Ecosoft MO 3 400 P ECO Installer And User Manual

Installer and user guide for
domestic reverse osmosis filter
Please, find model of your filter on enclosure
MODEL DESIGNATIONS
Models MO X YYY ZZZZ AAA BBB
MO 3 400 P ECO
MO — The type of filter. RO stands for reverse osmosis
MO 3 600 P ECO
X — Number of stages
MO 3 600 M P ECO
YYY — Capacity of reverse osmosis membrane in GPD (gallons per day)*:
400GPD 1 440 liters per day
600GPD 2 160 liters per day
* Capacity of the reverse osmosis filter is variable and depends on a number of factors. These include supply water
quality, wear of pre-filter cartridges and of membrane itself, supply water pressure and temperature.
ZZZZ — Legend of additional equipment (no letters specify base model with no extra equipment):
M The filter is equipped with mineralizing post-filter
P** The filter is equipped with pressure booster pump
AAA — Trademark
For example: MO3600MPECO means reverse osmosis unit with 3 stages equipped with membrane
of 600 gallon per day capacity (90 l / h), mineralizing post-filter and booster pump. Trademark
Ecosoft.
** Models equipped with a pressure booster pump (marked with the letter «P» in the model designation), are intended
for connection to the single-phase AC power with a voltage of 230 V, 50 Hz.
The filter is equipped with a power cord with a plug and should be connected in the proper type
of socket with grounding complying with the local standards. Electrical safety notice: this appliance
should be connected into a circuit with an RCB installed Before performing any operations system
must be disconnected from the electric power source.
CAUTION!
Filter installation should be carried out by a specialist with appropriate
qualifications and experience.
The product should only be used with cold water supply!
SPECIFICATIONS AND REQUIREMENTS
Parameter
Main pressure, bar
Feed water temperature, °C
Flow capacity, l/min
Electrical rating
Power, W
Weight of the system, kg
Ambient temperature, °C
Water supply connection
Filter dimensions, H × W × D, mm
* If supply water pressure is below required value, purchase pumped model or fit your existing filter with booster pump.
If the pressure in the water system is above the limit, it is necessary to install a pressure regulator on the main pipe. If
pressure in tank bladder is outside this range, it is necessary to pump up or release the pressure until it conforms to
the requirement.
** If supply water temperature is up in the range of +20...+30 °C, rejection of impurities will be decreased and system
capacity increased, bringing about an increase in TDS. Using the product with supply water temperature in excess of
+30 °C is not recommended.
SUPPLY WATER QUALITY REQUIREMENTS*
Index Value**
pH 6.5–8.5
TDS <1500 ppm
Hardness <500 ppm CaCO (<28 °dH)
3
Free chlorine <0.5 ppm
Iron <0.3 ppm
Do not use with water that is microbiologically unsafe or of unknown quality without
adequate disinfection before the system.
* If water supply does not meet the requirements, service life of membrane and/or pre-filter cartridges may be
shortened.
** If your home is supplied with raw well water, perform laboratory test of your water before in- stalling a reverse
osmosis filter. If any of your water indices exceed the limit, consider using a water treatment system to correct supply
water quality. Refer to water treatment specialists or companies for advice and proper equipment selection.
WATER QUALITY AFTER FILTER*
Index Value
pH 5.5–6.5
TDS 5–15 ppm
Calcium <2 ppm
Magnesium <1 ppm
Sodium + Potassium <5 ppm
QUALITY OF MINERALIZED WATER MO3600MPECO*
Index Value
pH 6.5–7.7
TDS 40–70** ppm
Calcium 4–6 ppm
Magnesium –
* Values are determined under the following conditions: temperature of supply water is 20 °C (68 °F), supply water
quality and operation conditions correspond to manufacturer's requirements, water consumption as typical for a family
of three. As the temperature of supply water drops in winter, the minerals content may be lower, and with increasing
temperature in summer — higher.
** After standby for one hour or more the content of minerals in the first glass of purified water may be higher than
the specified values, as more minerals can dissolve during this period. This is normal and does not impair the quality
of the purified water.
60 liters per hour
90 liters per hour
MO3400PECO MO3600PECO MO3600MPECO
2–5*
+5...+30**
1 1.5
230 V, 50 Hz
120
11
+5...+40
⅜" thread
435 × 140 × 458
Index Value**
Manganese <0.1 ppm
Chemical oxygen demand <5 ppm O
Total bacterial count (TBC) <50 CFU/mL
E. coli titer <3
* Values are determined under the following conditions:
temperature of supply water is 25 °C, supply water quality and
operation conditions correspond to manufacturer's requirements.
Please note!
Changes in the taste and odor of purified
water after replacing the carbon post-filter and
mineralizer are due to the maximum capacity of
the filter material at the beginning of the cartridge
life. During the operation of the cartridges, the
mineralization and organoleptic characteristics of
the water gradually decrease.
Follow the maintenance schedule for your filter to
ensure consistent quality of treated water.
REVERSE OSMOSIS FILTER COMPONENTS
1) Filter rack
4) Feed water adapter
with valve
Code: MO3400PECO
CF — CPVDFRO
RO — CSVRO400DFRO
CB — CHVCBDFRO
7) Set of cartridges
The manufacturer reserves the right to modify product design or specific components if such
modification does not entail deterioration of consumer properties of the product.
1.5
ENVIRONMENTAL AND HEALTH SAFETY
The product does not have any chemical, radiological, electrochemical impact on the environment. The
product is not regarded as hazardous by their impact on the human body, meets requirements of relevant
sanitary legislation for its intended scope of use.
PURCHASING
Desirably, the product should be purchased from authorized sales establishments. When buying, check
integrity of packaging, absence of mechanical damage and other defects, contents of the system (without
opening the plastic bags), availability of user documentation, particularly this manual.
TRANSPORTATION AND STORAGE
Shipping of the product may take place by any means of transport (except unheated during cold seasons
in colder climates) in accordance with the rules of transportation of goods, applicable to each type of
transport. Observe handling labels when handling and shipping the product. Product should be stored
indoors with protection from mechanical damage, impact of moisture and aggressive chemicals. Store
this product in the manufacturer' s original packaging at ambient temperatures ranging from 5 °C to 40 °C
(from 41 °F to 104 °F) and relative humidity up to 80%, at least 1 m (3.3 ft) away from heating equipment.
WARRANTY
2
We thank you for purchasing a reverse osmosis product by Ecosoft Company.
We hope that this product will serve you long and let you and your family enjoy high quality pure drinking
water.
Warranty period is 12 months from the date of purchase from a retail establishment (unless otherwise
specified in the product warranty card). The manufacturer guarantees that the water purification system
does not contain workmanship defects and no such defects will arise within warranty period from the date
of purchase from store provided that the technical requirements and operating conditions specified in this
manual are strictly adhered to.
To avoid misunderstanding, we urge you to carefully read the instructions on installation and operation
of the reverse osmosis system, warranty conditions liabilities, check correctness of the warranty card,
presence of proof of purchase (receipt, invoice, or bill). Warranty card is valid only if model, date of
purchase, and stamp of selling establishment are correctly specified. For proper installation details please
read instructions on how to install and use or seek help from a qualified professional. The manufacturer is
not liable for any damage to property or some other damage, including lost profits, which arose by chance
or due to use or inability to use this product. Manufacturer' s liability in accordance with this warranty is
limited to the cost of the filter.
WARRANTY CARD
Name of product:
Name and stamp of the dealer:
Date of sale:
If you have any questions or
concerns when installing, operating
or maintaining your reverse osmosis
system, call our toll free number:
0 800 30 10 21
or visit www.ecosoft.com
When you call, please be prepared
to provide the model, date code and
serial number of your product.
2) Power adaptor 3) Drinking water faucet
- with light indication for models
MO3600PECO and MO3600MPECO
- without light indication for model
MO3400PECO
5) Set of colored tubes 6) Drain saddle
Code: MO3600PECO Code: MO3600MPECO
CF — CPVDFRO CF — CPVDFRO
RO — CSVRO600DFRO RO — CSVRO600DFRO
CB — CHVCBDFRO MCB — PDCBDFRO
Manufacturer
Ecosoft SPC LTD
1ї, Pokrovska str., Irpin,
Kiev Oblast, 08200, Ukraine
