Summary of Contents for HETRONIC RX-ES-CAN-HL-DT
- Page 1 USER MANUAL RX-ES-CAN-HL-DT Release 01.2025 www.hetronic.com...
-
Page 2: Table Of Contents
1.5 Potential Sources of Danger ................................3 1.6 Security Features ................................... 4 1.7 STOP in case of EMERGENCY ..............................4 1.8 Caring for your Hetronic Product ..............................4 2. Introduction and Functional Description ..............................5 2.1 Before Operating Your Wireless Control Unit ..........................5 2.2 Product Rating Plate .................................. -
Page 3: Safety
Any modification, reconstruction or extension of the purchased machine control unit without a written consent from Hetronic automatically voids the warranty on the product. Furthermore, Hetronic, as the manufacturer and supplier of the purchased MCU assumes no liability for damages resulting from the non-observance of the safety operating instructions detailed in this user manual. -
Page 4: Security Features
Push the Emergency Stop button installed on the controlled machinery or the General Safe Stop button installed on the OCU. 1.8 Caring for your Hetronic Product The enclosure materials used in the Hetronic product have been carefully selected to minimize maintenance requirements. -
Page 5: Introduction And Functional Description
Functional Description We congratulate you on your purchase of the new Hetronic product. You have chosen a high-quality brand. Hetronic recommends you to familiarize yourself with the control unit before using it for the first time. Please carefully read the operating instructions and safety advice provided in this manual. -
Page 6: User Manual Symbol
USER MANUAL | RX-ES-CAN-HLs 2.4 User Manual Symbol The “Read User Manual” symbol on the MCU serves as a gentle reminder for users to thoroughly read through the manual before operating the radio remote control system. Always keep this manual in a safe and easily accessible place for quick reference when needed. -
Page 7: Mcu Functional Description
CU Functional Description 3.1 Operation The RX-ES-CANHL-DT operates as a typical radio decoder. Information transmitted by a Hetronic MCU is received by onboard RF module. Feedback transmission is Full Duplex mode by default. Control and feedback is also possible using CAN Cable Control through the CAN1 port, X1. - Page 8 USER MANUAL | RX-ES-CAN-HLs 3.2 CAN Message Descriptions While any transmitted CAN messages may be configured to suit the application, received CAN messages may need to be setup in particular ways for the RX-ES-CAN-HL to use them properly. For more details, please consult the CAN-HET-2 technical documentation for feedback, HDL, and RCL message formats.
-
Page 9: Pairing Ocu To Mcu
USER MANUAL | RX-ES-CAN-HLs 4. Pairing OCU to MCU Standard OCUs can be paired to a different MCU, other than the one they were delivered with from the factory using either a tethered-cable approach or through a secure wireless method. Some OCUs require the exchange of the ADMO memory key installed on the logic controller inside the OCU with new a ADMO memory pre-programmed with addresses that match those configured on the MCUs to which the OCU will be paired. -
Page 10: Technical Specifications
USER MANUAL | RX-ES-CAN-HLs 5. Technical Specifications Storage Temperature -40 °C to +85 °C Operating Temperature -20 °C to +70 °C Power Supply Voltage 9 to 33Vdc Standby Current 75 mA @ 12V CAN Bus Two channels CAN-FD Outputs Two Safety Relays rated at 6.0A / 32Vdc Auxiliary Output 750mA hold / 1.5A trip High-Side PCB Dimension... -
Page 11: Connection Diagram
USER MANUAL | RX-ES-CAN-HLs 6. Connection diagram... -
Page 12: Installing The Radio Remote Control
USER MANUAL | RX-ES-CAN-HLs 7. I nstalling the Radio Remote Control For a robust and dependable remote-control system, follow these vital recommendations. Entrust the installation of the remote control to skilled professionals exclusively. It's crucial to meticulously adhere to all safety instructions outlined in this manual — never overlook these essential guidelines. -
Page 13: Troubleshooting
If your system fails to operate following a standard start-up procedure, utilize the troubleshooting sequence provided below to identify the issue and implement necessary corrective measures. Should additional assistance be required, do not hesitate to reach out to your nearest Hetronic dealer for further guidance. PROBLEM... -
Page 14: Warranty, Service, Repair And Maintenance
This MCU is covered by a limited warranty. Please refer to the warranty card, your purchase agreement or contact your nearest Hetronic dealer for details on warranty coverage, terms, and conditions. The warranty provided with this MCU is subject to limitations and exclusions as outlined therein. -
Page 15: Regulatory Information
Substances of Very High Concern (SVHC) are not included in our products. Based on the response statements of our suppliers no materials from the ECHA are included on Hetronic products. For the latest version of the complete Declaration of Conformity please visit the Hetronic website at www.hetronic.com. -
Page 16: North America
California Proposition 65 As a designer and manufacturer of electrical and electronic products, Hetronic confirms that to the best of its knowledge at the date of this statement, none of the products supplied by it contain any of the hazardous chemicals listed on California’s Safe Drinking Water &... - Page 17 USER MANUAL | RX-ES-CAN-HLs IC Warning SED RSS-Gen Notice "This device complies with Industry Canada's licence-exempt RSSs. Operation is subject to the following two conditions: This device may not cause interference. This device must accept any interference, including interference that may cause undesired operation of the device." "Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
- Page 18 Technical information subject to change without notice. Hetronic reserves the right to discontinue, make changes to, and add improvements upon its standard products at any time without public notice or obligation. Hetronic disclaims liability for any claims or damages, whether regarding property, personal...
-
Page 19: Appendix A - Definition Of Terms
Address Module – The memory chip inside the OCU storing the OCU configuration AUTX Automatic Transmit Base address The base address is the Hetronic PC-Link assigned address of the coder Baud rate The transmission (rate) speed measured in bits per second. Frequency Channel Search Hamming distance A measurement of data transmission safety. -
Page 20: Appendix B - Safety Instructions
USER MANUAL | RX-ES-CAN-HLs Appendix B – Safety Instructions B.1 User Safety Precautions Before starting your shift, you should make sure that the equipment has a current inspection certificate and that the necessary inspections and risk assessment checks have been carried out and are up to date. Also, the equipment must be operated in accordance with the manufacturer’s instructions. -
Page 21: Safety Checklist
Instructions, manuals, and safety warnings of the manufacturers of the equipment where Hetronic products are used, Plant safety rules and procedures of the employers and the owners of the facilities where the Hetronic products are being used, Occupational Health and Safety Administration (OSHA) regulations, ...
