ProArc PT Series Owner's Manual

Welding positioner (3 axis)
Hide thumbs

Advertisement

Table of Contents

OWNER'S MANUAL
RD-8464DE
Important：Read these instructions before installing, operating or servicing this product.
Model：PT–XXXXH
Welding Positioner (3 Axis)
Serial Number：2311001 ~ and later
Revised Date：Jan. 21, 2024
UNITED PROARC CORPORATION
No.8 Gungye 2nd Road, Pingjen Industrial Park,
Tel No：886 3 4696600
Pingjen Dist., Taoyuan City 324403, Taiwan
Fax No：886 3 4694499
http://www.proarc.com.tw
E-Mail：
sales@proarc.com.tw

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT Series and is the answer not in the manual?

Questions and answers

Related Manuals for ProArc PT Series

Summary of Contents for ProArc PT Series

  • Page 1 Important：Read these instructions before installing, operating or servicing this product. Model：PT–XXXXH Welding Positioner (3 Axis) Serial Number：2311001 ~ and later Revised Date：Jan. 21, 2024 UNITED PROARC CORPORATION No.8 Gungye 2nd Road, Pingjen Industrial Park, Tel No：886 3 4696600 Pingjen Dist., Taoyuan City 324403, Taiwan Fax No：886 3 4694499 http://www.proarc.com.tw...
  • Page 2 TABLE OF CONTENTS Specifications 1.1 Specifications ....................1 Instruction 2.1 Introduction ....................2 Maintenance 2.2 Maintenance ....................2 Operation 3.1 Operation instruction ..................3 Service 4.1 Trouble shooting guide ................5 Parts list 5.1 Machine (PT-1000H) ................... 7 5.2 Machine (PT-2000H) ................... 8 5.3 Machine (PT-3000H) ...................

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS Operation and maintenance involve potential hazards. All operators and WARNING personnel should be alerted to possible hazards and precautions should be taken to prevent possible injury. Electrical safety Operator needs to take proper electrical insulation from work and electrical ground (PPE) to prevent electric shocks.

  • Page 4: Specifications

    1.1 SPECIFICATIONS Model Unit PT-1000H PT-2000H PT-3000H PT-5000H Power Input 3Ø AC220V 50/60Hz Capacity (W) 1,000 2,000 3,000 5,000 Rated center of gravity (S) Rated eccentricity (R) Rotation speed 0.05 ~ 1.0 0.05 ~ 0.8 0.05 ~ 0.8 0.05 ~ 0.8 Tilt range deg.

  • Page 5: Maintenance

    2.1 INTRODUCTION Main Features ＊ ProArc PT-H positioners offer the best solution for lifting, rotating and tilting heavy work-pieces with complex geometry. Work-piece height, angle and rotating speed are adjustable to ideal ergonomic working position. Loading capacity ranges from 1000 - 3000 kg.
  • Page 6 3.1 OPERATION INSTRUCTION 1. Rotary’s power switch：System’s control power switch . 2. “Start” switch (Power)：Turn ON the main power switch, press the control power switch ( power light ) to start operation. 3. Speed meter：Shows the speed.(rpm) 4. Foot switch： 1.
  • Page 7 3.1 OPERATION INSTRUCTION 5. Remote pendant： START：Press to activate continuous rotation and output weld ON signal. STOP：Press to stop rotation and stop weld ON signal. To switch rotating direction：Press and hold “CW / CCW rotation button” on remote pendant and press once on the “START”...

  • Page 8: Troubleshooting Guide

    4.1 TROUBLE SHOOTING GUIDE SYMPTOM POSSIBLE C AUSE/ REMEDY A. NFB jumps off. Check main circuit for any disconnection or short. B. No power input. Inspect the AC power input voltage. C. Power supply no DC24V output. 1. The power indicator light doesn't lit. (a) Inspect and make sure the switching power supply AC input voltage is correct.
  • Page 9 4.1 TROUBLE SHOOTING GUIDE SYMPTOM POSSIBLE C AUSE/ REMEDY A. Inverter breaks down, no output. Please refer to symptom Nos. 2 & 3. B. Hydraulic pump motor disabled Make sure AC220V / 380V is present. 5. Lift without action. C. Hydraulic solenoid malfunction. Check solenoid’s coil for any damage and correct DC24V control voltage.
  • Page 10 5.1 PART LIST ― MECHAMISM (PT-1000H) Item. Part No. Description Qty. Remark 0260-1051-1 Hydraulic pump ＊ 0353-0320 Worm reducer Rotation ＊ 0350-0040 Motor reducer Rotation ＊ 5014-1030000-30 Rotation drive pinion 5014-1630000-10 Shaft ＊ 0350-0052 Motor reducer Tilting ＊ 0353-0319 Worm Reducer Tilting ＊...
  • Page 11 5.2 PART LIST ― MECHAMISM (PT-2000H) Item. Part No. Description Qty. Remark ＊ 5015-1030000-21 Rotation drive pinion ＊ 0353-0341 Worm reducer Rotation drive ＊ 0353-0307 Reducer flange Rotation drive ＊ 0350-0049 Motor reducer Rotation drive 0260-1052 Hydraulic pump ＊ 3241-2002 Limit switch 0120-0005 Precision lock nut...
  • Page 12 5.3 PART LIST ― MECHAMISM ( PT-3000H ) Item. Part No. Description Qty. Remark ＊ 5015-1230000-21 Rotation drive pinion 0305-1301 Bearing 0120-0006 Precision lock nut ＊ 0353-0342 Worm reducer Rotation drive ＊ 0350-0049 Motor reducer Rotation drive 0261-0016 Hydraulic cylinder 5015-3650000-10 Shaft 5015-2030000-10...
  • Page 13 5.4 PART LIST ― MECHAMISM ( PT-5000H ) Item. Part No. Description Qty. Remark ＊ 5015-1430000-20 Rotation drive pinion 0305-1501 Bearing 0120-0007 Precision lock nut ＊ 0353-0352 Worm reducer Rotation drive ＊ 0350-0053 Motor reducer Rotation drive 0261-0016 Hydraulic cylinder 5015-3650000-10 Shaft 5015-2030000-10...
  • Page 14 5.5 PARTS LIST ― CONTROL BOX Item. Part No. Description Qty. Remark 3061-1006 Meter 3216-1003 Rotaryes switch 3214-4007 Push button 3332-1005 EMI Filter 3221-3010 No Fuse breaker 3224-1005 Magnetic contactor 3017-0007 Power supply ＊ 2501-6301-01 PLC & Software 3012-2103 PLC I/O Module 3251-4207 Relay with terminal 3251-2204...
  • Page 15 5.5 PARTS LIST ― CONTROL BOX...
  • Page 16 6.1 CIRCUIT DIAGRAM ― POWER (AC220V)
  • Page 17 6.1 CIRCUIT DIAGRAM ― POWER (AC380 ~ 460V)
  • Page 18 6.1 CIRCUIT DIAGRAM ― INVERTER...
  • Page 19 6.1 CIRCUIT DIAGRAM ― INVERTER...
  • Page 20 6.1 CIRCUIT DIAGRAM ― I/O LIST...
  • Page 21 6.1 CIRCUIT DIAGRAM ― CONNECTOR...

  • Page 22: Appendix A：parameter Settings (Pt-1000H)

    APPENDIX A：PARAMETER SETTINGS (PT-1000H) Parameter Code Turntable Tilt Lift 00-02 Parameter reset 00-10 Control mode 00-11 Speed Control mode 00-16 Load selection 00-20 Master frequency 00-21 Operation command 00-22 Stop method 01-00 Maximum operation frequency Output frequency of motor 1 01-01 01-12 Acceleration time 1...

  • Page 23: Appendix B：parameter Settings (Pt-2000H)

    APPENDIX B：PARAMETER SETTINGS (PT-2000H) Parameter Code Turntable Tilt Lift 00-02 Parameter reset 00-10 Control mode 00-11 Speed Control mode 00-16 Load selection 00-20 Master frequency 00-21 Operation command 00-22 Stop method 01-00 62.5 Maximum operation frequency Output frequency of motor 1 01-01 62.5 01-12...

  • Page 24: Appendix C：parameter Settings (Pt-3000H)

    APPENDIX C：PARAMETER SETTINGS (PT-3000H) Parameter Code Turntable Tilt Lift 00-02 Parameter reset 00-10 Control mode 00-11 Speed Control mode 00-16 Load selection 00-20 Master frequency 00-21 Operation command 00-22 Stop method 01-00 62.5 Maximum operation frequency Output frequency of motor 1 01-01 62.5 01-12...

  • Page 25: Appendix D：parameter Settings (Pt-5000H)

    APPENDIX D：PARAMETER SETTINGS (PT-5000H) Parameter Code Turntable Tilt Lift 00-02 Parameter reset 00-10 Control mode 00-11 Speed Control mode 00-16 Load selection 00-20 Master frequency 00-21 Operation command 00-22 Stop method 01-00 60.5 64.5 Maximum operation frequency Output frequency of motor 1 01-01 60.5 64.5...
