Grizzly T34360 Instructions

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
Introduction
The Model T34360 Extension Wings for Model
G0999 15" Planer are made of steel construction
and measure 17" long, 14" wide, and 1
offering increased infeed/outfeed area to support
longer workpieces.
Figure 1. Model T34360 Extension Wings
installed on Model G0990.
Inventory
Description
A. Extension Wings ........................................ 2
B. Mounting Brackets ...................................... 4
C. Shoulder Screws M8-1.25 x 12, 4 x 13 ....... 8
D. Button Head Cap Screws M6-1 x 10 .......... 8
E. Hex Wrench 4mm ....................................... 1
A
B
Figure 2. Boxed inventory.
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
C
D
E
COPYRIGHT © NOVEMBER, 2024 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
(FOR MODELS MFD. SINCE 01/25) #JA23429 PRINTED IN TAIWAN
***Keep for Future Reference***
EXTENSION WINGS FOR
MODEL G0999 15" PLANER
Installation
⁄ " tall,
3
4
Items Needed
Safety Glasses (Per Person) ........................1 Pr.
Hex Wrench 5mm .............................................. 1
Straightedge 36" ................................................ 1
To install extension wings:
DISCONNECT MACHINE FROM POWER!
1.
Attach (1) mounting bracket to each corner
2.
of machine base (see Figure 3) with (8)
M8-1.25 x 12, 4 x 13 shoulder screws.
Qty
Machine
Base
Figure 3. Location of mounting brackets and
Place (1) extension wing on front mounting
3.
brackets.
MODEL T34360
INSTRUCTIONS
Wear safety glasses during
the entire setup process!
x 8
fasteners.
Qty
Mounting
Brackets
(1 of 4)
V1.11.24
