Replacing The Chassis Fan - Dell Inspiron 530b Owner's Manual

2 Remove the computer cover (see "Removing the Computer Cover" on
page 107).
3 Remove the four screws securing the chassis fan.
4 Slide the chassis fan towards the front of the computer and lift it up.

Replacing the Chassis Fan

1 Follow the procedures in "Before You Begin" on page 105.
2 Remove the computer cover (see "Removing the Computer Cover" on
page 107).
3 Slide the chassis fan in place towards the back of the computer.
4 Tighten the four screws to secure the chassis fan.
1 screws (4) 2 chassis fan
Removing and Installing Parts
1
2
173
