Installation & Use Manual
HydroBoost
Installer
To assure you install this model easily and correctly, PLEASE READ THESE
SIMPLE INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK
YOUR INSTALLATION FOR COMPLIANCE WITH ALL PLUMBING, ELECTRICAL
AND OTHER APPLICABLE CODES. FOLLOW ALL WARNINGS AND CAUTIONS
CAREFULLY. After installation, leave these instructions with the customer for future
reference.
Warnings
1. Use with clean, clear, fresh potable drinking water only! Do not use with water that is microbiologically
unsafe or of unknown quality without adequate disinfection before the system.
2. Connect Power Cord only to a grounded three prong electrical outlet with electrical power that:
a. MUST be rated for this product as specified on product data label.
b. MUST have over-current protection (e.g. Fuse, Breaker).
c. MUST have Ground Fault Circuit Interrupt protection (GFCI).
d.
These products are designed to operate on 20 to 105 PSI supply line pressure. If inlet pressure is
above 105 PSI, a pressure regulator must be installed in supply line. Any damage caused
by reason of connecting this product to supply line pressure lower than 20 PSI or higher than
105 PSI is not covered by warranty
Patent zurn-elkay.com/patents
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov
AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov
HTHBSM-1A, HTHBSM-2A, HTHBSMWF-1A, HTHBSMWF-2A
Surface Mount Bottle Filling Station
®
Model
HTHB-WF
.
IMPORTANT
THIS IS AN INDOOR APPLICATION ONLY!
ALL SERVICE TO BE PERFORMED BY AN
AUTHORIZED SERVICE PERSONNEL.
TOOLS/ITEMS REQUIRED
BUT NOT SUPPLIED
- SERVICE STOP VALVE WITH 3/8"
COMPRESSION OUTLET
- FASTENERS FOR WALL TYPE (8 REQ'D.)
- SLIP JOINT DRAIN UNION OR
COMPRESSION CLAMP
- 5/32" HEX-WRENCH
Page 1
2000000501 (Rev. B - 04/23)
Advertisement
Table of Contents
Related Manuals for Halsey Taylor HydroBoost HTHBSM-1A
Summary of Contents for Halsey Taylor HydroBoost HTHBSM-1A
- Page 1 HTHBSM-1A, HTHBSM-2A, HTHBSMWF-1A, HTHBSMWF-2A Installation & Use Manual HydroBoost Surface Mount Bottle Filling Station ® IMPORTANT THIS IS AN INDOOR APPLICATION ONLY! ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSONNEL. TOOLS/ITEMS REQUIRED BUT NOT SUPPLIED - SERVICE STOP VALVE WITH 3/8" COMPRESSION OUTLET - FASTENERS FOR WALL TYPE (8 REQ’D.) - SLIP JOINT DRAIN UNION OR...
- Page 2 HTHBSM-1A, HTHBSM-2A, HTHBSMWF-1A, HTHBSMWF-2A ROUGH-IN HTHBSM, HTHBSM-220V, HTHBSM-WF, HTHBSM-WF-220V 17 15/16" 455mm 8 3/16" 208mm 7" 7" 178mm 178mm 5 3/8" 136mm ACTIVATION SENSOR 9 1/2" 241mm D OPTIONAL (3 PL) 25 7/16" DRAIN TRAP 647mm 2 7/8" CUSTOMER 73mm SUPPLIED 12"...
- Page 3 HTHBSM-1A, HTHBSM-2A, HTHBSMWF-1A, HTHBSMWF-2A INSTALLATION INSTRUCTIONS Pre-Installation (reference Rough-In, Fig. 1, Page 2) 1. Ensure Wall is structurally sound to bear the loads imparted by the HydroBoost Surface Mount Bottle Filling ® Station (On-Wall Bottle Filler). If necessary, install a Wall Support Carrier (not supplied). 2.
- Page 4 HTHBSM-1A, HTHBSM-2A, HTHBSMWF-1A, HTHBSMWF-2A Plumbing Connections • Ensure lines and ports remain clean and free of contaminants during assembly. • Purge each component if necessary. • To ensure quick-connect connections seal properly, follow instructions per Fig. 2, Page 2. Connect Plumbing Lines 1.
- Page 5 HTHBSM-1A, HTHBSM-2A, HTHBSMWF-1A, HTHBSMWF-2A BF9 PROGRAM SETTING THE CONTROL BOARD VERIFY CONTROL BOARD SOFTWARE SETTING UNIT TYPE 1) To verify the software program of the control board the unit will 1) Depress the program button for approximately 2 seconds need to be shut down and restarted. The chiller (if present) does not until the display changes then release.
- Page 6 HTHBSM-1A, HTHBSM-2A, HTHBSMWF-1A, HTHBSMWF-2A BF11 - BF12 PROGRAM SETTING THE CONTROL BOARD VERIFY CONTROL BOARD SOFTWARE Continued from below: 1) To verify the software program of the control board the unit will 2) When the display changes to “SETTINGS”, depress the button again. need to be shut down and restarted.
- Page 7 HTHBSM-1A, HTHBSM-2A, HTHBSMWF-1A, HTHBSMWF-2A WATERSENTRY PLUS FILTER PARTS LIST ® (See Fig. 3) ITEM PART NO. DESCRIPTION 55898C Filter Assy - 3000 Gallon 1000005553 Filter Head Assy. Bottom Power Cord 70792C Screw-#8-18 X .75 PHHL Cover Clamp 3/8” Water Inlet Bushing Screw 220V POWER CORD DETAIL...
