CARTON
ITEM
1
5868-25T
2
5868-25B
5868-25 REBA ROUND DINING TABLE
Packed in 2 cartons
PART
TABLE TOP x 1 PC
1
MOUNTING PANEL x 1PC
2
BASE x 1 PC
3
ASSEMBLY INSTRUCTIONS
15 MIN
A
B
C
D
x2
TOOLS REQUIRED
( Allen Key provided)
HARDWARE
M8 x 40 mm: 12 pcs
Ø8 x Ø13 x 1.2: 12 pcs
Ø8 x Ø22 x 2: 12 pcs
4mm x 50: 1 pc
Allen key
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Living Spaces Rena 5868-25
Summary of Contents for Living Spaces Rena 5868-25
- Page 1 5868-25 REBA ROUND DINING TABLE Packed in 2 cartons ASSEMBLY INSTRUCTIONS TOOLS REQUIRED ( Allen Key provided) 15 MIN CARTON ITEM PART HARDWARE M8 x 40 mm: 12 pcs Ø8 x Ø13 x 1.2: 12 pcs TABLE TOP x 1 PC Ø8 x Ø22 x 2: 12 pcs 5868-25T 4mm x 50: 1 pc...
- Page 2 STEP 1 Detach Mounting Panel (Part 2) from table top (Part 1) before assembling the table. Unscrew and remove listed hardware with Allen Key (D) to detach Mounting Panel Unscrew bolts and hardware from all 4 corners 4mm x 50: 1 pc M8 x 40 mm: 4 pcs Ø8 x Ø13 x 1.2: 4 pcs Ø8 x Ø22 x 2: 4 pcs...
- Page 3 STEP 3 Flip base and align Mounted panel to the Table Top holes. Secure the Base to the Table Top with corresponding screws as shown in image Secure and screw all pre-drilled holes around the Mounting Panel with hardware. Repeat this step 8 times to secure to the Base.
