- Page 1 USE INSTRUCTIONS Ordering code：009M31 Part number： FNI MBR-106-104-K54 [ Technical support ] 1 / 20...
- Page 2 32 DI NPN IP20 module user manual 2 / 20...
-
Page 3: Table Of Contents
Contents Security.............................4 ■ Expected use ..........................4 ■ Installation and start-up ......................4 ■ Corrosion resistance ........................4 ■ Dangerous voltage ........................4 1.Getting Started Guide ........................6 1.1 Module overview ........................7 1.2 Mechanical connection ......................7 1.3 Electrical connection ......................7 1.3.1Power interface (A-coded) ..................8 1.3.2 Network Interface (D-coded) ..................8 1.3.3 Signal port (screw-free spring-type terminal block) ..........9... -
Page 4: Security
Security ■ Expected use This manual describes as decentralized input and output modules for connecting to an industrial network. --------------------------------------------------------------------------------------------------------------------------------- ■ Installation and start-up Precautions! Installation and start-up may only be performed by trained personnel. A qualified individual is one who is familiar with the installation and operation of the product and has the necessary qualifications to perform such operations. -
Page 5: General Security
General security ■ Debugging Fault Owner/operator Expected use obligations inspection If the defect or equipment failure cannot be corrected, the operation This equipment Before of the is an EMC Class debugging, equipment A compliant read the user must be product. This manual stopped to device produces... -
Page 6: Module Overview
1.1 Module overview 1 Power supply interface 7 Sensor actuator power supply +24V 2 R485 output port 8 1-16 signal interface 3 DIP switch 9 Sensor actuator power supply 0V 4 R485 input port 10 Sensor actuator power supply +24V 5 Module status indicator 11 17-32 signal interface 6 Signal status indicator... -
Page 7: Mechanical Connection
1.2 Mechanical connection The module is installed using 4 M4 bolts or DIN35 rail snaps. 1.3 Electrical connection 1.3. 1Power interface (A-coded) Describe Function +24V(Brown) Ua-* 0V(White) +24V (Blue) Us-* 0V(Black) Power interface System power - Auxiliary power Notes: 1. It is recommended to provide US power and UA power separately. 2. -
Page 8: Signal Port (Screw-Free Spring-Type Terminal Block)
1.3.3 Signal port (screw-free spring-type terminal block) Notes: 1. Input signal types supported: three-wire NPN, two-wire NPN, dry contact; 2. Pin +24V single-channel input power supply maximum load 200mA; Common I/O NPN input 2-wire system 3-wire system 8 / 20... -
Page 9: Ip20 Module Wiring Method
1.3.4 IP20 module wiring method Independent power supply System power - Auxiliary power In independent power supply mode, the maximum current of each module can reach 4A 9 / 20... -
Page 10: Size
2.1. Size 2.2 Mechanical data Housing material Aluminum shell Housing grade complies with IEC 60529 IP20 Power interface A-Code Input port/output port Pluggable screw-free quick-connect terminals Dimensions (W*H*D) 140.5mm*92mm*50.1mm Installation type Screw fixation or DIN35 rail mounting Weight About 670g 2.3 Operating conditions Operating temperature -5°C ~ 80°C... -
Page 11: Network Port
2.5 Network port Ports 2 x 10Base-/100Base-Tx Port connections M12，D-Coded IEEE 802.3 compliant cable types Shielded twisted pair, minimum STP CAT 5/STP CAT 5e Data transfer rates 10/100 M bit/s Maximum cable lengths 100m Flow control Half-duty/full-duty (IEEE 802.3-PAUSE) 2.6 Function indicator Display Function Green, flashing... - Page 12 I/O Port Status Status Function Closed The state of the I/O pin input is 0 Yellow The state of the I/O pin input is 1 12 / 20...
-
Page 13: Module Configuration
3.1 Module Configuration 3.1.1 DIP switch setting Node address (range 1-247): In the power-off state, turn the dial to the preset node address Example: Dip switch X100=0, X10=2, X1=5 The node number is 25 Note: The maximum node number is 247. After the dial is adjusted, it needs to be powered on again to take effect;... -
Page 14: Data Mapping
3.2 Data mapping 3.2.1 Discrete inputs I1 -I32 Input coil Coil Read and Input coil Coil Read and address address Name write address address Name write bits permissions bits permissions 10201 10209 10202 10210 10203 10211 10204 10212 10205 10213 10206 10214 10207... -
Page 15: Short Circuit Overcurrent Input Status Holding Register (Read Only)
3.2.3 Short circuit overcurrent input status holding register (read only) Regi ster address bits 40049 40050 40052 40053 Regi ster address bits 40049 40050 3.2.4 Fault reset holding register (write only) Registe PLC address Number of registers Remark bits 0040H 40065 Write 005A first, then reset all faults within 500ms. - Page 16 3.2.6 Integration in Delta AS228T PLC 1. Before integrating the device into the PLC, first connect the module communication line to the COM1 port of the PLC. The corresponding relationship is A and +, B and; 2. Double-click "HWCONFIG" in the project tree; 3.
- Page 17 4. Click Device---General---COM1 Communication Interface Settings to set parameters such as baud rate and mode; 5. Click Device---Data Exchange---COM1, select Always Execute as the startup mode, and add the address to be controlled; 6. Select the added item and click "Edit" to make detailed settings; 17 / 20...
- Page 18 In the pop-up window, check "Start". Update cycle time: needs to be adjusted according to the actual number of connected slaves. Generally, the more the number, the larger the value required; Remote station number: fill in according to the module address dial; Type: Select standard MODBUS driver;...
-
Page 19: Ordering Information
4.1 Ordering Information Product Order Code Ordering code FNI MBR-106-104-K54 009M31 19 / 20... - Page 20 20 / 20...
