IN231100474V01_US
IN231100474V01_US_840-264V10
EN_IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
FR_IMPORTANT:A LIRE ATTENTIVEMENT ET À CONSERVER POUR CONSULTATION ULTÉRIEURE.
ES_IMPORTANTE, LEA Y GUARDE PARA FUTURAS REFERENCIAS.
PT_IMPORTANTE, RETER PARA REFERÊNCIA FUTURA: LEIA ATENTAMENTE.
DE_WICHTIG! SORGFÄLTIG LESEN UND FÜR SPÄTER NACHSCHLAGEN AUFBEWAHREN.
IT _ IMPORTANTE! CONSERVARE IL PRESENTE MANUALE PER FUTURO RIFERIMENTO E LEGGERLO ATTENTAMENTE.
US_CA
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Outsunny 840-264V10
Summary of Contents for Outsunny 840-264V10
- Page 1 IN231100474V01_US IN231100474V01_US_840-264V10 EN_IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. FR_IMPORTANT:A LIRE ATTENTIVEMENT ET À CONSERVER POUR CONSULTATION ULTÉRIEURE. ES_IMPORTANTE, LEA Y GUARDE PARA FUTURAS REFERENCIAS. PT_IMPORTANTE, RETER PARA REFERÊNCIA FUTURA: LEIA ATENTAMENTE. DE_WICHTIG! SORGFÄLTIG LESEN UND FÜR SPÄTER NACHSCHLAGEN AUFBEWAHREN. IT _ IMPORTANTE! CONSERVARE IL PRESENTE MANUALE PER FUTURO RIFERIMENTO E LEGGERLO ATTENTAMENTE.
- Page 3 WARNING Improper installation and operation of your awning can result in Safe Installation and Operation severe personal injury as well as product failure not covered by warranty. Please follow all instructions carefully or contact technical support for assistance. 1.Never install it in high and windy places, as the sunshade may drop and hurt someone.
- Page 4 HARDWARE 16PCS 8PCS 4PCS 4PCS PARTS 3PCS...
- Page 5 A-2 X1 A-3 X1 A-1 X1 Connect roller tubes "A-1"&"A-2"&"A-3" Insert roller tube "A-1"&"A-2"into "A-3" and connect them with screws "S" Complete the connection to be a complete roller tube "A"...
- Page 6 C-1 X1 C-2 X1 C-3 X1 S X4 Connect front bars "C-1"&"C-2"&“C-3” Insert front bar "C-2"&"C-1"into "C-3" and connect them with screws "S" Do not forget to tighten all the screws Complete the connection to be a complete front bar "C"...
- Page 7 B-1 X1 B-2 X1 L2=400mm L1=450mm Before connect parts "B-1" and parts "B-2", please measurement the length of "L" and check nuts on the tube is tighten or not. The length on "B-1" and "B-2" should be change the distance as request before usage. Please check the awning size you purchased and adjust the length by yourself.
- Page 8 B-2 X1 B-1 X1 B-3 X1 S X4 Connect parts "B-1" and "B-2" Connect steel square tubes with screws "S"...
- Page 9 G X3 E X1 F X1 Plastic rope "G" should be through into fabric "E" and flap "F" Thread the fabric into the groove of the tube Roller tube A Front bar C...
- Page 10 Install part "P" into the left and right groove of roller tube After installation, use a screwdriver to tighten the small screw on part "P" Roll the fabric as the arrow direct by hand...
- Page 11 K-1 X1 J X2 P X2 K-2 X1 Put parts ''J'' and ''P'' into left groove of front tube, then Put parts ''J'' and ''P'' into right groove of front tube, then tighten the screws on the "P" tighten the screws on the "P" Insert the plug "K-1"...
- Page 12 D- X1 Put the square tube "B-1" through the part "D-1". Square tube should be a little longer than "D-1" part Insert roller tube "A" into part "D-1" gear box hole, then put "D-2" parts into "B-2" square tube, and make sure roller tube "A" also into the fixing hole meanwhile.
- Page 13 Square tube of "B-2 "should be a little longer than "D-2" parts. Please make sure the distance of left side "X" and right side "X" is always same measurement. Please tighten all the screws on "D-1"&"D-2 "very much by wrench. This step is very important!!!
- Page 14 L X2 Insert in Insert in Insert Part "J" into the arm, then place the arm close to the square tube , keeping the arm parallel to tube "B" (this is an important step!!!) Fully tighten the screw nuts Untie the rope tied to the folding arm of the aluminum pipe, and the awning is assembled.
-
Page 15: Specification
Specification Wall Mounting Notes about Wall Mounting This awning can be secured to reinforced concrete, brick. Expansion bolt is for reinforced concrete, brick. Material and Applicable wall Recommended Applicable Product name We recommend a professional installer for the safest and most secure surface treatment type installation height... - Page 16 According to the size of the awning, find a suitable height on the Install the expansion screws to secure the wall bracket firmly wall. Mark the position of the wall bracket with a marker pen and to the wall. then drill holes. La=Lb=Lc=145cm M X3 N X6...
- Page 17 T X3 Install the awning on the wall bracket while tightening the fixing screws on the wall bracket.
