FAS FNI ECT-506-105-M Product Use Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USE INSTRUCTIONS
Ordering code：006B31
Part number：FNI ECT-506-105-M
[ Technical support ]
1 / 31

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FNI ECT-506-105-M and is the answer not in the manual?

Questions and answers

Related Manuals for FAS FNI ECT-506-105-M

Summary of Contents for FAS FNI ECT-506-105-M

  • Page 1 USE INSTRUCTIONS Ordering code：006B31 Part number：FNI ECT-506-105-M [ Technical support ] 1 / 31...
  • Page 2 FNI ECT-506-105-M 8xIO-Link,16 DI/8 DO PNP IO Link master module user manual 2 / 31...

  • Page 3: Table Of Contents

    Contents Security ............................... 4 ■ Expected use .......................... 4 ■ Installation and start-up ......................4 ■ Corrosion resistance ......................4 ■ Dangerous voltage ......................... 4 ■ General security ........................5 Getting started guide ........................6 1.1 Module overview ........................6 1.2 Mechanical connection ......................7 1.3 Electrical connections ......................7 1.3.

  • Page 4: Security

    Security ■Expected use This manual describes as decentralized input and output modules for connecting to an industrial network. --------------------------------------------------------------------------------------------------------------------------------- ■Installation and start-up Precautions! Installation and start-up may only be performed by trained personnel. A qualified individual is one who is familiar with the installation and operation of the product and has the necessary qualifications to perform such operations.

  • Page 5: General Security

    ■General security Debugging Fault Owner/operator Expected use obligations inspection If the defect or equipment failure cannot be corrected, the operation This equipment Before of the is an EMC Class debugging, equipment A compliant read the user must be product. This manual stopped to device produces...

  • Page 6: Getting Started Guide

    1.1 Module overview 1 Mounting hole 11 Port 4 2 Network port 2 status indicator 12 Port 2 3 Network port 2 13 Port status indicator 4 Power output port 14 port 0 5 DIP switch 15 Port identification plate 6 Port 1 16 Power input port 7 port 3...

  • Page 7: Mechanical Connection

    1.2 Mechanical connection The modules are connected using 2 M4 bolts and 2 washers. Isolation pads are available as accessories. 1.3 Electrical connections 1.3. 1 Power interface (L-code) Power input port definition Power output port definition Power port Function Description +24V(Brown) Ua-* 0V(White)

  • Page 8: Network Interface (D-Code)

    1.3.2 Network Interface (D-code) Function Send data+ Receive data+ Send data- Receive data- Note: Unused I/O port sockets must be covered with end caps to meet IP67 protection, etc. 1.3.3 I/O-port (A-code) Port0~Port7definition： Function +24V (Brown) Maximum current 1A Input/output (White) 0V (Blue) Input/Output/IOLINK (Black) Port4~Port7definition：...
  • Page 9 Normal I/O PNP output PNP input 3-wire system 2-wire system Note: 1. Regarding digital sensor input, please follow the input guidance of EN61131-2, Type 2. 2. The maximum output current of each port is 2A. The total module current is <16A. 3.

  • Page 10: Master Station Module Wiring Method

    1.3.4 Master station module wiring method Independent power supply In independent power supply mode, the maximum current of each master station can reach 16A. String power supply In the serial power supply wiring mode, if the rear module needs to be connected to the front module, the cumulative current must not exceed 16A.

  • Page 11: Technical Data

    2.1 Size 2.2 Mechanical data Shell material Die-cast aluminum housing, pearl nickel plated Housing rating according to IEC 60529 IP67 (only when inserted or plugged) Power interface L-Code (male and female) Input port/output port M12, A-Code (8*Female) Size(W*H*D) 65mm*222mm*25.8mm Installation type 2-Through hole mounting Ground bus accessories Weight...

  • Page 12: Network Port

    2.5 Network port Port 2 x 10Base-/100Base-Tx Port connection M12，D-Code IEEE 802.3 compliant cable types Shielded twisted pair, minimum STP CAT 5/STP CAT 5e Data transfer rate 10/100 M bit/s Maximum cable length 100m Flow control Half working condition/full working condition (IEEE 802.3-PAUSE) 2.6 Function indicator Blue...
  • Page 13 I/O port status State Function LED1 Closure The status of Pin4 input or output is 0 LED1 Yellow The status of Pin4 input or output is 1 LED1 Red Port configured as output: Pin4 short circuit LED1 Flashing red Port configured as output: Pin1 short circuit LED1 Green IOLink is connected LED1 Flashing green...

  • Page 14: Ethercat Node Address Setting

    2.7 EtherCAT node address setting 1. Set by dialing (1~192 or 401~499) a. Switch to the EtherCAT communication protocol. The X100 dialing code is the hundreds digit of the address, the X10 dialing code is the tens digit of the address, and the X1 dialing code is the ones digit of the address.

  • Page 15: Integrated

    Show ESI Library---click "Install File" in the pop-up window---select the corresponding product ESI file Create a module: Click on the toolbox on the right---find FAS Fieldbus Modules---select product model FNI ECT-506-105-M Double-click the corresponding product to add it to the main device...
  • Page 16 Module slot data (IOLINK mode): Right-click the module---select edit module configuration---drag the required data into the module slot---if the slave station has an output signal, you need to open the master station PIN2--- Click on I/O mapping---give Digital Output Mapping_Output Pin 2 a variable----set the port Output Pin 2 that is used for output signals in the program to 1---that means the configuration is successful! 16 / 31...
  • Page 17 17 / 31...
  • Page 18 Module I/O variables: Digital Output Mapping_Output Pin 4 Digital Output Mapping_Output Pin 4 Digital Output Mapping_Output Pin 2 Digital Output Mapping_Output Pin 2 Digital Input Mapping_Input Pin 4 Digital Input Map_Input Pin 2 Digital Input Mapping_Input Pin 2 Digital Input Map_Input Pin 2 Digital Input Mapping_Actuator Shutdown Pin 4 Input pin 4 short circuit detection Digital Input Mapping_Actuator Shutdown Pin 2...
  • Page 19 Equipment process input status function description Function Name Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 description Standard IO input Port7 Port6 Port5 Port4 Port3 Port2 Port1 Port0 Input Pin 4 0=no signal Pin4 Pin4 Pin4 Pin4 Pin4 Pin4 Pin4 Pin4 1=There is signal...
  • Page 20 Module slot data (normal IO mode): Right-click the module---select edit module configuration---drag the required data into the module slot (0~7: Pro0~7 PIN4 pin function, 8~15: Pro0~7 PIN2 pin function)---Click I/O mapping---configure input and output variables for the PIN2 and PIN4 pins of the port. As shown above, Pro0~7 PIN4 is the input setting, and Pro0~7 PIN2 is the output setting, which is in the I/O variable.

  • Page 21: Integrated In Beckhofft Wincatxae

    3.1.2 Integrated in BECKHOFFT winCATXAE Here you will see an example of how to integrate this module into TwinCAT XAE, using a CX5050 PLC as an example: Add PLC path: Right-click the TwinCAT icon in the lower right corner to open Edit Routes Click Add…;Add route (Add Route Dialog) Broadcast Search- choose PLC(CX-3D0A4)-Add Route 21 / 31...
  • Page 22 Enter the default password "1" - click OK to complete adding the PLC path Add device profile: FAS FNI-ECT-506-105 (provided by FAS) Copy the file to the following path to complete adding the configuration file: C:\TwinCAT\3.1\Config\IO\EtherCAT New Construction: Open the TwinCAT XAE software---File-New-Project---Select TwinCAT XAE Project-Enter the...
  • Page 23 Select target system: SYSTEM-Choose Target System-Select PLC(CX-3DB0A4)-OK Add module: Pull down the IO option-DEVICES-SCAN; search for the master station, select Device 2 (EtherCAT)-OK 23 / 31...
  • Page 24 Module slot data (IOLINK mode): Find the module FNI-ECT-508-105-M under the resource manager, select Slots, and select the required slot data for configuration. Slots 0~7 are PIN4 functions and slots 8~15 are PIN2 functions. 模块插槽 PIN2 数据设置： 若从站模块有输出信号接入,主站模块 PIN2 必须打开,在程序里给予赋值-----组态完成！ When the variable Output PIN2 is set to 1, PIN2 is enabled.
  • Page 25 Module slave data settings (COE settings): Find the module FNI-ECT-508-105-M under the resource manager and click COE-On-line 8100:0: Master Pro 0 port data setting 8110:0: Master Pro 1 port data setting 8120:0: Master Pro 2 port data setting 8130:0: Master Pro 3 port data settings 8140:0: Master Pro 4 port data settings 8150:0: Master Pro 5 port data settings 8160: 0: Master Pro 6 port data settings...
  • Page 26 Note that the input values of Index and Subindex are in decimal, and the input and output values of Data are in hexadecimal; (2) Common index functions of FAS slave stations: Example: a. Input and output configuration: Index =65, Subindex=0; the following figure is an example of slave station configuration: Notice：...

  • Page 27: Integrated In Inovance Am600-Cpu1608Tp/Tn

    For example:The slave module DI/DO requirement is full output (FFFF) Index=65 (Known from the site manual) Subindex=0 Length=2 Data=FFFF Control=2 Enter The writing is successful and the module configuration changes to full output. 3.1.2 Integrated in Inovance AM600-CPU1608TP/TN Here you will see an example of how to integrate this module into Inproshop, taking the AM600-CPU1608TP/TN PLC as an example: Add new project: Select the corresponding PLC model for a new project...
  • Page 28 Click PLC---Check the EtherCAT master station---Select the device on the left-----right-click ETHERCAT----Scan device 28 / 31...
  • Page 29 Module slot data: Double-click the device box module FNI-ECT-508-105-M on the left ------Slot configuration------Select the required slot data for configuration Slots 0~7 are PIN4 functions and slots 8~15 are PIN2 functions. Module slot PIN2 data setting: If the slave module has an output signal connected, the PIN2 of the master module must be turned on and assigned in the program------configuration completed! When the variable Output PIN2 address is set to 1, PIN2 is enabled.

  • Page 30: Appendix

    ·4 blind plugs M12 ·Ground bus ·Thread M4x6 ·20 tags 4.2 Order code FNI ECT-50X-105-M FAS network interface Various industrial communication protocols Function 506=IP67IO-Link master module, 8IO-Link port Port~4-7 has no IO output 508=IP67IO-Link master module, 8IO-Link ports Version 105=Show version...
  • Page 31 31 / 31...
