HIKVISION DS-3WF02-5AC/D Quick Start Manual

About this Document
● This Document includes instructions for using and managing
the Product. Pictures, charts, images and all other information
hereinafter are for description and explanation only.
● The information contained in the Document is subject to
change, without notice, due to firmware updates or other
reasons. Please find the latest version of the Document at the
Hikvision website (https://www.hikvision.com). Unless
otherwise agreed, Hangzhou Hikvision Digital Technology Co.,
Ltd. or its affiliates (hereinafter referred to as "Hikvision")
makes no warranties, express or implied.
● Please use the Document with the guidance and assistance of
professionals trained in supporting the Product.
About this Product
This product can only enjoy the after-sales service support in the
country or region where the purchase is made.
Acknowledgment of Intellectual Property Rights
● Hikvision owns the copyrights and/or patents related to the
technology embodied in the Products described in this
Document, which may include licenses obtained from third
Wireless Bridge
parties.
● Any part of the Document, including text, pictures, graphics,
etc., belongs to Hikvision. No part of this Document may be
Quick Start Guide
excerpted, copied, translated, or modified in whole or in part
by any means without written permission.
● and other Hikvision's trademarks and logos are
the properties of Hikvision in various jurisdictions.
● Other trademarks and logos mentioned are the properties of
their respective owners.
LEGAL DISCLAIMER
● TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
THIS DOCUMENT AND THE PRODUCT DESCRIBED, WITH ITS
HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS
IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES
NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE
PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL
HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL,
CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF
DATA, CORRUPTION OF SYSTEMS, OR LOSS OF
DOCUMENTATION, WHETHER BASED ON BREACH OF
CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT
LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF
THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES OR LOSS.
● YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET
PROVIDES FOR INHERENT SECURITY RISKS, AND HIKVISION
SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL
OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES
RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER,
HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF
REQUIRED.
● YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL
APPLICABLE LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR
ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE
LAW. ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS
PRODUCT IN A MANNER THAT DOES NOT INFRINGE ON THE
RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION,
RIGHTS OF PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR
DATA PROTECTION AND OTHER PRIVACY RIGHTS. YOU SHALL
NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES,
INCLUDING THE DEVELOPMENT OR PRODUCTION OF
WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY
ACTIVITIES IN THE CONTEXT RELATED TO ANY NUCLEAR
EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT
OF HUMAN RIGHTS ABUSES.
● IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT
AND THE APPLICABLE LAW, THE LATTER PREVAILS.
© Hangzhou Hikvision Digital Technology Co., Ltd. All rights
reserved.
UD39854B
Device Information
This manual is a general instruction for the entire series of
wireless bridges.
Scan the QR code below and select the desired device model to
obtain the corresponding device information.
Install Hik-Partner Pro
Scan the QR code below to install Hik-Partner Pro app, and
manege your wireless bridge remotely.
Appliable Prodeucts
This manual is applicable to Hikvision wireless bridge.
Symbol Conventions
The symbols that may be found in this document are defined as
follows.
Symbol Description
Provides additional information to emphasize or
supplement important points of the main text.
Indicates a potentially hazardous situation, which if
not avoided, could result in equipment damage, data
loss, performance degradation, or unexpected results.
Indicates a hazard with a high level of risk, which if not
avoided, will result in death or serious injury.
Safety Information
Use the attached accessory to power the device.
Install the device in the place where the maintenance
personnel can operate easily.
Disconnect the power supply when you have the device
serviced.
The temperature of the cover area will be high when the device
is working. In the circumstances, only personnel with relevant
professional knowledge, such as installation and maintenance
personnel, are allowed to operate the device.
The password strength of the device can be automatically
checked. We highly recommend you to change the password of
your own choosing (using a minimum of 8 characters, including
at least three kinds of the following categories: uppercase
letters, lowercase letters, numbers, and special characters) in
order to increase the security of your product.
We recommend you to change your password regularly,
especially in the high security system. Changing the password
monthly or weekly can better protect your product.
Proper configuration of all passwords and other security
settings is the responsibility of the installer and/or end-user.
Packing List
The figures in this manual are
for reference only.
Wireless Bridge The appearance and packing
list vary with different models.
Only some models of devices
are equipped with antenna
accessory bag.
For detailed information on
different models of devices,
please scan the QR code of the
Device Information.
Indicator
Shape 1 (Large Size)
Shape 2 (Small Size)
Port/Button
The port and button vary with different models. Scan the QR code of the Device
Information for details.
① ② ③
DC
Or
AP CPE
CPE
AP
① Reset Long press for 4 sec to restore the device to factory settings.
AP/CPE DIP Switch Switch up/down or left/right to set the device as AP or CPE.
②
SSID Switch up/down to set a 4-character SSID. The CPE will connect to the AP when its
SSID matches the AP's.
③ DC Port Use the attached power adapter to connect the DC port to socket.
④ Power Input Adaptive RJ45 port, also can be used as a PoE input port.
⑤ LAN Adaptive RJ45 port. Connect to network devices via an Ethernet cable.
⑥ Power Output Adaptive RJ45 port, also can be used as a PoE output port.
+ +
Or
PoE Power PoE Power AC
+ +
Injector Adapter Supply Cord
Regulatory
Compliance and
Quick Start Guide Cable Tie
Safety Information
Antenna Accessory Bag
Antenna Screw Set Clamp
Power Indicator
Solid Green: The device is powered on normally.
Unlit: No power supply connected or power supply
is abnormal.
LAN Indicator
Solid Green: The port is connected.
Flashing Green: The port is transmitting data. The
faster the indicator flashes, the greater the
transmission rate is.
Unlit: The port is disconnected or connection is
abnormal.
Signal Strength Indicator
Solid red, yellow, and green: The wireless signal is
strong.
Solid red and yellow, unlit green: The wireless
signal is normal.
Solid red, unlit yellow and green: The wireless
signal is weak. Please adjust the position and
direction of the device.
Unlit: The devices are not matched.
④ ⑤
6
(Standard/Passive) (Standard/Passive)
PoE/LAN PoE IN/LAN LAN PoE OUT/LAN
