American Heritage Billiards ESCALADE SPORTS SBALTA9 Assembly Instructions Manual

Alta 9' shuffleboard
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

Please Do Not Return This
Product to the Store!
Contact Escalade® Sports customer service department at:
Phone: 1-800-835-7665 (Toll-FREE!)
Hours: 10:00 - 6:00 EST, Monday - Friday
E-mail: Claims@AmericanHeritageBilliards.com
ALTA 9'
SHUFFLEBOARD
MODEL NO.
SBALTA9
2022 Escalade Sports
V1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESCALADE SPORTS SBALTA9 and is the answer not in the manual?

Questions and answers

Related Manuals for American Heritage Billiards ESCALADE SPORTS SBALTA9

Summary of Contents for American Heritage Billiards ESCALADE SPORTS SBALTA9

  • Page 1 ALTA 9’ SHUFFLEBOARD MODEL NO. SBALTA9 Please Do Not Return This Contact Escalade® Sports customer service department at: Phone: 1-800-835-7665 (Toll-FREE!) Product to the Store! Hours: 10:00 - 6:00 EST, Monday - Friday E-mail: Claims@AmericanHeritageBilliards.com 2022 Escalade Sports...

  • Page 2: P R E - A S S E M B L Y T I P S

    NOTICE: READ AND FOLLOW ALL ASSEMBLY, OPERATION AND SAFETY INSTRUCTIONS CAREFULLY. P R E - A S S E M B L Y T I P S 1. Read this manual carefully before starting assembly. Read each step completely before beginning next step.
  • Page 3 SBALTA9 HARDWARE LIST (ACTUAL SIZE) H1 - 5/16” X 3-1/4” FLANGED HEX H2 - 5/16” X 3/4” FLAT WASHER H3 - #6 X 1" HEAD BOLT (16 PCS) (16 PCS) PHILLIPS FLAT HEAD SCREW (4 PCS) PARTS LIST (NOT ACTUAL SIZE) SBALTA9 - CABINET P1 - SHUFFLEBOARD CABINET...

  • Page 4: Parts Required

    PARTS REQUIRED: 16 PCS H1 - 5/16-18 FLANGED HEX HEAD 1 PC P1 - SHUFFLEBOARD CABINET SCREW x 3.25" 4 PCS P2 - CORNER LEG 16 PCS H2 - 5/16 FLAT WASHER STEP 1: Place your Shuffleboard Cabinet P1 upside down as shown in FIGURE 1. Attach Corner Legs P2 to the bottom of Shuffleboard Cabinet P1 using Flanged Hex Head Screw H1 and Flat Washers H2 as shown in FIGURE 1.
  • Page 5 PARTS REQUIRED: 4 PCS H3 - #6 SCREW x 1” 2 PCS P3 - ABACUS SCORING SYSTEM STEP 2: Secure Abacus Scoring System P3 to Shuffleboard Cabinet P1 using #6 SCREW X 1" H3 as shown in FIGURE 2. Tighten with caution; do not overtighten to avoid stripping out the screws. Attach the Abacus Scorer Caps C1.

  • Page 6: Spare Parts List

    SPARE PARTS LIST KEY# PART# DESCRIPTION SBALTA9HARDWARE 5/16” X 3-1/4” FLANGED HEX HEAD BOLT SBALTA9HARDWARE 5/16” x 3/4” FLAT WASHER SBALTA9HARDWARE #6 X 1" PHILLIPS FLAT HEAD SCREW SBALTA9CABINETASSY-BA SHUFFLEBOARD CABINET ASSEMBLY SBALTA9CORNERLEG-BA CORNER LEG SBGENABACUSSET ABACUS SCORING SYSTEM SBALTA9HARDWARE HARDWARE KIT SBGENABACUSSET ABACUS SCORER CAP...

  • Page 7: Lifetime Warranty

    LIFETIME WARRANTY WARRANTY All American Heritage Billiard shuffleboards are guaranteed by a robust warranty against manufacturing defects and craftsmanship from the date of purchase of the original owner as follows: • The cradle/cabinet is warranted against splitting, cracking or warping from the date of purchase of the original owner.
