Outsunny 840-278V72 Instructions Manual

Outsunny 840-278V72 Instructions Manual

Electric awning
Hide thumbs

Advertisement

Quick Links

Download this manual
EN_Tips:Please do not use in bad weather to avoid damage.
FR_Conseils : Ne pas utiliser par mauvais temps afin d'éviter tout dommage.
ES_Consejos:No utilizar con mal tiempo para evitar daños.
PT_Dicas: Não utilizar com mau tempo para evitar danos.
DE_Tipps:Bitte nicht bei schlechtem Wetter verwenden, um Schäden zu vermeiden.
IT_Suggerimenti: non utilizzare in caso di maltempo per evitare danni.
EN_IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
FR_IMPORTANT:A LIRE ATTENTIVEMENT ET À CONSERVER POUR CONSULTATION
ULTÉRIEURE.
ES_IMPORTANTE, LEA Y GUARDE PARA FUTURAS REFERENCIAS.
PT_IMPORTANTE, RETER PARA REFERÊNCIA FUTURA: LEIA ATENTAMENTE.
DE_WICHTIG! SORGFÄLTIG LESEN UND FÜR SPÄTER NACHSCHLAGEN AUFBEWAHREN.
IT _ IMPORTANTE! CONSERVARE IL PRESENTE MANUALE PER FUTURO RIFERIMENTO E
LEGGERLO ATTENTAMENTE.
Electric awning
Instructions
IN241000382V01_UK
840-278V72
US_CA
US_CA

Advertisement

loading
Need help?

Need help?

Do you have a question about the 840-278V72 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Outsunny 840-278V72

Summary of Contents for Outsunny 840-278V72

  • Page 1 IN241000382V01_UK 840-278V72 Electric awning Instructions EN_Tips:Please do not use in bad weather to avoid damage. FR_Conseils : Ne pas utiliser par mauvais temps afin d'éviter tout dommage. ES_Consejos:No utilizar con mal tiempo para evitar daños. PT_Dicas: Não utilizar com mau tempo para evitar danos.
  • Page 2 Please prepare below tools before assembly. (Not included) ＞5m 14mm 17mm 14mm LEVELLER WARNING EN_lmproper installation and operation of your awning can result in severe personal injury. Please follow all instructions carefully or contact technical support for assistance.
  • Page 3 Before you proceed, please read the following safety precautions: -DO NOT remove the safety wrap that secures the awning arms until instructed to do so. The awning arms will spring open and can cause serious injury if handled inappropriately. DO NOT stand facing the awning when cutting off binds between arms.
  • Page 5 Step 1 Connect roller tubes "A-1" & "A-2"& "A-3"...
  • Page 6 Insert the roller tube "A-1"&"A-2" into the "A-3" and connect them with screws "S" Complete the connection to be a complete roller tube "A".
  • Page 7 Connect front bars "C-1" & "C-2"& "C-3". Insert the front bar "C-2"& "C-1" into the "C-3" and connect them with screws "S". Do not forget to tighten all the screws.
  • Page 8 Complete the connection to be a complete front bar "C". 14mm 17mm 3.5×3m---L1=120mm/L2=100mm Before connecting part "B-1" and part "B-2", please measure the length of "L" and check all the screws on the tube are tight. If the length on the "B-1" is 130mm, on "B-2" is 90mm, it's correct distance for use.
  • Page 9 Connect parts "B-1" and "B-2". Connect steel square tubes with screws "S".
  • Page 10 Plastic rope "G" should be threaded through into fabric "E" and flap "F". Roller tube A Front bar C Thread the fabric into the groove of the tube.
  • Page 11 Install part "P" into the left and right groove of roller tube. After installation, use a screwdriver to tighten the small screw on the part "P".
  • Page 12 Roll the fabric by hand in the direction of the arrow. Put parts ''J'' and ''P'' into left groove of the front tube, then tighten the screws on the "P". Insert the plug "K-1" into the front tube, a wooden hammer tool can be used to help with installation.
  • Page 13 Put parts ''J'' and ''P'' into right groove of the front tube, then tighten the screws on the "P". Insert the plug "K-2" into the front tube, a wooden hammer tool can be used to help with installation. Put the square tube "B-1" through the part "D-1". The square tube should be a little longer than the part "D-1".
  • Page 14 Insert the roller tube "A" into the part "D-1" gear box hole, then put "D-2"part into the "B-2" square tube, and make sure the roller tube "A" is also inserted into the fixing hole meanwhile. The square tube of "B-2 " should be a little longer than the "D-2" part. Please make sure the distance of left side "X"...
  • Page 15 Please tighten all the screws on the "D-1" & "D-2 " very much by wrench. This step is very important!!! Insert in Insert in Insert the Part "J" into the arm, then place the arm close to the square tube, keeping the arm parallel to the tube "B"...
  • Page 16 Make sure the product is assembled and the awning is fully closed. Untie the rope tied to the folding arm of the aluminum pipe, and the awning is assembled. Product name Retractable awning Material and surface treatment Materials: Steel tube, aluminum alloy, plastic parts, polyester fabric.

  • Page 17: Wall Mounting

    Wall Mounting Notes about Wall Mounting This awning can be secured to reinforced concrete, brick. Expansion bolt is for reinforced concrete, brick. We recommend a professional installer for the safest and most secure installation. Never attempt to secure the wall brackets to loose wall stones or any surfaces that are not absolutely firm! CAUTION Proper location of the brackets is the most important aspect of the awning...
  • Page 18 According to the size of the awning, find a suitable height on the wall. Mark the position of the wall bracket with a marker pen and then drill holes. 90 mm Install the expansion screws to secure the wall bracket firmly to the wall.
  • Page 19 Install the awning on the wall bracket while tightening the fixing screws on the wall bracket.
  • Page 21 Close the awning Stop the opening/closing of the awning Open the awning...
  • Page 22 A - Set awning opening range. B - Set awning closing range. MOTOR(Hidden inside roller) Controls Max Extension Point (A) Rotating towards the negative will reduce the amount that the awning extends Controls Max Retraction Point B) Rotating towards the negative will reduce the amount that the awning retracts.
  • Page 23 DOWN Adjustment area 14mm 17mm Lock nut 1 Adjustment bolt Lock nut 2...
  • Page 24 Lock nut 1, loosen Lock nut 2, loosen Lock nut 1, fasten Lock nut 2, fasten Lock nut 1, loosen Lock nut 2, loosen Lock nut 1, fasten Lock nut 2, fasten ME Motor Instructions Technique Specifications Motor : Power : AC220V/50HZ(110V/60Hz) Protection Index : IP 44 The motor can be compatible with 15 emitters at most Code Learning...
  • Page 25 B emitter copy learning from already learned A emitter 1)Press A emitter's 2)Press B emitter's 3)You can control the Learning button 8 Learning button once motor by B emitter. times. the motor will the motor will vibrate. vibrate. Code deleting A : Delete the emitter you are operating.
  • Page 26 1)Press emitter's 2)Press emitter's 3)The motor's Learning button six Down button once, running direction is times. the motor will vibrate. changed. Set the close limit When the motor is in still and not running, do not adjust the limits nuts. The close lirit is set.
  • Page 27 Set step by step function Note: lf the motor runs step by step, press emitter's UP or DOWN button for 3Sthe motor will run continuously. 1)Press the learning 2)Press the Up button 3)The motor will run step code once. within 10S,and the by step.
