DUCTED SYSTEM
R-32 Series
MODELS
(Ceiling concealed duct type)
FDYAN50/60/71/85/100/125/140/160AV1
FDYA71/85/100/125/140/160AV1
FDYUAN71/125/160AV1
FDYUA71/125/160AV1
FDYA71/85/100/125/140/160AV19
FDYUA71/125/160AV19
FDYAN & FDYA Series cannot be install underfloor,
Please use FDYUAN & FDYUA series only for underfloor installation.
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION.
KEEP THIS MANUAL IN A HANDY PLACE FOR FUTURE REFERENCE.
OPERATION MANUAL
IMPORTANT NOTE:
Air Conditioners
Advertisement
Table of Contents
Related Manuals for Daikin FDYAN Series
Summary of Contents for Daikin FDYAN Series
- Page 1 OPERATION MANUAL DUCTED SYSTEM R-32 Series Air Conditioners MODELS (Ceiling concealed duct type) FDYAN50/60/71/85/100/125/140/160AV1 FDYA71/85/100/125/140/160AV1 FDYUAN71/125/160AV1 FDYUA71/125/160AV1 FDYA71/85/100/125/140/160AV19 FDYUA71/125/160AV19 IMPORTANT NOTE: FDYAN & FDYA Series cannot be install underfloor, Please use FDYUAN & FDYUA series only for underfloor installation. PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION. KEEP THIS MANUAL IN A HANDY PLACE FOR FUTURE REFERENCE.
-
Page 3: Safety Considerations
Be sure to use separately sold component parts cold air. Your physical condition may deteriorate. designated by Daikin. Incomplete installation performed by yourself • This product contains Refrigerant Type: R32. may result in a water leakage, electric shock or fire. -
Page 4: Table Of Contents
Operation Manual CAUTION • • Never operate the air conditioner without the return air filter(s) in Do not use the air conditioner for other purposes. Do not use the air place. Operating the unit without the filter(s) will allow dust to enter the conditioner for special applications such as storage of foods, animals and indoor unit and build up on the heat exchanger coil and fan motor. -
Page 5: Controllers
Operation Manual CONTROLLERS This equipment can operate with a variety of Daikin Controllers. Please refer to the Operation Manual supplied with your controller. WHAT TO DO BEFORE OPERATING YOUR SYSTEM FOR THE FIRST TIME • Ensure that there are no obstacles near the air outlet of the outdoor •... -
Page 6: Trouble Shooting
Measure: Write down the fault code and then stop the operation. This is the noise of refrigerant stopping or changing direction. Measure: Notify your Daikin dealer and inform him/her of the display. DUST FROM THE AIR CONDITIONER • Dust may blow out from the unit when starting the air conditioner If the system does not operate properly and none of the above after a long resting time. -
Page 7: Maintenance
The air filter(s) and the suction grille(s) are supplied by your dealer. Ask your DAIKIN dealer how to clean them. Ensure the drain piping from the indoor unit is free of blockage. During cooling operation, water should drip from the outlet of the indoor HOW TO CLEAN AIR OUTLET GRILLE unit’s drain piping. - Page 8 Phone: 1300 368 300 Technical Support & Spare Parts 200 Governor Macquarie Drive, Warwick Farm, NSW 2170 Phone: 1300 362 438 Daikin New Zealand, 25 Dalrymple Road, Garbutt, 4814. www.daikin.com.au DAIKIN INDUSTRIES LTD. Head office: Umeda Centre Bldg., 2-4-12, Nakazaki-Nishi,...
