- Page 1 User’s Manual RX-MFS-ESCAN-HS1A...
- Page 2 Production and System Numbers Before contacting your dealer or Hetronic about service, repair or replacement parts, note the equipment Production and System numbers. These numbers are located on the silver label affixed to the unit.
- Page 3 DESCRIPTION RX-MFS-ESCAN-HS1A is an MFS 2.4GHz receiver with 2 CAN Interfaces, 2 independent E- Stop Relay Outputs, 2 Application Relay Outputs, 4 optional 0~10V, 0~20mA analog or 0~30V digital inputs, a USB and an optional RS232 interface. It shall be equipped with RTC and SD card for data logging capability.
-
Page 4: Technical Specification
TECHNICAL SPECIFICATION Operating Temperature to +70 Celsius Storage Temperature to +85 Celsius Environmental Protection IP65 Supply Voltage Range 9-24 VDC, 3A Max Jumpers J1, 2: Relay1,2 unswitched coil supply select J3: RS232 Bootloader Select J4: CAN1 termination resistor enable J5: Main controller RTC backup battery connect J7: CAN2 termination resistor enable J10: Internal 5V or External Supply for digital outputs Outputs... -
Page 5: Functional Description
FUNCTIONAL DESCRIPTION Operation As a standard Hetronic MFS receiver, this module is equipped with 2 microcontrollers, Main and Stop, for safety and redundant control of E-Stop Relay outputs. The Stop controller is common to standard 2.4GHz MFS receivers. The Main controller will have full control of RF, analog inputs, digital outputs, USB, RS232 and CAN interfaces. - Page 7 Receiver Safe Mode The following conditions cause the receiver to go into its Safe mode: • The transmitter goes into Sleep Mode • Radio signal interference • Transmitter out of operating range • E-Stop button is activated • E-Stop circuit failure •...
- Page 8 4. Depending on the application, the receiver should possibly be installed in such a manner that any connectors or cable plug holes face downwards. Consult with a Hetronic expert for best antenna mounting orientation on your application...
- Page 9 5. Should such an installation be performed on board mobile machinery or on a vehicle, then you should attach four rubber bumpers that can be ordered directly from your Hetronic dealer, unless already supplied as standard fittings on the radio control type in use. These rubber bumpers will dampen the strong vibrations coming from the machine from reaching the receiver.
-
Page 10: Troubleshooting
Troubleshooting If your ES-CAN HL receiver does not operate as required, follow the recommended troubleshooting sequence to help isolate the cause and determine corrective action. If you need more information, contact your nearest Hetronic dealer. FCC COMPLIANCE NOTIFICATIONS... - Page 11 “IC: 2119B-MFSCANHS1A” RF Exposure The Hetronic RX-MFS-ESCAN-HS1A equipment has been approved for mobile applications where the equipment should be used at distances greater than 20cm from the human body. Operation at distances of less than 20cm is prohibited and requires additional SAR evaluation.
- Page 12 L'équipement Hetronic RX-MFS-ESCAN-HS1A a été approuvé pour les applications mobiles où l'équipement doit être utilisé à des distances supérieures à 20 cm du corps humain. L'utilisation à des distances inférieures à 20 cm est interdite et nécessite une évaluation SAR supplémentaire.
