- Page 1 USE INSTRUCTIONS Ordering code：009M71 Part number： FNI MBR-116-006-K54 [ Technical support ] 1 / 23...
- Page 2 64 DI/DO NPN adaptive IP20 module user manual 2 / 23...
-
Page 3: Table Of Contents
Contents Security.............................4 ■ Expected use ..........................4 ■ Installation and start-up ......................4 ■ Corrosion resistance ........................4 ■ Dangerous voltage ........................4 1.Getting Started Guide ........................6 1.1 Module overview ........................6 1.2 Mechanical connection ......................7 1.3 Electrical connection ......................7 1.3.1 Power interface (A-coded) ..................7 1.3.2 Network Interface (D-coded) ..................7 1.3.3 Signal port (screw-free spring-type terminal block) ..........8... -
Page 4: Security
Security ■ Expected use This manual describes as decentralized input and output modules for connecting to an industrial network. --------------------------------------------------------------------------------------------------------------------------------- ■ Installation and start-up Precautions! Installation and start-up may only be performed by trained personnel. A qualified individual is one who is familiar with the installation and operation of the product and has the necessary qualifications to perform such operations. -
Page 5: General Security
General security ■ Debugging Fault Owner/operator Expected use obligations inspection If the defect or equipment failure cannot be corrected, the operation This equipment Before of the is an EMC Class debugging, equipment A compliant read the user must be product. This manual stopped to device produces... -
Page 6: Getting Started Guide
1.1 Module overview 1 Power supply interface 7 Sensor actuator power supply +24V 2 R485 output port 8 1-32 signal interface 3 DIP switch 9 Sensor actuator power supply 0V 4 R485 input port 10 Sensor actuator power supply +24V 5 Module status indicator 11 33-64 signal interface 6 Signal status indicator... -
Page 7: Mechanical Connection
1.2 Mechanical connection The module is installed using 4 M4 bolts or DIN35 rail snaps. 1.3 Electrical connection 1.3. 1Power interface (A-coded) Describe Function +24V(Brown) Ua-* 0V(White) +24V (Blue) Us-* 0V(Black) Power interface System power - Auxiliary power - Notes: 1. -
Page 8: Signal Port (Screw-Free Spring-Type Terminal Block)
1.3.3 Signal port (screw-free spring-type terminal block) Notes: 1. Input and output signal types supported: three-wire NPN, two-wire NPN, dry contact; 2. Pin +24V single-channel output current maximum 500mA. Module total current <4A; 3. Total current of each 8 channels (1~8, 9~16, 17-24, 25-32, 33-40, 41-48, 49-56, 57-64) <1A. Common I/O NPN input NPN output... -
Page 9: Ip20 Module Wiring Method
1.3.4 IP20 module wiring method Independent power supply System power - Auxiliary power - In independent power supply mode, the maximum current of each module can reach 4A 9 / 23... -
Page 10: Technical Data
2.1. Size 2.2 Mechanical data Housing material Aluminum shell Housing grade complies with IEC 60529 IP20 Power interface A-Code Input port/output port Pluggable screw-free quick-connect terminals Dimensions (W*H*D) 207.5mm*92mm*50.1mm Installation type Screw fixation or DIN35 rail mounting Weight About 670g 2.3 Operating conditions Operating temperature -5°C ~ 80°C... -
Page 11: Network Port
2.5 Network port Ports 2 x 10Base-/100Base-Tx Port connections M12，D-Coded IEEE 802.3 compliant cable types Shielded twisted pair, minimum STP CAT 5/STP CAT 5e Data transfer rates 10/100 M bit/s Maximum cable lengths 100m Flow control Half-duty/full-duty (IEEE 802.3-PAUSE) 2.6 Function indicator Display Function Green, flashing... - Page 12 I/O Port Status Status Function Closed The state of the I/O pin input or output is 0 Yellow The state of the I/O pin input or output is 1 12 / 23...
-
Page 13: Integrated
3.1 Module Configuration 3.1.1 DIP switch setting Node address (range 1-247): In the power-off state, turn the dial to the preset node address Example: Dip switch X100=0, X10=2, X1=5 The node number is 25 Note: The maximum node number is 247. After the dial is adjusted, it needs to be powered on again to take effect;... -
Page 14: Data Mapping
3.2 Data mapping 3.2.1 Output coil A1 -A16 Coil Coil Read and Coil Coil Read and address address Name write address address Name write bits permissions bits permissions 00101 00109 00102 00110 00103 00111 00104 00112 00105 00113 00106 00114 00107 00115 00108... -
Page 15: Discrete Inputs I1 -I16
00149 00157 00150 00158 00151 00159 00152 00160 00153 00161 00154 00162 00155 00163 00156 00164 3.2.2 Discrete input I1 -I64 Input coil Coil Read and Input coil Coil Read and address address Name write address address Name write bits permissions bits permissions... -
Page 16: Coil Output Holding Register (Readable And Writable)
10237 10245 10238 10246 10239 10247 10240 10248 Input coil Coil Read and Input coil Coil Read and address address Name write address address Name write bits permissions bits permissions 10249 10257 10250 10258 10251 10259 10252 10260 10253 10261 10254 10262 10255... -
Page 17: Short Circuit Overcurrent Input Status Holding Register (Read Only)
30035 30036 3.2.5 Short circuit overcurrent input status holding register (read only) Regi ster address bits 40049 40050 40052 40053 Regi ster address bits 40049 40050 40052 40053 3.2.6 Fault reset holding register (write only) Register PLC address Number of Remark bits registers... -
Page 18: Parameter Holding Register (Read Only)
3.2.7 Parameter holding register (read only) Register PLC address Function Value Remark bits range 0050H 40081 Device address 1-254 0: Broadcast address 0051H 40082 Baud rate index value 0052H 40083 Parity index value 0053H 40097 Product model 71:Indicates 009M71 0054H 40101 Software 102001:V1.2.1... -
Page 19: Integrated In Delta As228T Plc
3.2.8 Integration in Delta AS228T PLC 1. Before integrating the device into the PLC, first connect the module communication line to the COM1 port of the PLC. The corresponding relationship is A and +, B and; 2. Double-click "HWCONFIG" in the project tree; 3. - Page 20 4. Click Device---General---COM1 Communication Interface Settings to set parameters such as baud rate and mode; 5. Click Device---Data Exchange---COM1, select Always Execute as the startup mode, and add the address to be controlled; 6. Select the added item and click "Edit" to make detailed settings; 20 / 23...
- Page 21 In the pop-up window, check "Start". Update cycle time: needs to be adjusted according to the actual number of connected slaves. Generally, the more the number, the larger the value required; Remote station number: fill in according to the module address dial; Type: Select standard MODBUS driver;...
-
Page 22: Appendix
4.1 Ordering Information Product Order Code Ordering code FNI MBR-116-006-K54 009M71 22 / 23... - Page 23 23 / 23...
