Quest Engineering Q35 Quick Start

UNBOXING
PRO Headphones(optional)
LITE Headphones
Waterproof Headphones WRX Receiver(optional)
(optional)
Trouble Shooting
NOT POWER ON
Please recharge the detector. Contact your dealer if you can't
recharge.
NO ALARM
The coil is not connect to the control box
VERY NOISY
Please find another place with less interference
NO SOUND
Make sure the Volume is not set to ZERO level and/or wireless
audio has been activated
FALSING WHEN
Please confirm the coil cable is not broken or avoid to hit the
SEARCHING IN GRASS
coil edge on hard objects.
OVERLOAD ALARM
Please turn to BEACH MODE if you are detecting on the beach
or high mineralized ground.
Maintenance
• Do not twist the coil tail and connector to avoid wire damage.
• Do not store the device where prolonged exposure to extreme temperatures can occur to avoid device
damage.
• Never use a hard or sharp object to operate the touch pad, or damage may result.
• Avoid chemical cleaners, solvents, and insect repellents that can damage waterproof function, plastic
components and finishes.
• Secure the audio protection cap tightly(use a coin if necessary) to prevent damage to the audio port.
• Clean the surface of detector every time after you use under water, saltwater or freshwater. Please take
off the handle from rod and allow the inside of handle dry completely each time you return from
underwater detecting.
• Pay attention to the sand when change coils on the beach. Sand will get into the connector and void
the warranty.
Clean the detector
• Wipe the device using a cloth dampened with a mild detergent solution.
• Wipe it dry. After cleaning, allow the device to dry completely.
• Use a soft, clean, lint-free cloth. If necessary, lightly dampen the cloth with water.
• If using a dampened cloth, turn off the device and disconnect the device from power.
• Gently wipe the screen with the cloth.
Q U E S T
Box Contents
Q30+
Control box
✔
11"X10" RAPTOR11 Coil
✔
O
13"X9" Coil
O
PRO Headphones
LITE Headphones
✔
Waterproof O
Headphones
O
WRX Receiver
Wire Headphones
USB Charger
✔
Elbow Band
✔
Magnetic charge cable
✔
6～8Hrs
To 3.5mm
Wire Headphones
DETECTING
QUICK START
QUICK START
Recharge
1. Connect the provided charging
cable to the USB charger.
2. Simply align the magnetic
charging head to the recharge
socket of the detector. The Li-Po
battery will not show the memory
effect, you can recharge it as you
need to. You can also use a high
quality power bank to recharge
the detector.
Audio
1.Wire headphones. Remove the
protection cap and insert the
To 6.35mm
Wire Headphones
3.5mm headphones jack.
2.WireFree headphones. Turn on
the WireFree Pro/Lite and activate
the wireless function by quick
press on Wireless button.The
blinking WireFree symbol
light up constantly.
3.Pair the WRX with the detector
ON/Vol. Up
first if you need to use a 6.35mm
jack headphones wirelessly. Just
put the WRX close to the control
OFF/Vol. Down
box and quickly turn on-off-on the
WRX until light up constantly.
GROUND
PINPOINTING
BALANCING
Model: Q35
will
