  • Page 1 USE INSTRUCTIONS Ordering code：007D31 Part number：FNI MPL-236-105-M [ Technical support ] 第 1 页 共 25 页...
  • Page 2 FNI MPL-236-105-M 16 DO PNP IP67 module user manual 第 2 页 共 29 页...

  • Page 3: Table Of Contents

    Contents Security ............................5 ■ Expected use ........................5 ■ Installation and start-up ....................5 ■ Corrosion resistance ......................5 ■ Dangerous voltage ......................5 ■ General security .........................6 ......................7 Getting started guide 1.1 Module overview ......................7 1.2 Mechanical connection ....................8 1.3 Electrical connections .......................8 1.3.
  • Page 4 3.3.3 Omron NX1P2 Sysmac Studio Integrated (ECT) ............25 3.3.4 Mitsubishi FX5U Work2 Integrated (CIE) ..............26 4 Appendix ..........................27 4.1 Materials included ......................27 4.2 Order code ........................27 4.3 Ordering information ..................... 27 第 4 页 共 29 页...

  • Page 5: Security

    Security ■ Expected use This manual describes as decentralized input and output modules for connecting to an industrial network. --------------------------------------------------------------------------------------------------------------------------------- ■ Installation and start-up Precautions! Installation and start-up may only be performed by trained personnel. A qualified individual is one who is familiar with the installation and operation of the product and has the necessary qualifications to perform such operations.

  • Page 6: General Security

    General security ■ Debugging Fault Owner/operator Expected use obligations inspection If the defect or equipment failure cannot be corrected, the operation This equipment Before of the is an EMC Class debugging, equipment A compliant read the user must be product. This manual stopped to device produces...

  • Page 7: Module Overview

    1.1 Module overview 1 Mounting hole 8 Port 5 15 Port identification plate 2 Network port 2 status indicator 9 Port 7 16 Power input port 3 Network port 2 10 Port 6 17 Module indicator light 4 Power output port 11 Port 4 18 Network port 1 5 DIP switch...

  • Page 8: Mechanical Connection

    1.2 Mechanical connection The modules are connected using 2 M6 bolts and 2 washers. Isolation pads are available as accessories. 1.3 Electrical connection 1.3. 1 Power interface (L-code) Definition of power input port Definition of power output port Power port Function Description +24V(Brown)

  • Page 9: Network Interface(D-Code)

    1.3.2 Network Interface(D-code) Function Send data+ Receive data+ send data- Receive data- Note: Unused I/O port sockets must be covered with end caps to meet IP67 protection, etc. 1.3.3 I/O-port (A-code) Function +24V(Brown) Output (White) 0V(Blue) Output (Black) Normal I/O output Note: 1.

  • Page 10: Remote Module Wiring Method

    1.3.4 Remote module wiring method Independent power supply In independent power supply mode, the maximum current of each master station can reach 16A. String power supply In the serial power supply wiring mode, if the rear module needs to be connected to the front module, the cumulative current must not exceed 16A.

  • Page 11: Size

    2.1 Size 2.2 Mechanical data Shell material Die-cast aluminum housing, pearl nickel plated Housing rating according to IEC 60529 IP67 (Only in plug-in or plug type) Power interface L-Code (male and female) Input port/output port M12, A-Code (8*Female) Size(W*H*D) 65mm*222mm*25.8mm Installation type 2-Through hole mounting Ground bus accessories...

  • Page 12: Electrical Data

    2.4. Electrical data Voltage 18~30V DC，symbol EN61131-2 Voltage fluctuation ＜1% Input current when power supply <130mA voltage is 24V 2.5 Network port Port 2 x 10Base-/100Base-Tx Port connection M12，D-Code IEEE 802.3 compliant cable types Shielded twisted pair, minimum STP CAT 5/STP CAT 5e Data transfer rate 10/100Mbit/s Maximum cable length...
  • Page 13 EIP communication protocol module status Show Function Working status: The equipment is running Green light is always on normally Green light flashes 1HZ Standby: The device is not configured Flashing green, red and Self-test: The device is undergoing a power-on SF/MS/RUN green alternately test.
  • Page 14 CCIEBS communication protocol module status Show Function Green light off Module not connected Green light flashes 2.5HZ Module has no communication SF/MS/RUN Green light flashes 1HZ Module not configured Steady green Running: The device is running Closure Module works fine BF/NS/ERR Red light always on Communication error...
  • Page 15 I/O port status Status Function Closure The status of Pin4 output is 0 Yellow The status of Pin4 output is 1 The port is configured as output: Pin4 overcurrent Flashing red The port is configured as output: Pin1 overcurrent Closure The status of Pin2 output is 0 Yellow The status of Pin2 output is 1...

  • Page 16: Module Configuration

    3.1 Module configuration 3.1.1 Restoring factory settings and switching communication protocols LED indicator light PT color indicates the current protocol Serial X100 letter of number agreement ETHERNET/IP Green light — — PROFINET Orange light — — ETHERCAT Blue CIEBS White Steps: 1.

  • Page 17: Network Segment Modification

    3.1.2 Network segment modification (Only applicable to EIP, CCIEBS) 3.1.3 EtherCAT node address setting 1. Set by dialing (1~192 or 401~499) a. Switch to the EtherCAT communication protocol. The X100 dialing code is the hundreds digit of the address, the X10 dialing code is the tens digit of the address, and the X1 dialing code is the ones digit of the address.

  • Page 18: Data Mapping

    3.2 Data mapping EIP ECT PN communication protocol process output data Function description Byte Function description Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 Port7 Port6 Port5 Port4 Port3 Port2 Port1 Port0 Standard IO output Pin4 Pin4 Pin4 Pin4 Pin4 Pin4 Pin4 Pin4...
  • Page 19 EIP communication protocol configuration data Function description Byte Function description Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 Pin4 security status Port3 Port2 Port1 Port0 settings 00 = remain at 0 01 = remain at 1 Port7 Port6 Port5 Port4 10 = keep the last value Pin2 security Port3...
  • Page 20 CCIEBS communication protocol process output data Function description Byte Function Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 description Port7 Port6 Port5 Port4 Port3 Port2 Port1 Port0 Standard IO output Pin4 Pin4 Pin4 Pin4 Pin4 Pin4 Pin4 Pin4 0=off Port7 Port6 Port5 Port4...

  • Page 21: Plc Integration Tutorial

    3.3 PLC integration tutorial (The module communication protocol should be set before configuring the module, see 3.1.1 for details) 3.3.1 Siemens S7-1200 Portal Integration (PN) 1. Install the GSD file 2. In PLC---Device Configuration---Network View---Hardware Catalog, select the module and drag it in, click "Unassigned", and select the PLC to be connected;...
  • Page 22 (4) After the configuration is completed, click Download in the configuration view. 4. Assign module PN name: PLC switches to online state, select "Ungrouped Device" --- click on the module Name----Select Online and Diagnosis---Function-----Assign PROFINET device name----Select the module to be assigned in the list (should be selected based on the physical MAC)---Click "Assign Name"...
  • Page 23 3.3.2 Omron NX1P2 Sysmac Studio integration (EIP) 1. Install the EDS file: Tools---ETHERNET/IP Connection Settings---Double-click the PLC in the window---right-click the blank space of the toolbox on the right and select "Show EDS Library", click "Install" in the pop-up window, and select EDS File installation 2.
  • Page 24 (3) In the built-in ETHERNET/IP port setting window--select the second icon on the left (connection)---click "+", select the previously configured module for the target device, select EXCLUSIVE Owner for the IO type, and select the corresponding input For output, the target variable must be filled in 101,100;...
  • Page 25 3.3.3 Integration in Omron NX1P2 Sysmac Studio (ECT) 1. Install the ESI file: Double-click EtherCAT in Configuration and Settings--right-click the main device--select "Show ESI Library", and select the ESI file in the pop-up window for installation. 2. Configure the module into the EtherCAT network: Find the FieldBus Modules in the toolbox on the right and double-click the module model icon to join the network.
  • Page 26 3.3.4 Mitsubishi FX5U Work2 Integration (CIE) 1. Install the CCSP file: First open GX WORKS 3-Tools-Configuration File Management-Login-CSPP file (the project must be closed to import the file) 2. Click Project on the left - Parameters - FX5UCPU - Module parameters - Ethernet port, Basic settings - Self-node settings.
  • Page 27 6.To refresh the target, select the specified device - device name M - assign the device address - apply, and the configuration is completed! 第 27 页 共 29 页...

  • Page 28: Materials Included

    ·I/O-Block ·4 blind plugs M12 ·Ground bus ·Thread M4x6 ·20 tags 4.2. Order code FNI MPL-xxx-105-M FAS network interface Various industrial communication protocols Function 104=IP67 input module 206=IP67 output module 236=IP67 output module 302=IP67 input/output module 332=IP67 input/output module Version...
  • Page 29 第 29 页 共 29 页...
