Kool Karz Playground KKMB-009 Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
KKMB-009
Important
Warning!
1. Not Suitable for children under 36 months.
Choking hazard due to small parts
2. For family and domestic use only
Age: 3 Years +
3. Not to be used in traffic
Maximum user
4. Adult assembly required
weight :25Kg
5. Warning! Protective equipment should be worn
6. This toy has no brake
7
. This toy is unsuitable for children under
3 years due to its maximum speed.
8. This toy contains batteries that are
non-replaceable
Please keep this manual for future reference as it contains important information.
Before first time use, charge the battery for at least 8-12 hours, no more than 20 hours.

Advertisement

loading
Need help?

Need help?

Do you have a question about the KKMB-009 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kool Karz Playground KKMB-009

Summary of Contents for Kool Karz Playground KKMB-009

  • Page 1 KKMB-009 Important Warning! 1. Not Suitable for children under 36 months. Choking hazard due to small parts 2. For family and domestic use only Age: 3 Years + 3. Not to be used in traffic Maximum user 4. Adult assembly required weight :25Kg 5.
  • Page 2 Page 2 Page 3 Page 4 Page 5-7 Operate Page 8-12 Page 13 Page 14-15 Page 15 Page 16 Battery: Suitable age: 3+ years DC 12V4.5AH*1 Product size: Load Capacity: Under 25Kg 990*550*410 mm Optimum Material: Below 40 O C Temperature: 8-12 hours, Input: 100-240V,...
  • Page 3 screw is on it. Wheel Rear are the Wing same Rearview mirror Remote control M4X12 Instruction Spanner Manual training Cable wheel...
  • Page 5 Installation of training wheel Turn the car upside down. Remove the M4X12mm screw that has been fixed to the car body. Install training wheels. Then attach with M4X12mm screw. Install drive motor on the rear axle Load a wheel on the rear axle Load a 10# washer on the rear axle Tighten the nut with plastic wrench Add plastic wheel cover...
  • Page 6 Attach the power cable before Note: Power plugs cannot be operated in reverse Non-rechargeable batteries can not be recharged. Batteries can only be recharged under adult supervision. Rechargeable batteries should be removed from vehicle before charging. Different types of batteries or old and new batteries can not be combined. The battery should be placed in the correct polarity.

  • Page 7: Install The Steering Wheel

    Press the windshield into the body until installed. 6.Install the steering wheel Plug the cables from steering wheel as shown Insert steering wheel onto steering column Secure with steering wheel screw and Insert the hook on the mirror into the Rear view mirrors holes on both sides of the body.
  • Page 8 Step 1: open the battery cover on the back of the remote control and load into two AAA(1.5V) batteries; (dry batteries are not available in this product) Step 2: turn off the main power switch on the car; Part 3: hold down Forward and Back keys at the same time,when the Speed display light is flashing, switch the main power switch on the car, the Speed display red light should stop flashing, pairing success;...
  • Page 9 Important! Before using the vehicle for the first time, the battery needs to be charged for 8 to 12 hours, no more than 20 hours. Only an adult can charge the battery. Finish the car assembly according to the instruction steps in the manual. Ensure the battery has been plugged in and power is connected.
  • Page 10 Power Switch Forward Reverse Switch Always stop vehicle when changing the speed or direction to avoid damage between the gear box and motor. Pedal player Switch 1. Turn on the power switch first. 2. Forward ● Press the“Forward and Reverse switch” to the “Forward”position. ●...

  • Page 11: Horn Button

    HowToO era Your Vehicle 幅 ① interface: insert USB terminal, connect audio source, can play audio; ② TF card Jack: insert TF card, can play audio; ③ MP3 interface: The MP3 Aux line can be connected to other devices and play audio; ④...
  • Page 13 1. Find the charging input socket below the seat. 2. Plug the charger port into the input socket. 3. Plug the charger plug into a wall outlet. The battery will begin charging.
