Quest Engineering V80 Quick Start page 2

CONTROL BUTTONS
6
7
8
9
4
KEY FUNCTION ALTERNATIVE FUNCTION
1 Power on Hold 0.5 sec to Power off
Hold to turn iron on / off
2 Change modes
3 Change frequency
Hold to perform noise
cancelling
4 MENU Setup
5 Pinpoint
Hold for Ground Balance
6 Volume up Hold to + volume quickly
7 Volume down / Hold to - volume quickly
Vibration
8 Increase sensitivity Hold to + sensitivity quickly
9 Decrease sensitivity Hold to - sensitivity quickly
10 Backlight adjust Hold for flashlight
SETTINGS
FUNCTION
Select the appropriate search mode for the area you are searching.
Searchmodes
You can choose between park, field, beach, gold and cache.
The factory start up setting as well as the recommended sensitivity
setting is 70. At SENS 70 you will reach a good depth in most
ground conditions and a stable and silent detection result. If you
Sensitivity
reduce the SENS below 70 you will loose some depth. The
sensitivity levels 71 to 99 have to be seen as an extra (booster)
sensitivity which can be used in some ground conditions to reach
extra depth, although you will experience a more noisy detection in
most ground conditions.
Make custom patterns to separate wanted from unwanted
targets. Each target is shown by a number and a spot on the
Target ID
Discrimination Scale (1-99). By choosing or not choosing, you
Masking
can decide if they will be detected or ignored.
Adjust the strength of the electromagnetic field by changing the
TX POWER to different levels. The stronger the TX POWER, the
Transmitter
better the performance and it's a good option for finding high-
Power conductive targets such as large masses, treasure, and certain
currencies.
Choosing a faster recovery speed helps to quickly analyze
Recovery
signals in trashy conditions. A slower recovery speed is better for
Speed
clear and clean environments for increased depth.
Under this menu, press and hold the accept button to save your
current settings. You can also save your favorite settings as
Saved
personal programs for different situations, and manage them here.
Programs You can apply, edit, or pin a selected program to the top for easy
access.
The Target Tone Numbers categorizes target sounds into
several spaces. The more tone spaces you have, the more
Tone
different sounds you will hear. The changes will showed on the
Numbers
ID bars at the stand by interface as well.
Under this menu, press the accept button to choose between
different joints, and use the up/down buttons to navigate back and
Tone Space
forth.
Tone Pitch lets you customize the sound frequency of target
responses based on target categories from 90 to 1500Hz. It
Tone Pitch allows you to customize your desired audio and enhances your
ability to hear desired targets.
The Tone volume gives you complete control over the audio
Tone volumes
volume for detected targets in each Tone space.
1
10
2
3
5
IN MENU FUNCTION
Hold 0.5 sec to Power off
Confirm, Accept/Reject ID
Return to higher level MENU
Exit MENU
Scroll up/Increase
Scroll down/Increase
DESCRIPTION
WIRELESS AUDIO STATUS
SPEAKER VOLUME
TONE SPACES
CORRECTION INDEX
MINERALIZATION %
SALT WATER %
SENSITIVITY LEVEL
TX POWER
RECOVERY SPEED
⚙
Click to enter MENU.Use▲▼ to navigate. Click upper
Use ▲▼ to navigate in 2nd level menu. Click lower
DETECT MENU
SOUND MENU
GROUND MENU
SET MENU
FUNCTION
Choose
frequencies, including 5, 10, 15, 20, 40 and 60 kHz. or choose
Frequencies
Hyper-Q where you search with all frequencies from 5 to 80
kHz at the same time. Low frequencies are used for
searching for large objects, high frequencies for searching
for small objects. With Hyper-Q you can search with the
advantages of all frequencies at the same time.
Used to precise locate metal targets.
Pinpoint
Find a place where there is no metal, and hold down the
ground balance / pinpoint button and pump the search coil
Groundbalance
up and down between 25 and 5 cm from the ground. Ground
balance is to ignore the disturbances from the ground by
minerals as much as possible.
Iron Bias setting gives the machine permission to
identify ferrous-appearing targets as iron or not. It
Ferrous
helps the detector accurately classify big or intricate
Bias iron targets (such as rusted nails or bottle caps) as
ferrous, making them easier to reject.
A threshold tone is a continuous background noise that
assists
Threshold
undesirable targets, as well as detecting soft signals.
This function is only available in the Goldmode.
Instruct the detector to automatically initiate ground
balance without manual button press. Enable the
detector to automatically enter power-saving mode if
Gyro Sensor
there is no motion detected for 5 seconds. Activate
motion detection for the detector to measure swing
speed and angle for improved accuracy.
Manual
Ground
Manually select the ground effect correction
Blance
Accurately setup backlight brightness, LCD refresh rate
DIsplay
Clock setup
Setup
Manage wireless headphone connections, including
Wireless
searching for new devices, pairing, and unpairing
Setup headphones.
Reset to factory default setting
Reset
INTERFACE & MENU
BACKLIT
TARGET ID CLOCK
IRON AUDIO
FE/NONFE POSSIBILITY
▪
to enter 2nd level.
▪
to return to 1st level menu.
DESCRIPTION
between the different selectable
in distinguishing between desirable
BATTERY STATUS
TARGET ID MASK
SIGNAL STRENTH
FREQUENCY
MODE
GYRO STATUS
single
and
