 5/16” x 4-1/2” PHILLIPS HEX HEAD BOLT H3 - 5/16” LOCK WASHER 16 PCS 20 PCS H4 - 5/16” x 3/4” FLAT WASHER H5 - 5/16”...
- Page 9 PARTS REQUIRED: 12 PCS 1 PC P10 - SLATE H7 - 1/4” X 2-1/2” PHILLIPS HEX HEAD SCREW STEP 5: Attach Slate P10 to Beams, use Phillips Hex Head Screws H7 as shown in FIGURE 5. FIGURE 5...
- Page 10 PARTS REQUIRED: H6 - 2 PCS P1 - TOP RAIL/BLIND 16 PCS 5/16” x 16 mm FLAT WASHER 8 PCS H8 - 5/16” x 3-1/2” BOLT 1 PC P2A - END TOP RAIL/BLIND 16 PCS H5 - 5/16” HEX NUT P2B - END TOP RAIL/BLIND WITH 1 PC AHB NAME PLATE...
- Page 11 PARTS REQUIRED: H9 - DOME WASHER 18 PCS H10 - 3/8” LOCK WASHER 18 PCS 18 PCS H11 - 3/8” x 3” BOLT 18 PCS H12 - 3/8” HEX NUT STEP 7: Attach Top Rail/Blinds assembly from STEP 8 to Slate P11, use Bolts H11, Dome Washers H9, Lock Washers H10, and Hex Nuts H12 as shown in FIGURE 7.
- Page 12 PARTS REQUIRED: 4 PCS P8 - CORNER POCKET 2 PCS P9 - CENTER SIDE POCKET STEP 8: Attach Corner Pockets P8 and Center Side Pockets P9 to the table as shown in FIGURE 8. FIGURE 8...
-
Page 13: Spare Parts List
SPARE PARTS LIST KEY# PART# DESCRIPTION PTALXNH1 5/16” x 2-1/2” PHILLIPS HEX HEAD BOLT PTALXNH2 5/16” x 4-1/2” PHILLIPS HEX HEAD BOLT PTALXNH3 5/16” LOCK WASHER PTALXNH4 5/16” x 19 mm FLAT WASHER PTALXNH5 5/16” HEX NUT PTALXNH6 5/16” x 16 mm FLAT WASHER PTALXNH7 1/4”... -
Page 14: One Year Warranty
ONE YEAR WARRANTY WARRANTY All American Heritage Billiard pool is not include Warranty does not include re-leveling 1-800-835-7665 (Toll-FREE!) Phone: Hours: 10:00 - 6:00 EST, Monday - Friday E-mail: Claims@AmericanHeritageBilliards.com CARE AND MAINTENANCE...
