Living Spaces REBA 5868-01 Assembly Instructions

Rectangular dining table

Advertisement

Quick Links

5868-01 REBA RECTANGULAR DINING TABLE
CARTON
ITEM
1
5868-01T
2
5868-01B
Packed in 2 cartons
PART
TABLE TOP x 1 PC
1
EXTENSION LEAF x 1PC
2
LEGS x 2 PCS
3
ASSEMBLY INSTRUCTIONS
15 MIN
A
B
C
D
x2
TOOLS REQUIRED
( Allen Key provided)
HARDWARE
M8 x 40 mm: 8 pcs
Ø8 x Ø13 x 1.2: 8 pcs
Ø8 x Ø19 x 2: 8 pcs
4mm x 50: 1 pc
Allen key

Advertisement

loading
Need help?

Need help?

Do you have a question about the REBA 5868-01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Living Spaces REBA 5868-01

  • Page 1 5868-01 REBA RECTANGULAR DINING TABLE Packed in 2 cartons ASSEMBLY INSTRUCTIONS TOOLS REQUIRED ( Allen Key provided) 15 MIN CARTON ITEM PART HARDWARE M8 x 40 mm: 8 pcs Ø8 x Ø13 x 1.2: 8 pcs TABLE TOP x 1 PC Ø8 x Ø19 x 2: 8 pcs 5868-01T 4mm x 50: 1 pc...
  • Page 2 STEP 1 Prepare the Table top (Part 1) by placing it upside down on a soft clean surface to protect it from scratches. Turn legs (Part 3) upside down and prepare to attach both legs to the table top. Align and tighten bolts 4 times on each leg. 4mm x 50: 1 pc M8 x 40 mm: 8 pcs Ø8 x Ø13 x 1.2: 8 pcs...
  • Page 3 STEP 3 Reposition the Extension Leaf at the center of the table and align with the rest of the table. Move both parts of the table (left and right) close to the Extension Leaf and make sure there are no gaps. TABLE LOCK TABLE LOCK Open position...
