Assembly & User Instructions - Please keep for future reference
24V
The picture is for reference only. Please refer to the actual object
Important
Age: 3 Years +
Maximum user
weight: 60 kg
Important - Please read these instructions fully before assembly or use
These instructions contain important information which will help you to get the
best from your product and ensure safe and correct assembly, use, and
maintenance.
Silverado HD
24V Electric ride on 2 Seater
Official Licensed Product
Warning!
1. For family and domestic use only
2. Not to be used in traffic
3. Adult assembly required
© Kool Karz Playround - 2023
ASTM-F963
Advertisement
Table of Contents
Related Manuals for Kool Karz Playground CHEVROLET Silverado HD
Summary of Contents for Kool Karz Playground CHEVROLET Silverado HD
- Page 1 Silverado HD 24V Electric ride on 2 Seater Official Licensed Product Assembly & User Instructions - Please keep for future reference The picture is for reference only. Please refer to the actual object ASTM-F963 Important Warning! Age: 3 Years + 1.
-
Page 2: Table Of Contents
Table of Contents 1. About Your New Vehicle 2. Safety Information 3. Parts List 4. Parts Diagram 5. Assembly Steps 6. How To Operate Your Vehicle 7. Charging The Vehicle 8.Troubleshooting Guide 9. Maintaining Your Vehicle 10. Disposal Of Battery About Your New Vehicle Thank you for purchasing our products, we want your child to enjoy this product for years to come. -
Page 3: Safety Information
Safety Information WARNING! General safety: • • Adult assembly is mandatory for products that require assembly. As a parent or guardian, it is your duty to regularly inspect the tightness of screws, nuts, and bolts and make necessary adjustments. • Be mindful that this product may include small components. Ensure children are kept at a safe distance during assembly to avoid exposure to these small parts. - Page 4 Safety Information WARNING! Charging the battery: • • Ensure that only an adult is responsible for charging and recharging the battery. • Do not operate the product while it is charging. • Charging should be conducted in a sheltered, well-ventilated area. •...
-
Page 5: Parts List
Parts List PART PART PART PART REMARKS REMARKS PICTURE PICTURE NAME NAME (pcs) (pcs) Vehicle Windshield body Seat Seat Driving Motor wheel Rear Wheel Side Left Beacon mirror Side Steering Right wheel mirror Support Motor frame cover A... - Page 6 Parts List PART PART PART PART REMARKS REMARKS PICTURE PICTURE NAME NAME (pcs) (pcs) User Motor cover B manual Wrench Charger Socket battery Remote included contro Screw Assembly package M4X12 Screw Install the motor cover M4X12 Screw Install the support frame M4X12 Screw Install the seat M4X12 Screw...
-
Page 8: Assembly Steps
Assembly Steps 1. Install the rear wheels. Install the motor onto the axle, connect the wire connector firml Slide the rear wheel on to axle, followed by M8 washer and wheel nut. Tighten the wheel nut using the provided ... - Page 9 Assembly Steps 3. Install the support frame. Attach the support frame onto the car body, then tighten the screws. 4. Install the steering wheel. Remove the bolt and nut from the steering wheel. Connect the electric connectors. ...
-
Page 10: Install The Seat
Assembly Steps 5. Install the seat. Slide the seat A into the slot on the car body first, and then slide the seat B towards to seat A firmly Tighen the screws. 6. Install the side mirrors. Attach the side mirrors onto the car body, then tighten the screws. -
Page 11: Connect The Battery
Assembly Steps 7.Install the windshield and Rear Bar. Press the release button to open the hood. Attach the windshield onto the car body, then tighten the screws. Push down the rear bar until it “clicks“ into place, then push down the LED beacon until ... -
Page 12: How To Operate Your Vehicle
How To Operate Your Vehicle Use Operation( Ensure the power switch has been turned on IMPORTANT! Always stop vehicle when changing the speed or direction to avoid damage the gear box and motor. (1) Turn on the power switch (2) Forward The car will move forward when the accelerator pedal is pressed down, provided that the gear shifter is in the forward position(Power Switch must be ON). - Page 13 How To Operate Your Vehicle Media and Display Control ( 6 ) USB A Port MicroSD Card Slot 88:88 3.5mm Audio Port Display Screen Previous / Volume Down 6 7 8 Play / Pause Next / Volume Up Auto-Play function is enabled when an external USB / TF card media controller detected. Mode FUNCTIONS / FONCTIONS PREVIOUS/VOLUME DOWN:...
- Page 14 How To Operate Your Vehicle (7) How to use the remote controller: 1. Take off the battery cover on the rear side of the remote control and insert two AAA (1.5V) batteries. (Note: Batteries not includ-ed) 2. Ensure the car’s main power is turned OFF. 3.
-
Page 15: Charging Your Vehicle
Charging Your Vehicle ONLY AN ADULT CAN CHARGE AND RECHARGE THE BATTERY! Non-rechargeable batteries must not be recharged. Do not mix different types of batteries or combine new and used batteries. Ensure that batteries are inserted in the correct orientation, respecting polarity. ... - Page 16 Charging Your Vehicle WARNING! PREVENT FIRE AND ELECTRIC SHOCK: • Exercise caution not to drop the battery, as this could result in irreversible damage to the battery or serious injuries. • Prior to initiating the charging process, inspect the battery, charger, supply cord, and connectors for any signs of wear •...
-
Page 17: Troubleshooting Guide
Troubleshooting Guide ■PROBLEM: The vehicle does not run PROBLEM: The battery may be low on power. SOLUTION: After each use, or at a minimum once a month, ensure that the battery is charged for a duration of 8-12 hours. It is important not to leave the battery connected to the charger for more than 20 hours. POSSIBLE ISSUE: The thermal fuse has tripped. -
Page 18: Maintaining Your Vehicle
Troubleshooting Guide ■PROBLEM: The vehicle does not run very long. POSSIBLE ISSUE: The battery may be undercharged. SOLUTION: It is possible that the battery is not being charged for a sufficient duration. Ensure that after each use, or at least once a month, the battery is charged for a period of 8 to 12 hours. Avoid leaving the battery connected to the charger for more than 20 hours. -
Page 19: Disposal Of Battery
Disposal Of Battery Disposal Of Battery ● It is imperative to recycle or dispose of the sealed lead-acid battery in an environmentally responsible manner. ● Do not discard the lead-acid battery in a fire as it may result in an explosion or leakage. ●... - Page 20 CHEVROLET SILVERADO, all related Emblems, and vehicle body designs are General Motors Trademarks used under license to Pinghu United Vehicles Co., Ltd NOTES Kool Karz Playground Unit G2 - 20 Barnes Ct, Concord, ON L4K 4L4 1-888-383-9986 www.koolkarzplayground.com...
