- Page 1 MODEL: SIH60 V 1.0 | 1224 User Manual 60cm Integrated Extractor Hood Grey...
- Page 2 UK. Please refer to the warranty card at the rear of this manual for information regarding your product’s parts and labour warranty, or visit us online at w w w ww w . . solt.house Sôlt —...
- Page 3 1 Introduction Congratulations on the purchase of your new product. You have bought a high quality product. These instructions are part of this product. They contain important information regarding safety, use and disposal for the installer and user of the product. Please familiarise yourself with all information prior to using your product.
- Page 4 • Always check the power level selected on the cooker hood before turning on the appliance. If possible, always use the cooker hood with the switch in the “I” position. This setting is generally sufficient in the majority of cooking situations. •...
-
Page 5: Safety Instructions
3 Safety instructions Please take the time and read these general safety instructions carefully. Follow all the instructions. This will help you avoid the risk of fire, explosions, electric shocks or other hazards that may result in damage to property and/or severe or fatal injuries. Please ensure that everyone who uses the appliance has read and followed these warnings and instructions. - Page 6 • Protect the mains adapter from use by third parties (particularly children). Keep the mains adapter in a dry, elevated or locked location away from children. • The appliance may only be installed by a qualified and trained electrician. • Check the appliance and cable for any damage before installation.
- Page 7 • Never leave naked flames under the cooker hood to avoid overheating. • Always put lids on pots and pans when cooking on a gas cooker. • Do not use the cooker hood without the filters or when the filters are excessively greasy.
- Page 8 • Make sure the ducting has no bends sharper than 90 degrees as this will reduce the efficiency of the cooker hood. • When the cooker hood and other appliances supplied with energy other than electricity are simultaneously in operation, the negative pressure in the room may not exceed 4 Pa (4 x 10-5 bar).
-
Page 9: Installation
4 Installation • The appliance may only be installed by a qualified and trained electrician. • Before you install the appliance, you should check it for damage. If damage has occurred during transport, please inform the manufacturer immediately. The appliance has been tested to ensure proper functioning before delivery. - Page 10 Drawing for the hood INSTALLATION Important: Do not connect the power cable until the installation is complete! Recommends installing in a team of at least two people to avoid injuries. They typical installation method for your undermount rangehood is into a purpose built overhead/wall cabinet.
- Page 11 1.2. Use the pencil to draw the hole on the wall or cabinet, and then install the wall plug on the wall or cabinet. 1.3. Attach the hood onto the wall or cabinet with two screws.
- Page 12 1.4. Open the cover, and install the screws onto the safty holes 2. Install the wooden board into the metal panel 2.1. It need to make the wooden board size not over than 514*316*18mm 2.2. Open the metal panel...
- Page 13 2.3. Take out the screws from right and left side support kit(which one is connect the front metal panel) total 8pcs. 2.4. And then can take out the metal panel, after take it out, can install the wooden board onto the panel take out the metal panel...
- Page 14 2.5. Take out the screws from the metal panel, and all connect part's screws. screws Install the wooden board onto the metal panel with screws, as the drawing. Screws. Remark: it's back side not the front side...
- Page 15 2.6. After install the wooden board on the metal panel, and then can re-install the panael onto the hood. Put the panel onto the bracket Install 8 pcs screws , connect the panel and support kit, right & left side...
- Page 16 2.7.Fix the one-way valve to the air outlet of the rangehood. Then attached the exhaust pipe onto the one-way-valve as shown below. Remark: The pipe is not included. The hood with inside recycle, just install the one-way-valve & charcoal filter is The hoow if with outer recycle, it need to buy an extra exhaust pipe, after install the one-way-valve, you need to install the exhuaust pipe on it, as below pic.
-
Page 17: Using The Cooker Hood
Press the symbol. The light will turn on. NOTICE Only switch on the lights when operating the appliance. Do not switch on the lights to lighten up the room. Control for SIH60 Press to turn on/ off the cooker hood. - Page 18 PRODUCT FICHE Symbol Value Unit Model identification SIH60 kWh/a Annual Energy Consumption AEC h 29.2 Time increase factor Fluid Dynamic Efficiency 12.7 hood Fluid Dynamic Efficiency class Class E Energy Efficiency Index 65.9 hood Energy Efficiency class Class B Measured airflow rate at the best...
-
Page 19: Maintenance And Cleaning
Maintenance and cleaning Cleaning the appliance • Make sure you switch off the appliance. • Unplug the power supply before cleaning the appliance. • Always let the appliance and its components cool down before cleaning them. • Do not use wipes, chemicals or alcohol as these could damage the surface. -
Page 20: Replacing The Active Carbon Filter
Clean the mesh filters. Monthly (see Cleaning the mesh filters) Clean the active carbon filter. Every 3 to 6 months (see Replacing the active carbon filter) Cleaning the mesh filter To clean the mesh filters: Remove a mesh filter. To clean the filter, do one of the following: • Cleaning manually (max. 30 °C): Soak the filter for about 3 minutes in water with a mild non-corrosive grease-removing detergent. - Page 21 To replace the active carbon filter: Disconnect the power supply from the wall socket. Remove the mesh filter(s). Replace the active carbon filters on both sides of the motor. NOTICE Turn left to remove a previously installed carbon filter. Turn right to place a carbon filter on the motor. Turn the filter slightly to the left or pull it carefully until the filter is installed properly. Match the brackets of the filter with the holding mechanism of the motor and pull carefully until the filter locks. Place the mesh filter. Connect the power supply to the wall socket.
-
Page 22: Troubleshooting
Troubleshooting Problem finding • Only a qualified electrician may carry out any electrical repairs. All local regulations must be followed. Contact the manufacturer in case of any doubts. • Unplug all power connections before opening the appliance. Cause Error Solution The light can be Fan switch turned off Put the on/off switch in the switched on but the “I”... -
Page 23: Replacing The Lamp
Replacing the lamp • Only a qualified electrician may replace the lamp. • Unplug all power connections before opening the appliance. • Risk of burning! Always let the lamp cool down before replacing it. • Always use gloves or a cloth to avoid direct contact with your hands. Direct contact may reduce the lifespan of the lamp. -
Page 24: Notes On Environmental Protection
NOTES ON ENVIRONMENTAL PROTECTION -During cooking, make sure that there is sufficient air supply so that the cooker hood can operate efficiently and with low operating noise. -Adjust the fan speed to the amount of steam produced during cooking. Use the intensive mode only when necessary. - Page 25 Solt Service: T. 01759 48 78 26 E. admin@appliancesupport.co.uk Online. www.appliancesupport.co.uk/solt www.solt.house...
