OWNER'S MANUAL
MODEL:TR – 0104
DIGITAL TURNING ROLL
Serial number:2101001 ~ and later
Date : Jan. 06, 2021
UNITED PROARC CORPORATION
Tel No:886 3 4696600
Fax No:886 3 4694499
E-Mail:
customerservice@proarc.com.tw
RD-8459AE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TR-0104 and is the answer not in the manual?

Questions and answers

Summary of Contents for ProArc TR-0104

  • Page 1 POSITIONING SYSTEM AND ACCESSORIES MODEL:TR – 0104 DIGITAL TURNING ROLL Serial number:2101001 ~ and later Date : Jan. 06, 2021 UNITED PROARC CORPORATION No. 3 Gungye 10 Road, Pingjen Ind. Park, Tel No:886 3 4696600 Pingjen City, Taoyuan 324, Taiwan Fax No:886 3 4694499...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction Introduction ......................i Safety precautions ....................ii Limited Warranty ....................iii Specification 1.1 Specification ....................1 1.2 Installation hole ....................2 Operator controls 2.1 Control panel ....................3 2.2 Operation ...................... 4 2.3 Adjustment procedure ..................5 Part list 3.1 Parts list –...
  • Page 4 INTRODUCTION A procedure, which, if not properly followed, may cause injury to the operator WARNING or others in the operating area. Equipment Identification The identification number specification or part number, model, and serial number of this unit usually appears on a nameplate attached to the control panel, record these numbers for future reference.
  • Page 5: Safety Precautions

    SAFETY PRECAUTIONS Operation and maintenance involves potential hazards. All operators and WARNING personnel should be alerted to possible hazards and precautions should be taken to prevent possible injury. Machine : Electrical safety ﹡ The counter, safety device against excess current and electrical installation, are compatible with its maximum power and its main voltage.
  • Page 6 SAFETY PRECAUTIONS Gases and fumes * Gases and fumes produced during the plasma cutting or welding process can be dangerous and hazardous to your health. ﹡ Ventilation must be adequate to remove gases and fumes during operation. ﹡ Keep all fumes and gases from the breathing area. ﹡...
  • Page 7: Limited Warranty

    UNITED PROARC’s obligation under this warranty policy is expressly limited to the replace or repair, at its option, of the defected part only. ProArc’s option to repair or replacement of a defected part under this warranty shall be based on FOB Taiwan basis.
  • Page 8: Specification 1.1 Specification

    1.1 SPECIFICATION TR ‒ 0104 Model Unit Input power 1 Phase, AC 110 ~ 240V, 50/60 Hz Turning capacity 1,000 Load capacity (Drive + Idler) 1,000 Speed range mm / min 80 ~ 1,600 ψ20 ~ψ500 /ψ400 ~ψ800 Diameter range (G / G1) Drive motor PMDC Motor, 65W Roller type...
  • Page 9: Installation Hole

    1.2 INSTALLATION HOLE...
  • Page 10: Operator Controls 2.1 Control Panel

    2.1 CONTROL PANEL Operation Panel: 1. Stop button. 2. Power socket. 3. Forward / Reverse switch. 4. Speed adjustment Knob. 5. Foot switch. 6. Panel display 7. Power cord.
  • Page 11: Operation

    2.2 OPERATION 1. Power cord: Connect power to 100V~240VAC single phase power. 2. Power switch (SW1): I = On,O = Off 3. Forward / Reverse switch (SW2): Reverse ( ) / Forward ( 4. Stop: Press the Stop button to pause all motion and disable all control. Rotate the Stop button clockwise to reset.
  • Page 12: Adjustment Procedure

    2.3 MAIN WHEEL ADJUSTMENT PROCEDURE Step 1: Start the machine, then adjust the speed to 50%. Step 2: Use 17mm wrench and adjust the nut in clockwise direction until the PU roller moves. Step3: Press the rollers with approximate 20-30 kg pressure and check for any slip on the PU rollers.
  • Page 13: Part List 3.1 Parts List - Driver Roll (Tr-0104P)

    3.1 PARTS LIST ― DRIVER ROLL ( TR-0104 P ) Item. Part No. Description Q’ty. Remark 5118-02271103030-10 Screw 0121-2000 Washer 5041-1030000-10 Pu wheel with bearing 5041-1030100-10 Pu wheel * 0301-0403 Bearing 5118-02271103040-10 Spacer 0123-2000 Hex nut 0122-2000 Spring washer 5041-1020000-10 Main drive wheel *...
  • Page 14: Parts List - Idler Roll (Tr-0104I)

    3.2 PARTS LIST ― IDLER ROLL ( TR-0104 I ) Item. Part No. Description Q’ty. Remark 5118-02271103030-10 Screw 0121-2000 Washer 5041-1030000-10 Pu wheel with bearing 5041-1030100-10 Pu wheel * 0301-0403 Deep-groove ball bearing 5118-02271103040-10 Spacer 0123-2000 0122-2000 Spring washer 5118-02271115000-11 Idler wheel assembly *...
  • Page 15: Parts List - Control Box

    3.3 PARTS LIST ― CONTROL BOX Item. Part No. Description Q’ty. Remark 3216-0006 Knob * 3747-1001 Potentiometer 3213-4007 Toggle switch * 3922-1310 Printed circuit board * 3922-1310-1 Printed circuit board Encoder 3214-2009 Push button Stop 3242-1118 Foot switch Cable 3M 3445-2009 Power socket 3445-0001...
  • Page 16: Circuit Diagram 4. Circuit

    4. CIRCUIT DIAGRAM...
