ProArc TR-0103 Owner's Manual

Turning roll
Hide thumbs Also See for TR-0103:
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
RD-8468CE
Important：Read these instructions before installing, operating or servicing this product.
Model：TR‒0103
Turning Roll
Serial number：2407012 ~ and later
Date : Aug. 07, 2024
UNITED PROARC CORPORATION
No.8 Gungye 2nd Road, Pingjen Industrial Park,
Tel No：886 3 4696600
Fax No ： 886 3 4694499
Pingjen Dist., Taoyuan City 324403, Taiwan
http://www.proarc.com.tw
E-Mail：sales@proarc.com.tw

Advertisement

loading
Need help?

Need help?

Do you have a question about the TR-0103 and is the answer not in the manual?

Questions and answers

Related Manuals for ProArc TR-0103

Summary of Contents for ProArc TR-0103

  • Page 1 Important：Read these instructions before installing, operating or servicing this product. Model：TR‒0103 Turning Roll Serial number：2407012 ~ and later Date : Aug. 07, 2024 UNITED PROARC CORPORATION No.8 Gungye 2nd Road, Pingjen Industrial Park, Tel No：886 3 4696600 Fax No ： 886 3 4694499 Pingjen Dist., Taoyuan City 324403, Taiwan http://www.proarc.com.tw...

  • Page 2: Safety Precautions

    TABLE OF CONTENTS Introduction Safety precautions ..................i Specification 1.1 Specification ....................1 Operator controls 2.1 Control panel ....................2 Adjustment 3.1 Main wheel adjustment procedure ............. .3 4.1 Parts list – Turning rolls ................4 Part list 4.2 Parts list – Idler rolls ................... 5 4.3 Parts list –...

  • Page 3: Specification

    1.1 SPECIFICATION Model Unit TR-0103 Input power 1Ø 100~240VAC 50/60Hz Drive motor 1/12 Overall length (A) (Drive / Idler) 470 / 450 Overall width (B) (Drive / Idler) 320 / 160 Overall height (C) (Drive / Idler) Diameter range (D) Ø...

  • Page 4: Operation Panel

    2.1 OPERATION PANEL A. Operation Penal Stop button. Power socket. Forward / Reverse switch. Speed adjustment knob. Foot switch. Power cord. B. Operation 1. Power cord. Connect power to 100V~240VAC single phase power. 2. Power switch. (SW1) I = On，O = Off 3.
  • Page 5 3.1 MAIN WHEEL ADJUSTMENT PROCEDURE Step 1： Start the machine, then adjust the speed to 50%. Step 2 ： Use 17mm wrench and adjust the nut in clockwise direction until the PU roller moves. Step 3 ： Press the rollers with approximate 20-30 kg pressure and check for any slip on the PU rollers.
  • Page 6 4.1 PARTS LIST ― TRUNING ROLL Q’ty. Item. Part No. Description Remark 5118-02271103030-10 Axle screw 0121-2000 Washer ＊ 5041-1030000-10 PU Wheel with bearing 5041-1030100-10 PU Wheel ＊ 0301-0403 bearing 5118-02271103040-10 Spacer 0123-2000 Hex Nut 5041-1020000-10 Main drive wheel ＊ 0311-2002 Fish-Eye Bearing 5118-02271104020-10 Internal stud...
  • Page 7 4.2 PARTS LIST ― IDLER ROLL Q’ty. Item. Part No. Description Remark 5118-02271103030-10 Screw 0121-2000 Washer ＊ 5041-1030000-10 Pu wheel with bearing 5041-1030100-10 PU Wheel ＊ 0301-0403 bearing 5118-02271103040-10 Spacer 0123-2000 ＊ Recommended spare parts...
  • Page 8 4.3 PARTS LIST — CONTROL BOX Q’ty. Item. Part No. Description Remark 3216-0006 Knob 3747-1001 Potentiometer 3213-4007 Toggle switch 3214-2009 Push button 3242-1120 Foot switch 3445-2009 Power socket 3445-0001 Power cord Option (Standard) 3456-0003 Power cord Option (European) 3456-0004 Power cord Option (Australian) 3456-0005 Power cord...
  • Page 9 5.1 CICUIT DIAGRAM...
