- Page 1 Models System Indoor Outdoor FSNRP50MBNZ FINRP50MBNZ HONRP50B REFRIGERANT Pro Series Single Split Floor Console Air Conditioner Installation guide...
- Page 2 Warning Improper installation, adjustment, alteration, service and maintenance can cause property damage, personal injury or loss of life. For more information about buying, using, and servicing of Rinnai appliances call: 0800 RINNAI (0800 746 624). Rinnai New Zealand Limited 105 Pavilion Drive, Mangere, Auckland...
-
Page 3: Table Of Contents
Contents Safety messages / important information .....4 Pro Series specification summary ......6 Component description.........6 Installation overview ..........7 Positioning and clearances - indoor unit....7 Positioning and clearances - outdoor unit ....9 Indoor installation ..........10 Outdoor installation..........13 Refrigerant piping connection .......15 Evacuation ............17 Electrical and gas leak checks ......18 Test run ..............19 Installation checklist..........20... -
Page 4: Safety Messages / Important Information
Safety messages / important information This appliance is heavy, use two people or a mechanical lifting device. Improper lifting may result in serious injury. HEAVY Use two people or a mechanical lifting device For safety and warranty, appliances that are damaged MUST NOT be installed or operated under any circumstances. - Page 5 R32 refrigerant This appliance uses R32 (difluoromethane) refrigerant, which is a mildly flammable gas. R32 is classified as an A2L refrigerant in accordance with AS/NZS ISO 817, and must be handled by a qualified person with the appropriate refrigerant handling licence. Make sure to check for and rectify any refrigerant leaks after you install or repair the unit.
-
Page 6: Component Description
Floor Console specification summary Power supply 220-240 V, 1 Ph, 50 Hz Capacity 4.70 kW Input 1440 W Current 5.95 A Cooling (standard conditions) AEER 3.2504 TCSPF (hot / mix /cold) 5.769 / 5.444 / 5.828 Star (hot / mix / cold) 4.0 / 3.5 / 4.0 Capacity 5.20 kW... -
Page 7: Installation Overview
Installation overview Evacuate refrigeration system. Install the indoor unit. Install the drainpipe. Install the outdoor unit. Connect the wires. Connect the Perform a test run. refrigerant pipes. Positioning and clearances - indoor unit Required clearances 200 mm ≥100 mm ≥1000 mm 794 mm 150 mm 150 mm... -
Page 8: Positioning And Clearances - Outdoor Unit
Positioning and clearances - outdoor unit Clearances The outdoor unit must be installed in accordance with the clearances outlined below. Note maintenance access, there must be sufficient room for installation and maintenance. Wall or obstacle >100 mm Air inlet from back wall >300 mm on left Maintenance... -
Page 9: Indoor Installation
Indoor installation Select installation location Refer notes and clearances diagram on p.7. Installing the main body After loosening the screws, remove the mounting plate from the unit. Note: If the pipe comes out on the left, loosen the screws on the bottom mounting plate—not required if piping is coming out in other directions. -
Page 10: Pipe Connection
Bottom mounting plate installation - without skirting The bottom mounting plate is fixed directly to the wall. Refrigerant pipe Drain pipe Power cord Bottom mounting plate installation - with skirting Knock the bottom mounting plate straight with a tool and fix it on the skirting line. Knock straight Pipe connection Open the bottom piping cover plate. -
Page 11: Drill Wall Hole For Connective Piping
Drill wall hole for connective piping • Determine the location of the wall hole based on the location of the outdoor unit. • Using a core drill, drill a hole in the wall. Make sure the hole is drilled at a slight downward angle, so that the outdoor end of the hole is lower than the indoor end by approximately 12 mm. - Page 12 When connecting multiple drainpipes, install the pipes as illustrated Slope downward over 1/100 ≥ 10 cm (4 “) Recommended opening location of connecting pipe outlet Ø55 Drainage pipe fixing requirements: When installing the drainage pipe, fix it in place to reduce the likelihood of the pipe pulling loose from the unit.
-
Page 13: Outdoor Installation
Outdoor installation Select installation location Refer notes and clearances diagram on p.8. Install drain joint Before bolting the outdoor unit in place, you must install the drain joint at the bottom of the unit so condensate can be properly drained away so as not to cause property damage. In cold climates, make sure the drain hose is as vertical as possible to ensure water quickly drains away. - Page 14 Connect signal and power cables Before performing any electrical or wiring work, turn off the mains power to the system. All wiring must be performed in accordance with the wiring diagrams located inside the WARNING units. The signal cable enables communication between the indoor and outdoor units. You must choose the right cable size before preparing it for connection.
-
Page 15: Refrigerant Piping Connection
Refrigerant piping connection When connecting refrigerant piping do not let substances or other gases other than the specified refrigerant enter the unit. The presence of other gases or substances will lower the unit’s capacity, and can cause abnormally high pressure in the refrigeration cycle. WARNING This can cause explosion and injury. -
Page 16: Connect Pipes
Refrigerant piping connection continued Connect pipes When connecting refrigerant pipes be careful not to use excessive torque or to deform the piping in any way. You should first connect the low- pressure pipe, then the high pressure pipe. When bending connective Radius ≥... -
Page 17: Evacuation
Evacuation Air and foreign matter in the refrigerant circuit can cause abnormal rises in pressure, which can damage the unit, reduce its efficiency, and cause injury. Use a vacuum pump and manifold gauge to evacuate the refrigerant circuit, removing any residual gas and moisture from the system. Evacuation should be performed upon initial installation and when the unit is relocated. -
Page 18: Electrical And Gas Leak Checks
Electrical and gas leak checks Confirm the unit’s electrical system is safe and operating properly. Check all flare nut connections and confirm the system is not leaking. Confirm gas and liquid (high and low pressure) valves are fully open. Electrical safety checks After installation confirm that all electrical wiring is installed in accordance with the wiring diagrams on the appliance and with local regulations. -
Page 19: Test Run
Test run Perform the test run for at least thirty minutes. Connect power to the unit and press the ON/OFF button on the remote to turn it Press the MODE button to scroll through the following functions: • COOL select the lowest temperature •... -
Page 20: Installation Checklist
Installation checklist Complete the installation checklist below and make sure this is left with the homeowner. Also instruct the homeowner about the use, care, and maintenance of the system, and ensure they understand the safety instructions. Check Issues if not checked F Is the indoor unit installed securely? Dislodgement, vibration, noise F Checked for gas leaks? -
Page 21: Appendix 1: Indoor Unit Wiring Diagram
Appendix 1: Indoor unit wiring diagram | 21... - Page 22 Appendix 1: Outdoor unit wiring diagram (Single split) 16022000033970 BLACK BLUE CN 4 OPTIONAL: CN 2-1 CN 2-2 CN 2-3 DR MODEL 1(L) 2(N) CN 3 CN 23 CN 6 CN 7 CN 8 CN 2 RJ45 CN 3 OPTIONAL 4-WAY OUTDOOR MAIN...
-
Page 23: Appendix 2: Error Code Summary Indoor Unit
Appendix 2: Error code summary indoor unit Error code Error description Indoor unit EEPROM parameter error EH 00 / EH 0R Indoor / outdoor communication error EL 01 Zero crossing signal detection error EH 02 Indoor fan speed operating outside the normal range EH 03 Upper indoor fan operating outside the normal range EH 31... - Page 24 Rinnai.co.nz Tel: 0800 746 624 Floor Console installation guide http://www.youtube.com/rinnainz http://facebook.com/rinnainz 15316-A I 1-25...
