Quest Engineering V80 Quick Start

PARTS
Controller
BLIZZARD11
Carbon-fiber rods
Aluminium rods
IN THE BOX INSTALLATION
V80 V60
ITEMS
3
V80 Control box ✔
V60 Control box ✔
✔
Carbon fiber rod set
O
1 Install controler
Aluminum rod set ✔
O
2 Install armrest
✔ ✔
Armrest+Elbow band
3 Extend rods
Blizzard11 Coil ✔ ✔
4 Connect coil to rod
Blizzard9 Coil
O O
5 Route coil cable on rods
✔
WireFree WRXB 6 Connect coil to controler
O
WireFree Pro HE ✔
O
✔
WireFree Vibe
O
USB Charger+Cable ✔ ✔
Headphones Adaptor ✔ ✔
Underwater Headphones
O O
5
: included. O: optional
✔
Trouble shooting
Coil is not connected. Power is low, please recharge the
NOT POWER ON
detector.
SPEAKER NO ALARM
Check the volume of speaker, or wireless headphones
Perform noise canceling. Please find another place with less
VERY NOISY
interference. Lower sensitivity
Make sure the Volume is not set to ZERO level and/or wireless
NO SOUND
audio has been activated
Use Velcro tape to secure cable to rod, prevent tangling, and
FALSING WHEN
SEARCHING IN GRASS
protect from hard impacts
Please turn to BEACH MODE if you are detecting on the
OVERLOAD ALARM
beach or high mineralized ground. Also very large objects
close to the surface can cause overload alarms, please change
location.
Make sure the headphone jack is far enough in the port /HE
THE SOUND IS VERY WEAK
Maintenance
•
Do not twist coil tail or connector to prevent wire damage.
•
Store device away from extreme temperatures.
•
Use soft object to operate touchpad to avoid damage.
•
Avoid chemicals, solvents, and insect repellents that can harm waterproofing, plastics,
and finishes. Tightly secure audio protection cap to prevent damage to audio port.
Cleaning
•
Clean detector after underwater use, let handle dry completely.
•
Beware of sand when changing coils on the beach.
•
Clean detector with soft, clean, lint-free microfiber cloth.
•
If dampening cloth, turn off device and disconnect from power.
•
Gently wipe screen with microfiber cloth.
remove sand from the shaft, so that it will not harm the camlock connections of the shaft.
•
Quest products are designed in California U.S.A. and produced in China by the manufacturer Quest Metal detectors Inc. Quest products are distributed and available in many European
countries. Go to www.quest-metaldetectors.eu to find your nearest dealer. Quest Europe GmbH is located in Germany and is offering customer service/after sales and technical support
for European customers.
Quest Europe GmbH
Bunde-West 37
26831 Bunde
Deutschland
info@quest-metaldetectors.eu
www.quest-metaldetectors.eu
+49 (0)4 953 7082940
EU Declaration of Conformity
Hereby, Dongguan Quest Detection Technology Co., Limited declares that this radio equipment is in compliance with directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following address: www.detectorportal.eu/compliance
* Size not to scale
Waterproof
PRO HE Headphones
Headphones
BLIZZARD9
VIBE Headphones Headphones Adaptor
Armrest
WRXB Receiver Quick Start Manual
1
2
4
1
QUICK START
2
CLICK TO
SELECT MODE
RECHARGE
BASIC TECHNICS
6
KEEP
50% OVERLAPPING
QUEST METAL DETECTORS
info@questmetaldetectors.com
QUICK START
for V80 V60
4
CLICK TO YOU ARE GOOD
3
POWER ON
TO GO NOW
GOLD
HOLD FOR
NOISE CANCELING
BEACH
CLICK ONCE TO
PINPOINT, CLICK
AGAIN TO RETURN
10 sec
OK
6-8 hrs
HOLD AND PUMP
FOR GROUND
BALANCE
VER:200111S63EN
